简介

在查阅文献的过程中，看到了几幅非常不错的出版图，今天就跟着小编一起学习下，他们是怎么使用 R 绘制出来的。

今天主要介绍第一幅图（A)，初步观察来看，改图是由两张照片合并而成，并且在上面加上了箭头、圆圈，来说明作者想表达的问题。

后面几幅图会一一介绍，读者在学习过程中，可以将内部学到的知识点应用到自己的图形绘制中。

那我们来看看，他是怎么实现这个功能的吧，对应代码可在 GitHub - marco-meer/scifig_plot_examples_R: Scientific publication figure plotting examples with R[1] 可以找到。

主要知识点

学会如何导入图形，并将其并排展示；
学会设置自定义主题，简化代码，统一主题，方便绘制其他图形使用；
学会使用 ggplot2 包内置参数添加文字已经其他其他修饰图标。

绘图

加载包

首先加载一些需要使用到的包。

library(ggplot2) # Grammar of graphics
library(cowplot) # Arranging multiple plots into a grid
library(png)     # Load JPEG, PNG and TIFF format
library(scales)  # Generic plot scaling methods
library(viridis) # Default color maps from 'matplotlib'
library(grid)    # A rewrite of the graphics layout capabilities
library(magick)  # graphics and image processing
library(rsvg)    # Render svg image into a high quality bitmap
library(ggforce) # Collection of additional ggplot stats + geoms

设置主题

接下来，为了方便起见，作者在绘图前设置好了主题，并将该函数命名为 my_theme。

这个主题并没有在第一幅图中使用，但是在后面几幅图中都会使用，这里先将其展示下。使用方式会在下一篇推文中进行介绍。

手动修改大部分面板，具体可以参考本篇文章[2]。或者观看我在 B 站发布的《R 语言可视化教程》，里面也有一些简单主题设置介绍。

# 全局字体大小
base_size = 12

# 手动修改大部分面板
# documentation: https://ggplot2.tidyverse.org/reference/theme.html
my_theme <-  function() {
  theme(
    aspect.ratio = 1,
    axis.line =element_line(colour = "black"),

    # shift axis text closer to axis bc ticks are facing inwards
    axis.text.x = element_text(size = base_size*0.8, color = "black",
                               lineheight = 0.9,
                               margin=unit(c(0.3,0.3,0.3,0.3), "cm")),
    axis.text.y = element_text(size = base_size*0.8, color = "black",
                               lineheight = 0.9,
                               margin=unit(c(0.3,0.3,0.3,0.3), "cm")),

    axis.ticks = element_line(color = "black", size  =  0.2),
    axis.title.x = element_text(size = base_size,
                                color = "black",
                                margin = margin(t = -5)),
    # t (top), r (right), b (bottom), l (left)
    axis.title.y = element_text(size = base_size,
                                color = "black", angle = 90,
                                margin = margin(r = -5)),
    axis.ticks.length = unit(-0.3, "lines"),
    legend.background = element_rect(color = NA,
                                     fill = NA),
    legend.key = element_rect(color = "black",
                              fill = "white"),
    legend.key.size = unit(0.5, "lines"),
    legend.key.height = NULL,
    legend.key.width = NULL,
    legend.text = element_text(size = 0.6*base_size,
                               color = "black"),
    legend.title = element_text(size = 0.6*base_size,
                                face = "bold",
                                hjust = 0,
                                color = "black"),
    legend.text.align = NULL,
    legend.title.align = NULL,
    legend.direction = "vertical",
    legend.box = NULL,
    panel.background = element_rect(fill = "white",
                                    color  =  NA),
    panel.grid.major = element_blank(),
    panel.grid.minor = element_blank(),
    plot.title = element_text(size = base_size,
                              color = "black"),
  )
}

绘图步骤详解

由于代码复杂，知识点较多，为了读者更好理解代码逻辑和含义，小编将其分布讲解。最后再将完整代码放到本节末。

导入图片

首先使用 magick 包中的 image_read() 导入两幅图，并通过image_flip()进行转化。

img1 <- magick::image_flip(magick::image_read("./image1.jpg"))
img2 <-  magick::image_flip(magick::image_read("./image2.png"))

