[分享] SDK 2018.3烧写没有DDR的单板的Flash

cmd /C program_flash -f \
C:\prj\mzed_ddrless.sdk\Application\bootimage\BOOT.bin \
-offset 0 -flash_type qspi_single -fsbl \
C:\prj\mzed_ddrless.sdk\fsbl_ddrless_not_xip\Debug\fsbl_ddrless_not_xip.elf \
-blank_check -verify -cable type xilinx_tcf url TCP:127.0.0.1:3121

****** Xilinx Program Flash
****** Program Flash v2018.2 (64-bit)
  **** SW Build 2258646 on Thu Jun 14 20:03:12 MDT 2018
    ** Copyright 1986-2018 Xilinx, Inc. All Rights Reserved.


Connected to hw_server @ TCP:127.0.0.1:3121
Available targets and devices:
Target 0 : jsn1
Target 1 : jsn-DLC10-000016c46e9801
	Device 0: jsn-DLC10-000016c46e9801-4ba00477-0

Retrieving Flash info...

Initialization done, programming the memory
===== mrd->addr=0xF800025C, data=0x00000000 =====
BOOT_MODE REG = 0x00000000
Downloading FSBL...
Running FSBL...
Finished running FSBL.
===== mrd->addr=0xF8000110, data=0x000FA220 =====
READ: ARM_PLL_CFG (0xF8000110) = 0x000FA220
===== mrd->addr=0xF8000100, data=0x00028008 =====
READ: ARM_PLL_CTRL (0xF8000100) = 0x00028008
===== mrd->addr=0xF8000120, data=0x1F000200 =====
READ: ARM_CLK_CTRL (0xF8000120) = 0x1F000200
===== mrd->addr=0xF8000118, data=0x001452C0 =====
READ: IO_PLL_CFG (0xF8000118) = 0x001452C0
===== mrd->addr=0xF8000108, data=0x0001E008 =====
READ: IO_PLL_CTRL (0xF8000108) = 0x0001E008
Info:  Remapping 256KB of on-chip-memory RAM memory to 0xFFFC0000.
===== mrd->addr=0xF8000008, data=0x00000000 =====
===== mwr->addr=0xF8000008, data=0x0000DF0D =====
MASKWRITE: addr=0xF8000008, mask=0x0000FFFF, newData=0x0000DF0D
===== mwr->addr=0xF8000910, data=0x000001FF =====
===== mrd->addr=0xF8000004, data=0x00000000 =====
===== mwr->addr=0xF8000004, data=0x0000767B =====
MASKWRITE: addr=0xF8000004, mask=0x0000FFFF, newData=0x0000767B
Problem in running uboot
Flash programming initialization failed.

ERROR: Flash Operation Failed

#undef XPAR_PS7_DDR_0_S_AXI_BASEADDR

  // DDR init
  //ret = ps7_config (ps7_ddr_init_data);
  //if (ret != PS7_INIT_SUCCESS) return ret;

int main(void)
{
	u32 BootModeRegister = 0;
	u32 HandoffAddress = 0;
	u32 Status = XST_SUCCESS;
	u32 RegVal;
	/*
	 * PCW initialization for MIO,PLL,CLK and DDR
	 */
	Status = ps7_init();
	if (Status != FSBL_PS7_INIT_SUCCESS) {
		fsbl_printf(DEBUG_GENERAL,"PS7_INIT_FAIL : %s\r\n",
						getPS7MessageInfo(Status));
		OutputStatus(PS7_INIT_FAIL);
		/*
		 * Calling FsblHookFallback instead of Fallback
		 * since, devcfg driver is not yet initialized
		 */
		FsblHookFallback();
	}

	/*
	 * Unlock SLCR for SLCR register write
	 */
	SlcrUnlock();

	/* If Performance measurement is required
	 * then read the Global Timer value , Please note that the
	 * time taken for mio, clock and ddr initialisation
	 * done in the ps7_init function is not accounted in the FSBL
	 *
	 */
#ifdef FSBL_PERF
	XTime tCur = 0;
	FsblGetGlobalTime(&tCur);
#endif

	/*
	 * Flush the Caches
	 */
	Xil_DCacheFlush();

	/*
	 * Disable Data Cache
	 */
	Xil_DCacheDisable();

	/*
	 * Register the Exception handlers
	 */
	RegisterHandlers();

	/*
	 * Print the FSBL Banner
	 */
	fsbl_printf(DEBUG_GENERAL,"\n\rXilinx First Stage Boot Loader \n\r");
	fsbl_printf(DEBUG_GENERAL,"Release %d.%d	%s-%s\r\n",
			SDK_RELEASE_YEAR, SDK_RELEASE_QUARTER,
			__DATE__,__TIME__);

