本文资料与代码来源于医学方出品的《SCI论文绘图之道》，转载请说明。
一、前言
高水平的SCI插图有如下的特点：
1.形式丰富且合适；
2.信息直观，每张图最多反应2-3个信息；
3.根据期刊要求使用颜色、形状、大型；
4.布局不能留太多空白和拥挤；
5.必要时添加辅助线帮助阅读。
如何绘制：
1.理解数据
2.绘制草图
3.根据期刊要求准备图片配色、格式、分辨率
二、ggplot2的绘图原理
2.1 散点图
#install.packages(c('tidyverse','ggsci'))
library(tidyverse)
library(ggsci)
ggplot(mtcars,aes(mpg,qsec,color = factor(cyl)))+
size = 3, alpha = .6)+
theme_bw()+
scale_color_lancet()+
scale_x_continuous()+
scale_y_continuous()
元素组成
元素组成：
1.画布：ggplot()函数，mtcars为画图数据
2.横纵坐标：mpg,qsec两个变量
3.散点- 几何对象： geom_point(）函数，size,alpha为控制点属性的参数
4.散点颜色- 变量映射：color = factor(cyl)：把cyl这个变量因子化，不同的颜色表示变量的分类水平
5.图例- 变量映射的产物
6.背景网路：theme_bw()完成，主题函数
7.坐标：横纵坐标，包括坐标轴上的刻度。
最基本的四要素：
1)绘图数据:mtcars
2)画布：由geom_point()函数完成
3)映射：由aes()函数完成
4)几何对象：由 geom_point()函数完成
ggplot2的基本结构：
1）变量映射系统
2）几何对象系统
3）标度系统
4）主题系统
三、常见图形绘制
连续型数据：某个区间内的任意值都可以取的数据，特点是可以进行 无限的分割和测量，两个相邻的值之间可能存在无数个中间值。
离散型数据则是指只能取到有限个数或者是可数个数的数据，通常以整数表示。
3.1 单个连续型变量
常用：盒型图和小提琴图，在纵坐标上展示数据
离散型变量（分组变量）+连续变量
3.2 两个或多个连续型变量
散点图图形-shape参数
ggplot中颜色实现两种方式：
1.变量映射（取值越大颜色越深）
2.人为定义：颜色参数设置为某个颜色
mtcars <- mtcars %>% as_tibble() %>% mutate(cyl = factor(cyl),
carb = factor(carb))
set.seed(2019)
dsamp <- diamonds[sample(nrow(diamonds), 1000), ]
p1 <- ggplot(mtcars,aes(mpg,qsec,fill = cyl))+
geom_point(size = 3,shape = 21, color = 'black')+
theme_classic()+
theme(legend.position = c(.1,.8),#图标的位置
legend.background = element_rect(color = 'black'))#图标的颜色
p2 <- ggplot(mtcars,aes(mpg,qsec,fill = carb))+
geom_point(size = 3,shape = 21, color = 'black')+
theme_classic()+
theme(legend.position = c(.1,.7),
legend.background = element_rect(color = 'black'))
#plot_grid()函数用于多个 ggplot 对象（即图表）排列组合,align参数设置对齐方式 ，v表示垂直对齐，h表示水平对齐。
plot_grid(p1,p2,ncol=2,labels = c('A','B'),align = c('v','h'))
散点图颜色：标度函数-scale_fill(); scale_color()，分为连续色和离散色。
1.连续色：由scale_fill函数第三个词决定，如scale_fill_gradient表示连续色
dsamp <- dsamp %>% mutate(depth = depth - median(depth))
p1 <- ggplot(dsamp, aes(carat, price)) +
geom_point(aes(fill = depth),shape=21, color = 'black',size = 2)+
scale_fill_gradient2(low = '#41ab5d',mid = 'white',high = '#e31a1c',
midpoint = 0)+
theme(legend.position = c(.1,.8))
p2 <- ggplot(dsamp, aes(carat, price)) +
geom_point(aes(fill = depth),shape=21, color = 'black',size = 2)+
scale_fill_gsea()+
theme(legend.position = c(.1,.8))
plot_grid(p1,p2,ncol=2,labels = c('A','B'),align = c('v','h'))
2.离散色：使用配色包，如ggsci包，提供了一组科学期刊风格的配色方案
3.3 连续型变量绘图优化
气泡图
set.seed(2019)
dsamp <- diamonds[sample(nrow(diamonds), 500), ]
dsamp <- dsamp %>% mutate(x = exp(x))
p1 <- ggplot(dsamp, aes(carat, price)) +
geom_point(aes(size = x,fill = cut),shape=21,
color = 'black')+
scale_fill_brewer(palette = 'Set2')
p2 <- ggplot(dsamp, aes(carat, price)) +
geom_point(aes(size = log(x),fill = cut),shape=21,
color = 'black')+
scale_fill_brewer(palette = 'Set2')
#RColorBrewer配色包--颜色区分较大，适合分类变量，如 Set1, Set2, Set3, Accent, Paired, Pastel1, Pastel2 等
plot_grid(p1,p2,ncol=2,labels = c('A','B'),align = c('v','h'))
二维密度图：适合大数据量，stat_density_2d()函数
a <- data.frame( x=rnorm(20000, 10, 1.9), y=rnorm(20000, 10, 1.2) )
b <- data.frame( x=rnorm(20000, 14.5, 1.9), y=rnorm(20000, 14.5, 1.9) )
c <- data.frame( x=rnorm(20000, 9.5, 1.9), y=rnorm(20000, 15.5, 1.9) )
data <- rbind(a,b,c)
p2 <- ggplot(data, aes(x=x, y=y) ) +
stat_density_2d(aes(fill = ..level..), geom = "polygon")+
