PHP 服务实现性能剖析、跟踪和可观察性最佳实践

composer require openzipkin/zipkin

function create_tracing($endpointName, $ipv4)
{
    $endpoint = Endpoint::create($endpointName, $ipv4, null, 2555);
    /* Do not copy this logger into production.
     * Read https://github.com/Seldaek/monolog/blob/master/doc/01-usage.md#log-levels
     */
    $logger = new \Monolog\Logger('log');
    $logger->pushHandler(new \Monolog\Handler\ErrorLogHandler());
    $reporter = new Zipkin\Reporters\Http(\Zipkin\Reporters\Http\CurlFactory::create());
    $sampler = BinarySampler::createAsAlwaysSample();
    $tracing = TracingBuilder::create()
        ->havingLocalEndpoint($endpoint)
        ->havingSampler($sampler)
        ->havingReporter($reporter)
        ->build();
    return $tracing;
}

$rootSpan = $tracer->newTrace();
$rootSpan->setName('encode');
$rootSpan->start();

try {
  doSomethingExpensive();
} finally {
  $rootSpan->finish();
}

$span = $tracer->newChild($parentSpan->getContext());
$span->setName('encode');
$span->start();
try {
  doSomethingExpensive();
} finally {
  $span->finish();
}

   Client Span                                                Server Span
┌──────────────────┐                                       ┌──────────────────┐
│                  │                                       │                  │
│   TraceContext   │           Http Request Headers        │   TraceContext   │
│ ┌──────────────┐ │          ┌───────────────────┐        │ ┌──────────────┐ │
│ │ TraceId      │ │          │ X-B3-TraceId      │        │ │ TraceId      │ │
│ │              │ │          │                   │        │ │              │ │
│ │ ParentSpanId │ │ Inject   │ X-B3-ParentSpanId │Extract │ │ ParentSpanId │ │
│ │              ├─┼─────────>│                   ├────────┼>│              │ │
│ │ SpanId       │ │          │ X-B3-SpanId       │        │ │ SpanId       │ │
│ │              │ │          │                   │        │ │              │ │
│ │ Sampled      │ │          │ X-B3-Sampled      │        │ │ Sampled      │ │
│ └──────────────┘ │          └───────────────────┘        │ └──────────────┘ │
│                  │                                       │                  │
└──────────────────┘                                       └──────────────────┘

composer require openzipkin/zipkin

<?php
/**
 * @desc 全链路监控中间件
 * @author Tinywan(ShaoBo Wan)
 * @date 2021/12/6 14:06
 */
declare(strict_types=1);

namespace app\middleware;

use Monolog\Handler\ErrorLogHandler;
use Monolog\Logger;
use support\Log;
use think\facade\Db;
use Webman\MiddlewareInterface;
use Webman\Http\Response;
use Webman\Http\Request;
use Zipkin\Reporters\Http;
use Zipkin\TracingBuilder;
use Zipkin\Samplers\BinarySampler;
use Zipkin\Endpoint;
use Workerman\Timer;
use const Zipkin\Tags\SQL_QUERY;

class ArmsMiddleware implements MiddlewareInterface
{
    /**
     * @desc: 方法描述
     * @param Request $request
     * @param callable $next
     * @return Response
     * @author Tinywan(ShaoBo Wan)
     */
    public function process(Request $request, callable $next) : Response
    {
        static $tracing = null, $tracer = null;
        if (!$tracing) {
            $endpoint = Endpoint::create('开源技术小栈', $request->getRealIp(), null, 2555);
            $logger = new Logger('log');
            $logger->pushHandler(new ErrorLogHandler());
            $reporter = new Http(['endpoint_url' => config('security')['endpoint_url']]);
            $sampler = BinarySampler::createAsAlwaysSample();
            $tracing = TracingBuilder::create()
                ->havingLocalEndpoint($endpoint)
                ->havingSampler($sampler)
                ->havingReporter($reporter)
                ->build();
            $tracer = $tracing->getTracer();
            // 55秒上报一次，尽量将上报对业务的影响减少到最低
            Timer::add(55, function () use ($tracer) {
                $tracer->flush();
            });
            register_shutdown_function(function () use ($tracer) {
                $tracer->flush();
            });
        }

        $rootSpan = $tracer->newTrace();
        $rootSpan->setName($request->controller."::".$request->action);
        $rootSpan->start();
        $request->rootSpan = $rootSpan;
        $request->tracer = $tracer;
        $result = $next($request);

        // 统计sql（日志在内存）
        if (class_exists(Db::class)) {
            $logs = Db::getDbLog(true);
            if (!empty($logs['sql'])) {
                foreach ($logs['sql'] as $sql) {
                    $sqlSpan = $tracer->newChild($rootSpan->getContext());
                    $sqlSpan->setName(SQL_QUERY);
                    $sqlSpan->start();
                    $sqlSpan->tag('db.statement', $sql);
                    $sqlSpan->finish();
                }
            }
        }

        $rootSpan->finish();

        return $result;
    }
}

return [
    '' => [
        \app\middleware\ArmsMiddleware::class,
    ],
    ...
];