#ifdef XPAR_PS7_DDR_0_S_AXI_BASEADDR

    /*
     * DDR Read/write test
     */
	Status = DDRInitCheck();
	if (Status == XST_FAILURE) {
		fsbl_printf(DEBUG_GENERAL,"DDR_INIT_FAIL \r\n");
		/* Error Handling here */
		OutputStatus(DDR_INIT_FAIL);
		/*
		 * Calling FsblHookFallback instead of Fallback
		 * since, devcfg driver is not yet initialized
		 */
		FsblHookFallback();
	}

#endif  // XPAR_PS7_DDR_0_S_AXI_BASEADDR

	/*
	 * PCAP initialization
	 */
	Status = InitPcap();
	if (Status == XST_FAILURE) {
		fsbl_printf(DEBUG_GENERAL,"PCAP_INIT_FAIL \n\r");
		OutputStatus(PCAP_INIT_FAIL);
		/*
		 * Calling FsblHookFallback instead of Fallback
		 * since, devcfg driver is not yet initialized
		 */
		FsblHookFallback();
	}

	fsbl_printf(DEBUG_INFO,"Devcfg driver initialized \r\n");

	/*
	 * Get the Silicon Version
	 */
	GetSiliconVersion();

#ifdef XPAR_XWDTPS_0_BASEADDR
	/*
	 * Check if WDT Reset has occurred or not
	 */
	CheckWDTReset();

	/*
	 * Initialize the Watchdog Timer so that it is ready to use
	 */
	Status = InitWatchDog();
	if (Status == XST_FAILURE) {
		fsbl_printf(DEBUG_GENERAL,"WATCHDOG_INIT_FAIL \n\r");
		OutputStatus(WDT_INIT_FAIL);
		FsblFallback();
	}
	fsbl_printf(DEBUG_INFO,"Watchdog driver initialized \r\n");
#endif

	/*
	 * Get PCAP controller settings
	 */
	PcapCtrlRegVal = XDcfg_GetControlRegister(DcfgInstPtr);

	/*
	 * Check for AES source key
	 */
	if (PcapCtrlRegVal & XDCFG_CTRL_PCFG_AES_FUSE_MASK) {
		/*
		 * For E-Fuse AES encryption Watch dog Timer disabled and
		 * User not allowed to do system reset
		 */
#ifdef	XPAR_XWDTPS_0_BASEADDR
		fsbl_printf(DEBUG_INFO,"Watchdog Timer Disabled\r\n");
		XWdtPs_Stop(&Watchdog);
#endif
		fsbl_printf(DEBUG_INFO,"User not allowed to do "
								"any system resets\r\n");
	}

	/*
	 * Store FSBL run state in Reboot Status Register
	 */
	MarkFSBLIn();

	/*
	 * Read bootmode register
	 */
	BootModeRegister = Xil_In32(BOOT_MODE_REG);
	BootModeRegister &= BOOT_MODES_MASK;

	/*
	 * QSPI BOOT MODE
	 */
#ifdef XPAR_PS7_QSPI_LINEAR_0_S_AXI_BASEADDR

#ifdef MMC_SUPPORT
	/*
	 * To support MMC boot
	 * QSPI boot mode detection ignored
	 */
	if (BootModeRegister == QSPI_MODE) {
		BootModeRegister = MMC_MODE;
	}
#endif

	if (BootModeRegister == QSPI_MODE) {
		fsbl_printf(DEBUG_GENERAL,"Boot mode is QSPI\n\r");
		InitQspi();
		MoveImage = QspiAccess;
		fsbl_printf(DEBUG_INFO,"QSPI Init Done \r\n");
	} else
#endif  // XPAR_PS7_QSPI_LINEAR_0_S_AXI_BASEADDR

	/*
	 * NAND BOOT MODE
	 */
#ifdef XPAR_PS7_NAND_0_BASEADDR
	if (BootModeRegister == NAND_FLASH_MODE) {
		/*
	 	* Boot ROM always initialize the nand at lower speed
	 	* This is the chance to put it to an optimum speed for your nand
	 	* device
	 	*/
		fsbl_printf(DEBUG_GENERAL,"Boot mode is NAND\n");

		Status = InitNand();
		if (Status != XST_SUCCESS) {
			fsbl_printf(DEBUG_GENERAL,"NAND_INIT_FAIL \r\n");
			/*
			 * Error Handling here
			 */
			OutputStatus(NAND_INIT_FAIL);
			FsblFallback();
		}
		MoveImage = NandAccess;
		fsbl_printf(DEBUG_INFO,"NAND Init Done \r\n");
	} else
#endif

	/*
	 * NOR BOOT MODE
	 */
	if (BootModeRegister == NOR_FLASH_MODE) {
		fsbl_printf(DEBUG_GENERAL,"Boot mode is NOR\n\r");
		/*
		 * Boot ROM always initialize the nor at lower speed
		 * This is the chance to put it to an optimum speed for your nor
		 * device
		 */
		InitNor();
		fsbl_printf(DEBUG_INFO,"NOR Init Done \r\n");
		MoveImage = NorAccess;
	} else