theme_bw()+
scale_fill_gradient(low = '#edf8e9',high = '#238b45')+
theme(panel.grid = element_blank())
散点+密度图：ggExtra包
install.packages("ggExtra")
library(ggExtra)
piris <- ggplot(iris, aes(Sepal.Length, Sepal.Width, color = Species)) +
geom_point(shape=21, size = 3,stroke = 1.2)+
scale_color_npg()+
theme_bw()+
theme(legend.position = c(.1,.86))
ggMarginal(piris, type= 'density',
groupFill = TRUE)
层峦叠峰：ggridges包，geom_density_ridges()函数
install.packages('ggridges')
library(ggridges)
ggplot(dsamp,aes(x = carat,y = clarity, fill = clarity))+
geom_density_ridges(alpha = .5)+
scale_fill_brewer(palette = 'Set3')+
theme_classic()
3.4 两个连续型变量相关性图-ggcorrplot包
install.packages("ggcorrplot")
library(ggcorrplot)
mtcars <- mtcars %>% select(c('mpg','disp','hp','drat','wt','qsec'))
corr <- round(cor(mtcars), 1)
p1 <- ggcorrplot(
corr,
type = "lower",
outline.color = "white",
colors = c("#6D9EC1", "white", "#E46726")
)
p2 <- ggcorrplot(
corr,
type = "upper",
outline.color = "white",
colors = c("#084594", "white", "#ef3b2c")
)
p3 <- ggcorrplot(corr,
type = "lower",
lab = TRUE)
p.mat <- cor_pmat(mtcars)
p4 <- ggcorrplot(corr,
type = "lower",
p.mat = p.mat)
plot_grid(p1,p2,p3,p4,ncol=2,labels = LETTERS[1:4],align = c('v','h'))
3.5 连续型变量趋势图
3.5.1线图：geom_line()+geom_point()函数
set.seed(2020)
id <- 1:8
dat <- tibble(x = rep(id,2),
y = c(2*id+rnorm(8,0,1),
6*id+rnorm(8,0,2)),
group = rep(c('Group1','Group2'),each = 8))
p1 <- ggplot(dat,aes(x, y, color = group))+
geom_line(size = .8)+
geom_point(shape = 21,color = 'black',size=3,fill = 'white')+
scale_color_d3()+
theme_classic()+
theme(legend.position = c(.15,.85))
p2 <- ggplot(dat,aes(x, log(y), color = group))+
geom_line(size = .8)+
geom_point(shape = 21,color = 'black',size=3,fill = 'white')+
scale_color_d3()+
theme_classic()+
theme(legend.position = c(.15,.85))
p3 <- ggplot(dat,aes(x, y))+
geom_line(size = .8,color = '#2b8cbe')+
geom_point(shape = 21,color = 'black',size=3,fill = 'white')+
theme_classic()+
facet_wrap(~group,ncol = 2,scales = 'free_y')+
theme(legend.position = c(.15,.85),
strip.background = element_blank(),
strip.text = element_text(size = 12))
p4 <- plot_grid(p1,p2,ncol=2,labels = LETTERS[1:2],align = c('v','h'))
plot_grid(p4,p3,ncol=1,labels = c('','C'),align = c('v','h'))
3.5.2配比坡度图
3.5.3面积图 geom_area()函数
3.5.4平滑曲线 geom_smooth()函数
3.5.5生存曲线 survminer,survival包
3.5.6三元图 ggtern包
与等高线，三位密度图结合
install.packages('ggtern')
library(ggtern)
set.seed(2019)
a <- tibble(x=rnorm(20000, 80, 30),
y=rnorm(20000, 100, 30),
z = rnorm(20000, 60, 20))
ggtern(data=a,aes(x,y,z))+
stat_density_tern(aes(fill = ..level..,alpha = ..level..),
geom = 'polygon')+
scale_fill_gradient(low = '#fcbba1',high = '#ef3b2c')+
theme_showarrows()+
guides(color = "none", fill = "none", alpha = "none")
3.5.7 雷达图:ggradar包
3.6 离散型数据构成可视化
3.6.1.饼图：ggplot中由条形图变形而来，条图和坐标系转换而成
injuries <- tibble(type = c('Road injury','Self-harm','CVD',
'Cancers','Infectious Diseases'),
counts = c(214,123,69,24,17),
share = counts/sum(counts)*100)
p1 <- ggplot(injuries,aes('', y = counts, fill = type))+
geom_bar(width = 1, size = 1, color = 'white',stat = 'identity')+
coord_polar(theta = 'y')+
geom_text(aes(label = paste0(round(share,1),'%')),
position = position_stack(vjust = .5))+