接下来，将两幅图并行合并，放置到一幅图中。这里的代码，小编也是第一次见。通过 grid 包中的 grid.raster() 设置光栅（raster）对象，并使用 annotation_custom()设置摆放位置。这时候得到的结果是

ggplot() +
  annotation_custom(rasterGrob(image =  img1,
                               x=0.27,
                               y=0.49,
                               width = unit(0.45,"npc"),
                               height = unit(0.87,"npc")),
                    -Inf, Inf, -Inf, Inf) +
  annotation_custom(rasterGrob(image = img2,
                               x=0.73,
                               y=0.49,
                               width = unit(0.45,"npc"),
                               height = unit(0.87,"npc")),
                    -Inf, Inf, -Inf, Inf)

其他修饰图标

加入修饰图标，来说明问题。主要使用 geom_ellipse() 构建椭圆形，geom_segment() 增加线段（箭头设置，在内部参数 arrow 中）。

geom_ellipse(aes(x0 = 0.25,
                 y0 = 0.3,
                 a = 0.1,
                 b = 0.04,
                 angle = 0),
              color="yellow",
              size=1) +
  scale_x_continuous(limits = c(0,1))+ # 设置 x 轴坐标范围
  scale_y_continuous(limits=c(0,1)) +
  geom_segment(aes(x=0.15,
                   xend=0.2,
                   y=0.75,
                   yend=0.7),
               arrow = arrow(length=unit(0.30,"cm"),
                             ends="last",
                             type = "closed"),
               size = 1,
               color="white") +
  geom_segment(aes(x=0.3,
                   xend=0.9,
                   y=0.7,
                   yend=0.7),
               arrow = arrow(length=unit(0.30,"cm"),
                             ends="both",
                             type = "closed"),
               size = 1,
               color="red")

添加文字

使用 annotate() 添加文字（"text"），使用 geom_segment() 添加线段（右下角白色的线段），这里没有设置箭头。

annotate("text", x = 0.25, y = 0.5, label = "PNG",color="white") +
  annotate("text", x = 0.75, y = 0.5, label = "JPEG",color="white") +
  annotate("text", x = 0.25, y = 1, label = "image 1",color="black") +
  annotate("text", x = 0.75, y = 1, label = "image 2",color="black") +
  annotate("text", x = 0.39, y = 0.07, label = "20~mu*m",color="white",parse=T) +
  annotate("text", x = 0.89, y = 0.07, label = "20~mu*m",color="white",parse=T) +
  geom_segment(aes(x=0.33,xend=0.45,y=0.03,yend=0.03), size = 2,color="white") +
  geom_segment(aes(x=0.83,xend=0.95,y=0.03,yend=0.03),size = 2,color="white")

这时候得到的结果为：

微调主题

去除主题，并修改图形边界。

  theme_void() +# blank plot w/o axes etc.
  theme(plot.margin = unit(c(-0,0,1,0), "cm"),
        aspect.ratio = 1)

完整代码

library(ggplot2) # Grammar of graphics
library(cowplot) # Arranging multiple plots into a grid
library(png)     # Load JPEG, PNG and TIFF format
library(scales)  # Generic plot scaling methods
library(viridis) # Default color maps from 'matplotlib'
library(grid)    # A rewrite of the graphics layout capabilities
library(magick)  # graphics and image processing
library(rsvg)    # Render svg image into a high quality bitmap
library(ggforce) # Collection of additional ggplot stats + geoms

# global font size
base_size = 12

# Manual theme for most panels
# documentation: https://ggplot2.tidyverse.org/reference/theme.html
my_theme <-  function() {
  theme(
    aspect.ratio = 1,
    axis.line =element_line(colour = "black"),

