算法复现 | 使用KMEAN算法对印度洋台风路径进行分类

import pandas as pd
import numpy as np
import glob
import cartopy
import cartopy.crs as ccrs
import cartopy.feature as cfeat
from cartopy.mpl.ticker import LongitudeFormatter,LatitudeFormatter
from cartopy.io.shapereader import Reader, natural_earth
import matplotlib.pyplot as plt
import matplotlib.ticker as mticker
from matplotlib.image import imread
import shapely.geometry as sgeom
import cartopy.io.shapereader as shpreader
import matplotlib.lines as mlines
from sklearn.cluster import KMeans

files = glob.glob(f'/home/mw/input/india_typhoon6005/indian/*/*')
df_list = []
i = 1
for f in files[:]:
    lines = open(f, 'r').readlines()
    max_line = max(lines, key=len)
    max_line_num = len(max_line.split(','))
    df = pd.read_csv(f, sep=',', header=None, error_bad_lines=False, names=range(max_line_num))

    df['count'] = i
    df = df[df.columns.drop('count').insert(0, 'count')]
    df = df.loc[:, :8].drop(columns=[0, 3, 4, 5])

    df.columns.values[:6] = ['count', 'num', 'time', 'lat', 'lon', 'speed']

    df['time'] = pd.to_datetime(df['time'], format='%Y%m%d%H')
    df['year'] = df['time'][0].year
    df['month'] = df['time'][0].month
    df['day'] = df['time'][0].day

    df['y'] = df['lat'].apply(lambda x: float(x[:-1]) / 10)
    df['x'] = df['lon'].apply(lambda x: float(x[:-1]) / 10)
    df['speed'] = df['speed'] * 0.514
    df['w'] = df['speed'] ** 0.5

    if (df['time'].iloc[-1] - df['time'].iloc[0]).days >= 1 and df['speed'].max() >= 17.2:
        df_list.append(df)
        i = i + 1

data = pd.concat(df_list)
data['w'] = data['w'].replace(0, np.nan)
data.dropna(axis='rows', how='any', inplace=True)
data.drop(columns=['lat', 'lon'], inplace=True)

data

tc = data

tc['wx'] = tc['w'] * tc['x']
tc['wy'] = tc['w'] * tc['y']
tc

tc['wx_sum'] = tc.groupby(['count'])['wx'].transform('sum')
tc['wy_sum'] = tc.groupby(['count'])['wy'].transform('sum')
tc['w_sum'] = tc.groupby(['count'])['w'].transform('sum')
tc['x_mean'] = tc['wx_sum'] / tc['w_sum']
tc['y_mean'] = tc['wy_sum'] / tc['w_sum']
tc['x_var'] = tc['wx_sum'] / tc['w_sum']
tc['x_var'] = (tc['x'] - tc['x_mean']) ** 2 * tc['w']
tc['y_var'] = (tc['y'] - tc['y_mean']) ** 2 * tc['w']
tc['xy_var'] = (tc['y'] - tc['y_mean']) * (tc['x'] - tc['x_mean']) * tc['w']
tc['x_var_sum'] = tc.groupby(['count'])['x_var'].transform('sum')
tc['y_var_sum'] = tc.groupby(['count'])['y_var'].transform('sum')
tc['xy_var_sum'] = tc.groupby(['count'])['xy_var'].transform('sum')
tc['x_var_mean'] = tc['x_var_sum'] / tc['w_sum']
tc['y_var_mean'] = tc['y_var_sum'] / tc['w_sum']
tc['xy_var_mean'] = tc['xy_var_sum'] / tc['w_sum']
tc

tc_group = tc.groupby('count').mean()[['x_mean', 'y_mean', 'x_var_mean', 'y_var_mean', 'xy_var_mean']]
tc_group

kmeans = KMeans(n_clusters=4, random_state=0)
kmeans.fit(tc_group)

KMeans(n_clusters=4, random_state=0)

print(kmeans.labels_)

[2 2 0 0 2 3 0 2 3 0 3 2 0 2 2 2 2 2 2 3 3 2 2 3 2 2 1 2 3 2 2 2 2 2 3 2 2
 3 2 2 0 0 2 3 2 2 2 2 2 3 2 2 0 2 2 0 2 3 2 2 0 2 2 1 2 0 0 1 2 2 3 2 0 0
 3 2 2 2 3 2 2 1 2 2 2 2 2 0 0 2 3 3 3 3 2 2 3 2 3 2 2 2 2 2 1 2 3 3 3 3 2
 2 2 2 2 3 2 3 2 3 3 0 2 2 2 2 2 2 0 2 2 3 2 2 2 3 0 2 3 2 2 2 2 2 2 0 2 2
 2 3 2 2 3 3 2 0 3 2 3 3 0 2 3 2 2 3 2 2 0 2 0 2 2 3 2 3 2 3 2 3 3 3 2 3 2
 2 1 2 2 3 2 3 3 2 2 3 2 0 2 2 3 3 3 3 3 3 2 3 3 2 2]

print(kmeans.cluster_centers_)