labs(x = NULL, y = NULL, fill = NULL,
title = "Injury proportion in young adults")+
scale_fill_npg()+
theme_classic() +
theme(axis.line = element_blank(),
axis.text = element_blank(),
axis.ticks = element_blank(),
plot.title = element_text(hjust = 0.5, color = "#666666"))
injuries2 <- injuries %>% mutate(type = factor(type,
levels = type[order(counts)]))
p2 <- ggplot(injuries2,aes('', y = counts, fill = type))+
geom_bar(width = 1, size = 1, color = 'white',stat = 'identity')+
coord_polar(theta = 'y')+
geom_text(aes(label = paste0(round(share,1),'%')),
position = position_stack(vjust = .5))+
labs(x = NULL, y = NULL, fill = NULL,
title = "Injury proportion in young adults")+
scale_fill_npg()+
theme_classic() +
theme(axis.line = element_blank(),
axis.text = element_blank(),
axis.ticks = element_blank(),
plot.title = element_text(hjust = 0.5, color = "#666666"))+
guides(fill = guide_legend(reverse = TRUE))
plot_grid(p1,p2,ncol=2,labels = LETTERS[1:2],align = c('v','h'))
3.6.2玫瑰图:饼图x轴进行真实变量映射
ggplot(injuries,aes(x = type, y = counts, fill = type))+
geom_bar(width = 1,color = 'black',stat = 'identity')+
coord_polar(theta = 'x')+
geom_text(aes(label = paste0(round(share,1),'%'),
y = counts+2))+
labs(x = NULL, y = NULL, fill = NULL,
title = "Injury proportion in young adults")+
scale_fill_tron()+
theme_bw() +
theme(axis.text.x = element_text(size = 13, color='black',
angle = seq(-30,-330,len = 5)),
plot.title = element_text(hjust = 0.5, color = "#666666"),
panel.border = element_blank(),
axis.text.y = element_blank(),
axis.ticks.y = element_blank(),
legend.position = 'none')
3.6.3戒指图：设置条柱的宽度width及x轴取值范围
install.packages('ggpubr')
library(ggpubr)
ggdonutchart(injuries,'share',
label = paste0(round(injuries$share),'%'),
fill = 'type',color = 'white',
palette = 'lancet')
3.6.4.树图
install.packages('treemapify')
library(treemapify)
set.seed(2019)
diseases <- data.frame(type = rep(c('CVD','Infections','Cancer',
'Metabolic','Digestive','CNS'),
times = c(5,5,5,3,4,6)),
diseases = c('Heart attack','Stroke','CHD',
'Arrhythmia','Heart failure',
'Hepatitis','Malaria','HIV',
'TB','Influenza','HCC','CRC',
'Lung','Gastric','Breast',
'Diabetes','Hypertention',
'Mucolipidoses','IBD','Celiac Disease',
"Crohn's Disease",'Diarrhea',
'Autism','ADHD','Depression','Meningitis',
'Migraine','GBM'),
freqs = sample(20:60,28))
ggplot(diseases,aes(area = freqs,fill = type,
label = diseases, subgroup = type))+
geom_treemap(color = 'gray20')+
geom_treemap_subgroup_border() +
geom_treemap_subgroup_text(place = "centre", grow = T,
alpha = 0.5, colour ="black",
fontface = "italic", min.size = 0) +
geom_treemap_text(colour = "white", place = "topleft", reflow = T)+
scale_fill_brewer(palette = 'Set2')
3.7 离散型数据分布: geom_hline()+geom_bar()
3.7.1 堆栈式条图
injuries <- tibble(age = rep(c('Young adults',
'Middle-aged people',
'the elders'),each=5),
type = rep(c('Road injury','Self-harm','CVD',
'Cancers','Infectious Diseases'),3),
counts = c(214,123,69,24,17,
129,110,201,101,45,
56,32,212,189,78))
injuries <- injuries %>% mutate(age = factor(age,
levels = c('Young adults',
'Middle-aged people',
'the elders')))
injuries <- injuries %>%
mutate(type = factor(type,levels = c('CVD','Road injury','Cancers',
'Self-harm','Infectious Diseases')))