    # shift axis text closer to axis bc ticks are facing inwards
    axis.text.x = element_text(size = base_size*0.8, color = "black",
                               lineheight = 0.9,
                               margin=unit(c(0.3,0.3,0.3,0.3), "cm")),
    axis.text.y = element_text(size = base_size*0.8, color = "black",
                               lineheight = 0.9,
                               margin=unit(c(0.3,0.3,0.3,0.3), "cm")),

    axis.ticks = element_line(color = "black", size  =  0.2),
    axis.title.x = element_text(size = base_size,
                                color = "black",
                                margin = margin(t = -5)),
    # t (top), r (right), b (bottom), l (left)
    axis.title.y = element_text(size = base_size,
                                color = "black", angle = 90,
                                margin = margin(r = -5)),
    axis.ticks.length = unit(-0.3, "lines"),
    legend.background = element_rect(color = NA,
                                     fill = NA),
    legend.key = element_rect(color = "black",
                              fill = "white"),
    legend.key.size = unit(0.5, "lines"),
    legend.key.height =NULL,
    legend.key.width = NULL,
    legend.text = element_text(size = 0.6*base_size,
                               color = "black"),
    legend.title = element_text(size = 0.6*base_size,
                                face = "bold",
                                hjust = 0,
                                color = "black"),
    legend.text.align = NULL,
    legend.title.align = NULL,
    legend.direction = "vertical",
    legend.box = NULL,
    panel.background = element_rect(fill = "white",
                                    color  =  NA),
    panel.grid.major = element_blank(),
    panel.grid.minor = element_blank(),
    plot.title = element_text(size = base_size,
                              color = "black"),
  )


}

# Panel A ----

img1 <- magick::image_flip(magick::image_read("./image1.jpg"))
img2 <-  magick::image_flip(magick::image_read("./image2.png"))

panel_A <- ggplot() +
  annotation_custom(rasterGrob(image =  img1,
                               x=0.27,
                               y=0.49,
                               width = unit(0.45,"npc"),
                               height = unit(0.87,"npc")),
                    -Inf, Inf, -Inf, Inf) +
  annotation_custom(rasterGrob(image = img2,
                               x=0.73,
                               y=0.49,
                               width = unit(0.45,"npc"),
                               height = unit(0.87,"npc")),
                    -Inf, Inf, -Inf, Inf) +

  geom_ellipse(aes(x0 = 0.25,
                            y0 = 0.3,
                            a = 0.1,
                            b = 0.04,
                            angle = 0),
                        color="yellow",
                        size=1)+
  scale_x_continuous(limits = c(0,1))+
  scale_y_continuous(limits=c(0,1)) +
  geom_segment(aes(x=0.15,
                   xend=0.2,
                   y=0.75,
                   yend=0.7),
               arrow = arrow(length=unit(0.30,"cm"),
                             ends="last",
                             type = "closed"),
               size = 1,
               color="white") +
  geom_segment(aes(x=0.3,
                   xend=0.9,
                   y=0.7,
                   yend=0.7),
               arrow = arrow(length=unit(0.30,"cm"),
                             ends="both",
                             type = "closed"),
               size = 1,
               color="red") +

  annotate("text", x = 0.25, y = 0.5, label = "PNG",color="white") +
  annotate("text", x = 0.75, y = 0.5, label = "JPEG",color="white") +
  annotate("text", x = 0.25, y = 1, label = "image 1",color="black") +
  annotate("text", x = 0.75, y = 1, label = "image 2",color="black") +
  annotate("text", x = 0.39, y = 0.07, label = "20~mu*m",color="white",parse=T) +
  annotate("text", x = 0.89, y = 0.07, label = "20~mu*m",color="white",parse=T) +
  geom_segment(aes(x=0.33,xend=0.45,y=0.03,yend=0.03), size = 2,color="white") +
  geom_segment(aes(x=0.83,xend=0.95,y=0.03,yend=0.03),size = 2,color="white")  +
  theme_void() +# blank plot w/o axes etc.
  theme(plot.margin = unit(c(-0,0,1,0), "cm"),
        aspect.ratio = 1)

panel_A