[[ 73.8071703   11.65878343  39.74780613   7.47642322 -11.02116106]
 [ 78.00734193  10.96868728 112.7133901    4.30306716  -2.60074766]
 [ 86.76754499  14.82524246   6.22982994   7.68770382  -0.54250094]
 [ 63.71074018  15.72378535   8.58366153   3.80791174  -1.27377464]]

tc_group['label'] = kmeans.labels_ + 1

tc_group['label'].value_counts()

3    121
4     59
1     25
2      6
Name: label, dtype: int64

tc_group

tc.set_index(['count'], inplace=True)
tc['label'] = tc_group['label']

tc

# 分级设色
def get_color(w):
    if w <= 13.8:
        color='#FFFF00'
    elif 13.9<= w <= 17.1:
        color='#6495ED'
    elif 17.2 <= w <= 24.4:
        color='#3CB371'
    elif 24.5<= w <= 32.6:
        color='#FFA500'
    elif 32.7 <= w <= 61.3:
        color='#FF00FF'
    else:
        color='#DC143C'
    return color

def create_map(title, extent):
    fig = plt.figure(figsize=(12, 8), dpi=400)
    ax = fig.add_subplot(1, 1, 1, projection=ccrs.PlateCarree())
    ax.imshow(
        imread('/home/mw/input/natural_earth8967/NE1_50M_SR_W.tif'),
        origin='upper',
        transform=ccrs.PlateCarree(),
        extent=[-180, 180, -90, 90]
    )
    ax.set_extent(extent,crs=ccrs.PlateCarree())

    gl = ax.gridlines(draw_labels=False, linewidth=1, color='k', alpha=0.5, linestyle='--')
    gl.top_labels = gl.right_labels = False
    ax.set_xticks(np.arange(extent[0], extent[1]+5, 5))
    ax.set_yticks(np.arange(extent[2], extent[3]+5, 5))
    ax.xaxis.set_major_formatter(LongitudeFormatter())
    ax.xaxis.set_minor_locator(plt.MultipleLocator(1))
    ax.yaxis.set_major_formatter(LatitudeFormatter())
    ax.yaxis.set_minor_locator(plt.MultipleLocator(1))
    ax.tick_params(axis='both', labelsize=10, direction='out')

    province = shpreader.Reader('/home/mw/input/cn_shp3641/Province_9.shp')
    ax.add_geometries(province.geometries(), crs=ccrs.PlateCarree(), linewidths=0.1,edgecolor='k',facecolor='none')

    a = mlines.Line2D([],[],color='#FFFF00',marker='o',markersize=7, label='D',ls='')
    b = mlines.Line2D([],[],color='#6495ED', marker='o',markersize=7, label='DD',ls='')
    c = mlines.Line2D([],[],color='#3CB371', marker='o',markersize=7, label='CS',ls='')
    d = mlines.Line2D([],[],color='#FFA500', marker='o',markersize=7, label='SCS',ls='')
    e = mlines.Line2D([],[],color='#FF00FF', marker='o',markersize=7, label='VSCS',ls='')
    f = mlines.Line2D([],[],color='#DC143C', marker='o',markersize=7, label='SuperCS',ls='')
    ax.legend(handles=[a,b,c,d,e,f], numpoints=1, handletextpad=0, loc='upper left', shadow=True)
    plt.title(f'{title} Typhoon Track', fontsize=15)
    return ax

for label in tc_group['label'].value_counts().index[:]:
    tc_number = tc_group["label"].value_counts()[label]
    print(f'label:{label}, tc number:{tc_number}')

    one_type = tc[tc['label']==label].reset_index()
    ax = create_map(f'Type {label}', [40, 110, 0, 30])

    for num in one_type['count'].value_counts().index:
        df = one_type[one_type['count']==num]
        for i in range(len(df))[:1]:
            ax.scatter(list(df['x'])[i], list(df['y'])[i], marker='o', s=10, color='k')

        for i in range(len(df)-1):
            pointA = list(df['x'])[i],list(df['y'])[i]
            pointB = list(df['x'])[i+1],list(df['y'])[i+1]
            ax.add_geometries([sgeom.LineString([pointA, pointB])], color=get_color(list(df['speed'])[i+1]),crs=ccrs.PlateCarree(), linewidth=2)
    plt.savefig(f'track_type{label}_typhoon.png')

label:3, tc number:121
label:4, tc number:59
label:1, tc number:25
label:2, tc number:6