p1 <- ggplot(injuries,aes(type,weight = counts,fill = age))+
geom_hline(yintercept = seq(100,400,100),color = 'gray')+
geom_bar(color = 'black',width = .7,position = 'stack')+
scale_fill_brewer(palette = 'Accent')+
scale_y_continuous(expand = c(0,0))+
theme_classic()+
theme(axis.text.x = element_text(angle = 45,hjust=1))
p2 <- ggplot(injuries,aes(type,weight = counts,fill = age))+
geom_bar(color = 'black',width = .7,position = 'fill')+
scale_fill_brewer(palette = 'Accent')+
scale_y_continuous(expand = c(0,0))+
theme_classic()+
theme(axis.text.x = element_text(angle = 45,hjust=1))
plot_grid(p1,p2,ncol=1,labels = c('A','B'))
3.7.2 条图排序，突出最重要的分组
作图前对y轴数值进行排序，order默认从小到大
set.seed(2019)
injuries <- tibble(
type = c('Heart attack','Stroke','CHD',
'Arrhythmia','Heart failure',
'Hepatitis','Malaria','HIV',
'TB','Influenza','HCC','CRC',
'Lung','Gastric','Breast',
'Diabetes','Hypertention',
'Mucolipidoses','IBD','Celiac Disease',
"Crohn's Disease",'Diarrhea',
'Autism','ADHD','Depression','Meningitis',
'Migraine','GBM'),
counts = sample(20:100,28))
injuries <- injuries %>% mutate(
type = factor(type,levels = type[order(counts)]))
p1 <- ggplot(injuries,aes(type,weight = counts))+
geom_hline(yintercept = seq(20,90,10),color = 'gray')+
geom_bar(color = 'black',width = .7,fill = '#00bdaa',size = .3)+
scale_y_continuous(expand = c(0,0))+
theme_classic()+
theme(axis.text.x = element_text(angle = 45,hjust=1))
injuries2 <- injuries %>% mutate(
type = factor(type,levels = rev(type[order(counts)])))
# or:
#injuries2 <- injuries %>% mutate(
# type = factor(type,levels = type[order(counts,decreasing = T)]))
p2 <- ggplot(injuries2,aes(type,weight = counts))+
geom_hline(yintercept = seq(20,90,10),color = 'gray')+
geom_bar(color = 'black',width = .7,fill = '#a1dd70',size = .3)+
scale_y_continuous(expand = c(0,0))+
theme_classic()+
theme(axis.text.x = element_text(angle = 45,hjust=1))
plot_grid(p1, p2, ncol = 1,labels = c('A','B'),align = c('v','h'))
当有正负值时
set.seed(2019)
df <- tibble(diseases = c('Heart attack','Stroke','CHD',
'Arrhythmia','Heart failure',
'Hepatitis','Malaria','HIV',
'TB','Influenza','HCC','CRC',
'Lung','Gastric','Breast',
'Diabetes','Hypertention',
'Mucolipidoses','IBD','Celiac Disease',
"Crohn's Disease",'Diarrhea',
'Autism','ADHD','Depression','Meningitis',
'Migraine','GBM'),
trends = rnorm(28,0,2))
df <- df %>% mutate(
diseases = factor(diseases,levels = rev(diseases[order(trends)])))
ggplot(df,aes(diseases,weight = trends))+
geom_hline(yintercept = seq(-4,3,1),color = 'gray')+
geom_bar(color = 'black',width = .6,fill = '#5bd1d7',size = .3)+
scale_y_continuous(limits = c(-5,3.5))+
theme_classic()+
ylab('Temporal trends of diseases')+
theme(axis.text.x = element_text(angle = 45,hjust=1))
瘦身--棒棒糖图：geom_segment()+geom_point()
ggplot(injuries,aes(y = type,x = counts))+
geom_segment(aes(y = type, yend = type,x = 0,xend = counts),
color = 'black')+
geom_point(color = 'black',fill = '#28c3d4',
size = 3,shape = 21)+
scale_y_discrete(expand = c(0.02,0.02))+
scale_x_continuous(expand = c(0,0.8),
breaks = seq(20,100,20),
labels = seq(20,100,20))+
theme_light()+
ylab('')+
theme(
panel.grid.major.y = element_blank(),
panel.border = element_blank(),
axis.ticks.y = element_blank())
一个分组由不同亚型组成
set.seed(2019)
diseases <- data.frame(type = rep(c('CVD','Infections','Cancer',
'Metabolic','Digestive','CNS'),
times = c(5,5,5,3,4,6)),
disease = c('Heart attack','Stroke','CHD',
'Arrhythmia','Heart failure',
'Hepatitis','Malaria','HIV',
'TB','Influenza','HCC','CRC',
'Lung','Gastric','Breast',
'Diabetes','Hypertention',
'Mucolipidoses','IBD','Celiac Disease',
"Crohn's Disease",'Diarrhea',
'Autism','ADHD','Depression','Meningitis',
'Migraine','GBM'),
freqs = sample(20:60,28))
diseases2 <- diseases %>%
mutate(disease =
factor(disease,levels = disease[order(freqs,decreasing = TRUE)]))
sums <- tapply(diseases$freqs,type,sum)
diseases3 <- diseases2 %>%
mutate(type = factor(type,levels =
names(sums)[order(sums,decreasing = T)]),
disease = interaction(disease,type,drop = TRUE))
ggplot(diseases3,aes(disease, weight = freqs, fill = type))+
geom_bar(color = 'black',width = .6,size = .3)+
scale_y_continuous(expand = c(0,0))+
scale_x_discrete(labels = gsub('\\.[a-zA-Z]{0,20}','',
levels(diseases3$disease)))+
scale_fill_lancet()+
theme_classic()+
theme(axis.text.x = element_text(angle = 45,hjust=1))杠铃图geom_segment()+geom_point)()+
df <- tibble(Age = rep(c('0-19','20-34','35-49','50-64','65+'),2),
Sex = rep(c('Male','Female'),each = 5),
Values = c(18,21,20,26,29,15,18,15,22,23))
df2 <- df %>% tidyr::spread(key = Sex, value = Values)
p2 <- ggplot()+
geom_segment(data = df2,aes(x = Female, xend = Male,
y = Age, yend = Age),
size = 1.5,color = 'gray')+
geom_point(data = df, aes(Values, Age, fill = Sex),
shape = 21,size = 3)+
labs(x = 'Values')+
scale_fill_jco()+
theme_light()+
theme(legend.position = 'top',
panel.grid.minor=element_blank(),
panel.grid.major.y=element_blank(),
panel.grid.major.x=element_line(),
axis.ticks=element_blank(),
panel.border=element_blank())
plot_grid(p1, p2, ncol = 2,labels = c('A','B'),align = c('v','h'))
圆心旋转饼图
整洁数据，将数据整理成这样的格式
data <- data.frame(
individual=paste( "Mister ", seq(1,60), sep=""),
group=c( rep('A', 10), rep('B', 30), rep('C', 14), rep('D', 6)) ,
value=sample( seq(10,100), 60, replace=T)
)
empty_bar <- 4
to_add <- data.frame( matrix(NA, empty_bar*nlevels(data$group), ncol(data)) )
colnames(to_add) <- colnames(data)
to_add$group <- rep(levels(data$group), each=empty_bar)
data <- rbind(data, to_add)
data <- data %>% arrange(group)
data$id <- seq(1, nrow(data))
label_data <- data
number_of_bar <- nrow(label_data)
angle <- 90 - 360 * (label_data$id-0.5) /number_of_bar
label_data$hjust <- ifelse( angle < -90, 1, 0)
label_data$angle <- ifelse(angle < -90, angle+180, angle)
ggplot(data, aes(x=as.factor(id), y=value, fill=group)) +
geom_bar(stat="identity", alpha=0.5) +
ylim(-100,120) +
theme_minimal() +
theme(
legend.position = "none",
axis.text = element_blank(),
axis.title = element_blank(),
panel.grid = element_blank(),
plot.margin = unit(rep(-1,4), "cm")) +
coord_polar() +
geom_text(data=label_data, aes(x=id, y=value+10, label=individual,
hjust=hjust), color="black",
fontface="bold",alpha=0.6, size=2.5,
angle= label_data$angle, inherit.aes = FALSE )
金字塔图：
populations <- tibble(age = rep(c("0-4","5-9","10-14","15-19",
"20-24","25-29","30-34",
"35-39","40-44","45-49","50-54",
"55-59","60-64","65-69","70-74",
"75-79","80-84",'85+'),2),
sex = rep(c('Male','Female'),each = 18),
pops = c(91646,65397,75560,108622,245368,
278821,196527,153679,153202,248852,
388813,350713,241516,130285,103534,
119681,76644,47576,
85376,62108,72649,107474,238128,269100,
192116,159126,156828,240783,378479,
361806,225168,123183,112859,149189,
105804,78370
))
populations <- populations %>% mutate(
age = factor(age, levels = c("0-4","5-9","10-14","15-19",
"20-24","25-29","30-34",
"35-39","40-44","45-49","50-54",
"55-59","60-64","65-69","70-74",
"75-79","80-84",'85+')),
pops = pops/1e3,
pops = ifelse(sex == 'Female',-pops, pops))
library(ggthemes)
ggplot(populations,aes(x =age,y=pops,fill=sex,width=0.8)) +
coord_flip() +
geom_bar(data=subset(populations,sex=="Female"),stat = "identity") +
geom_bar(data=subset(populations,sex=="Male"), stat = "identity") +
scale_y_continuous(breaks = seq(-400,400,length=9),
labels = paste0(as.character
(c(abs(seq(-400,400,length=9)))), "k"),
limits = c(-450, 450)) +
theme_economist_white(horizontal = FALSE) +
scale_fill_economist() +
labs(title="2010",
y="Population",x="Age") +
guides(fill=guide_legend(reverse = TRUE))+
theme(
legend.position =c(0.8,0.9),
legend.title = element_blank(),
plot.title = element_text(size=20),
plot.caption = element_text(size=12,hjust=0)
)
3.8 离散型数据相关性可视化
韦恩图-VennDiagram包
install.packages('VennDiagram')
library(VennDiagram)
set.seed(2019)
SNP_pop_1=paste(rep("SNP_" , 200) , sample(c(1:1000) ,
200 , replace=F) , sep="")
SNP_pop_2=paste(rep("SNP_" , 200) , sample(c(1:1000) ,
200 , replace=F) , sep="")
SNP_pop_3=paste(rep("SNP_" , 200) , sample(c(1:1000) ,
200 , replace=F) , sep="")
SNP_pop_4=paste(rep("SNP_" , 200) , sample(c(1:1000) ,
200 , replace=F) , sep="")
venn.diagram(
x = list(SNP_pop_1 , SNP_pop_2 , SNP_pop_3, SNP_pop_4),
category.names = c("SNP pop 1" , "SNP pop 2 " , "SNP pop 3","SNP_pop_4"),
filename = 'Venn.png',
output = T ,
lty = 'blank',
fill = c('#07689f','#a2d5f2','#ff7e67','#10ddc2')
)upset图-ggupset包
install.packages('ggupset')
library(ggupset)热图heatmap()函数或pheatmap包
set.seed(2019)
df <- tibble(cancers = rep(c('Bladder','Bone','CNS','Breast','Cervix uteri',
'CRC','Lung','Liver','Prostate','Kidney',
'Eye','Skin','Thyroid','HLM','GBM'),3),
regions = rep(c('Region A','Region B','Region C'),each = 15),
incidence = sample(10:100,45))
#16-rank(incidence)显示肿瘤在不同regions从大到小排列，需要根据自己的数据更改
df <- df %>% group_by(regions) %>% mutate(ranks = 16-rank(incidence))
ggplot(df, aes(cancers, regions,fill = incidence))+
geom_tile(color = 'gray20',size = .4)+
theme_gray()+
scale_x_discrete(expand = c(0,0)) +
scale_y_discrete(expand = c(0,0))+
theme(axis.text.x = element_text(angle = 45,hjust=1))+
labs(x = "", y = "") +
geom_text(aes(label = ranks))+
scale_fill_gradient(low = '#fff5f0',high = '#cb181d')3.9 文字注释：叠加文本 text或annotate()函数
1.ggrepel包中geom_text_repel()函数加标签
set.seed(2019)
df <- tibble(gene = paste0('gene',1:5000),
expressions = c(rnorm(4995,3,0.5),
5.5,6,7,8,9),
position = sample(1:100,5000,replace = T))
df <- df %>% mutate(expressions = ifelse(expressions<0,0.01,expressions),
level = ifelse(expressions>5,'High','Low'))
install.packages('ggrepel')
library(ggrepel)
ggplot(df, aes(x = position, y= expressions,
fill = level,size = level))+
geom_hline(yintercept = 5,color = 'gray',linetype =2)+
geom_jitter(shape = 21, color = 'black')+
scale_fill_manual(values = c('blue','gray'))+
scale_size_manual(values = c(4,2))+
geom_text_repel(data = df[df$expressions>=5,],
aes(x = position, y= expressions,label = gene))+
theme(legend.position = 'none')
2.gghighlight包高亮文本
install.packages('gghighlight')
library(gghighlight)
gghighlight_point(df,aes(position, expressions, color = level,
size = level),
expressions > 5)+
geom_hline(yintercept = 5,color = 'gray',linetype =2)+
scale_color_manual(values = c('blue','gray'))+
scale_size_manual(values = c(4,2))+
theme(legend.position = 'none')grid包在绘图区域外添加文本
annotate()函数可以标记多种元素，如文本、矩形、散点等
ggplot(mtcars, aes(x = wt, y = mpg)) +
geom_point(shape = 21, color = 'black',fill = '#ff8a5c',size=4)+
geom_smooth(method = lm)+
annotate("text", x = 5, y = 32, label = "italic(R) ^ 2 == 0.75",
parse = TRUE,size = 6, color = 'blue')+
theme_bw()3.10 p值标注-ggsignif, ggpval, ggstatsplot包
ggsignif
install.packages("ggsignif")
library(ggsignif)
set.seed(2019)
df <- tibble(group = rep(paste('Group',LETTERS[1:4]),times = c(10,8,10,13)),
values = c(rnorm(10,15,2),rnorm(8,14,2),
rnorm(10,8,1),rnorm(13,5,2)))
p1 <- ggplot(df,aes(group,values))+
geom_boxplot()+
geom_jitter(size = 2,shape = 21,fill = 'gray40')+
geom_signif(comparisons = list(c('Group A','Group B'),
c('Group A','Group C'),
c('Group A','Group D')),
map_signif_level = FALSE, textsize=6, #TRUE标记星号
test = t.test,
step_increase = 0.2) +
ylim(NA, 25)+
theme_classic()
plot_grid(p1,p2,ncol=2,align = 'h',labels = c('A','B'))
ggstatsplot
install.packages("ggstatsplot")
library(ggstatsplot)
ggbetweenstats(
data = iris,
plot.type = 'box',
x = Species,
y = Sepal.Length,
pairwise.comparisons = T,
mean.plotting = F,
messages = T,
type = 'p',
palette = 'Set1') +
scale_y_continuous(breaks = seq(3, 8, by = 1))+
theme_classic()+
theme(legend.position = c(.11,.8))
ggstatsplot
3.11 seqlogo与进化树
seqlogo（基序图）：ggseqlogo包，需要将序列转化字符串
不同位置展示该位置上碱基的构成比例，字母越大则表示该碱基占比越大。也可以用来展示蛋白序列。
install.packages('ggseqlogo')
library(ggseqlogo)
data(ggseqlogo_sample)
ggseqlogo( seqs_dna$MA0001.1 )
MA0001.1
ggplot()+
annotate("rect", xmin = 0.5, xmax = 3.5, ymin = -0.05, ymax = 1.9,
alpha=0.1, col="black", fill="yellow")+
geom_logo(seqs_dna$MA0001.1, stack_width = 0.9,
col_scheme = 'nucleotide2')+
annotate("segment", x=4, xend = 8, y=1.2, yend = 1.2, size=2)+
annotate("text", x=6, y=1.3, label="Text annotation")+
theme_logo()
加标注
进化树-ggtree包
环形结构进化树
nwk <- system.file("extdata", "sample.nwk", package="treeio")
tree <- read.tree(nwk)
circ <- ggtree(tree, layout = "circular")
df <- data.frame(first=c("a", "b", "a", "c", "d", "d",
"a", "b", "e", "e", "f", "c", "f"),
second= c("z", "z", "z", "z", "y", "y",
"y", "y", "x", "x", "x", "a", "a"))
rownames(df) <- tree$tip.label
set.seed(2019)
df2 <- as.data.frame(matrix(rnorm(39), ncol=3))
rownames(df2) <- tree$tip.label
colnames(df2) <- LETTERS[1:3]
p1 <- gheatmap(circ, df, offset=.8, width=.2,
colnames_angle=95, colnames_offset_y = .25) +
scale_fill_viridis_d(option="D", name="discrete\nvalue")
library(ggnewscale)
p2 <- p1 + new_scale_fill()
p3 <- gheatmap(p2, df2, offset=15, width=.3,
colnames_angle=90, colnames_offset_y = .25) +
scale_fill_viridis_c(option = 'C',name="continuous\nvalue")
plot_grid(p1,p3,ncol = 2,labels = c('A','B'))
环形结构进化树
和玹图-chordDiagram()函数，输入数据为数据框或矩阵
library(circlize)
set.seed(2019)
numbers <- sample(c(1:1000), 100, replace = T)
data <- matrix( numbers, ncol=5)
rownames(data) <- paste0("Set-", seq(1,20))
colnames(data) <- paste0("Pair-", seq(1,5))
chordDiagram(data, transparency = 0.5)
元素增多
circos.par("track.height" = 0.4)
set.seed(2019)
data = data.frame(
factor = sample(letters[1:8], 1000, replace = TRUE),
x = rnorm(1000),
y = runif(1000)
)
circos.initialize( factors=data$factor, x=data$x )
circos.trackPlotRegion(factors = data$factor, y = data$y,
panel.fun = function(x, y) {
circos.axis()
})
circos.trackPoints(data$factor, data$x, data$y, col="deeppink",pch = 16)
circos.trackHist(data$factor, data$x, col="#69b3a2")
4.配色-RColorBrewer, ggsci, paletteer包
配色网站：https://colorbrewer2.org/
4.1离散色-离散变量上色
ggsci包匹配期刊配色，但不一定符合杂志最新配色要求
RColorBrewer包集成到ggplot2中，使用scale_fill_brewer()函数即可。推荐使用Set2,Set3,Accent配色板
RColorBrewer包配色板
paletteer包含25个包，869种配离散色
devtools::install_github("EmilHvitfeldt/paletteer")
library(paletteer)
p1 <- ggplot(dsamp, aes(carat, price, fill = cut)) +
geom_point(shape = 21, color = 'black', size = 3) +
scale_fill_paletteer_d("awtools::mpalette") +
theme_classic() +
labs(title = 'awtools-mpalette', x = '', y = '') +
theme(legend.position = c(.15,.8),
legend.background = element_rect(fill = NA),
plot.title = element_text(hjust = 0.5))
p1
paletteer包配色
scale_fill_manual()函数自定义
4.2 连续色-paletteer包中scale_fill_paletteer_c()函数即可调用。
5.主题选择与整体布局
展示数据大小，选择网格背景 ，方便比较大小；
展示数据相关性，选择空白背景的test和classic主题。
set.seed(2019)
dsamp <- diamonds[sample(nrow(diamonds), 1000), ]
P1 <- ggplot(dsamp,aes(carat, price, fill = cut))+
geom_point(shape = 21, color = 'black', size = 3)+
scale_fill_manual(name = '',
values = c('#a6cee3','#1f78b4','#b2df8a','#33a02c','#fb9a99'))+
labs(title = 'default theme',x='',y='')+
theme(legend.position = c(.15,.8),
legend.background = element_rect(fill = NA,color = NA),
plot.title = element_text(hjust = 0.5))
P2 <- ggplot(dsamp,aes(carat, price, fill = cut))+
geom_point(shape = 21, color = 'black', size = 3)+
scale_fill_manual(name = '',
values = c('#a6cee3','#1f78b4','#b2df8a','#33a02c','#fb9a99'))+
labs(title = 'bw theme',x='',y='')+
theme_bw()+
theme(legend.position = c(.15,.8),
legend.background = element_rect(fill = NA,color = NA),
plot.title = element_text(hjust = 0.5))
主题选择
5.2 图例位置、大小应与插图搭配-theme()函数
set.seed(2019)
id <- 1:10
df <- tibble(x = rep(id,2),
y = c(id*1.8+rnorm(10,0,1),
x=id*3+rnorm(10,0,1)),
group = rep(c('Group A','Group B'),each = 10))
p1 <- ggplot(df, aes(x,y,fill = group,group = group))+
geom_line()+
geom_point(shape = 21, color = 'gray40', size = 3)+
theme_classic()
p2 <- ggplot(df, aes(x,y,fill = group,group = group))+
geom_line()+
geom_point(shape = 21, color = 'gray40', size = 3)+
theme_classic()+
theme(legend.position = c(.15,.85))图例位置
图例位置
5.3多面板图facet_wrap(~clarity,ncol = 3)分三列 面板
5.4元素大小
散点图geom_point()函数中size参数调整
柱状图geom_bar()函数中width参数调整
scale_size_continuous()函数调整size属性
6.细节修饰-标度函数
7.图片拼接与导出
7.1对齐与拼接
plot_grid()函数拼接，align = c('v','h')参数纵 横向对齐
patchwork包-支持多层嵌套拼图，直接+相连
7.2导出-'Cairo'包，export包(导出PPT)
CairoPDF('file_name.pdf',height = 6,width = 6)
graph2ppt(object)原创声明：本文系作者授权腾讯云开发者社区发表，未经许可，不得转载。
如有侵权，请联系 cloudcommunity@tencent.com 删除。
原创声明：本文系作者授权腾讯云开发者社区发表，未经许可，不得转载。
如有侵权，请联系 cloudcommunity@tencent.com 删除。
评论
登录后参与评论
推荐阅读
腾讯云开发者