	/*
	 * SD BOOT MODE
	 */
#if defined(XPAR_PS7_SD_0_S_AXI_BASEADDR) || defined(XPAR_XSDPS_0_BASEADDR)

	if (BootModeRegister == SD_MODE) {
		fsbl_printf(DEBUG_GENERAL,"Boot mode is SD\r\n");

		/*
		 * SD initialization returns file open error or success
		 */
		Status = InitSD("BOOT.BIN");
		if (Status != XST_SUCCESS) {
			fsbl_printf(DEBUG_GENERAL,"SD_INIT_FAIL\r\n");
			OutputStatus(SD_INIT_FAIL);
			FsblFallback();
		}
		MoveImage = SDAccess;
		fsbl_printf(DEBUG_INFO,"SD Init Done \r\n");
	} else

	if (BootModeRegister == MMC_MODE) {
		fsbl_printf(DEBUG_GENERAL,"Booting Device is MMC\r\n");

		/*
		 * MMC initialization returns file open error or success
		 */
		Status = InitSD("BOOT.BIN");
		if (Status != XST_SUCCESS) {
			fsbl_printf(DEBUG_GENERAL,"MMC_INIT_FAIL\r\n");
			OutputStatus(SD_INIT_FAIL);
			FsblFallback();
		}
		MoveImage = SDAccess;
		fsbl_printf(DEBUG_INFO,"MMC Init Done \r\n");
	} else

#endif // defined(XPAR_PS7_SD_0_S_AXI_BASEADDR) || defined(XPAR_XSDPS_0_BASEADDR)

	/*
	 * JTAG  BOOT MODE
	 */
	if (BootModeRegister == JTAG_MODE) {
		fsbl_printf(DEBUG_GENERAL,"Boot mode is JTAG\r\n");

		RegVal = Xil_In32(XPS_DEV_CFG_APB_BASEADDR + XDCFG_INT_STS_OFFSET);
		/** If bitstream was loaded in jtag boot mode prior to running FSBL */
		if(RegVal & XDCFG_IXR_PCFG_DONE_MASK)
		{
#ifdef PS7_POST_CONFIG
		ps7_post_config();
		/*
		 * Unlock SLCR for SLCR register write
		 */
		SlcrUnlock();
#endif
		}
		/*
		 * Stop the Watchdog before JTAG handoff
		 */
#ifdef	XPAR_XWDTPS_0_BASEADDR
		XWdtPs_Stop(&Watchdog);
#endif
		/*
		 * Clear our mark in reboot status register
		 */
		ClearFSBLIn();

		/*
		 * SLCR lock
		 */
		SlcrLock();

		FsblHandoffJtagExit();
	} else {
		fsbl_printf(DEBUG_GENERAL,"ILLEGAL_BOOT_MODE \r\n");
		OutputStatus(ILLEGAL_BOOT_MODE);
		/*
		 * fallback starts, no return
		 */
		FsblFallback();
	}

	fsbl_printf(DEBUG_INFO,"Flash Base Address: 0x%08lx\r\n", FlashReadBaseAddress);

	/*
	 * Check for valid flash address
	 */
	if ((FlashReadBaseAddress != XPS_QSPI_LINEAR_BASEADDR) &&
			(FlashReadBaseAddress != XPS_NAND_BASEADDR) &&
			(FlashReadBaseAddress != XPS_NOR_BASEADDR) &&
			(FlashReadBaseAddress != XPS_SDIO0_BASEADDR)) {
		fsbl_printf(DEBUG_GENERAL,"INVALID_FLASH_ADDRESS \r\n");
		OutputStatus(INVALID_FLASH_ADDRESS);
		FsblFallback();
	}

	/*
	 * NOR and QSPI (parallel) are linear boot devices
	 */
	if ((FlashReadBaseAddress == XPS_NOR_BASEADDR)) {
		fsbl_printf(DEBUG_INFO, "Linear Boot Device\r\n");
		LinearBootDeviceFlag = 1;
	}

#ifdef	XPAR_XWDTPS_0_BASEADDR
	/*
	 * Prevent WDT reset
	 */
	XWdtPs_RestartWdt(&Watchdog);
#endif

#ifdef XPAR_PS7_DDR_0_S_AXI_BASEADDR
	/*
	 * This used only in case of E-Fuse encryption
	 * For image search
	 */
	SystemInitFlag = 1;

	/*
	 * Load boot image
	 */
	HandoffAddress = LoadBootImage();

	fsbl_printf(DEBUG_INFO,"Handoff Address: 0x%08lx\r\n",HandoffAddress);

	/*
	 * For Performance measurement
	 */
#ifdef FSBL_PERF
	XTime tEnd = 0;
	fsbl_printf(DEBUG_GENERAL,"Total Execution time is ");
	FsblMeasurePerfTime(tCur,tEnd);
#endif

	/*
	 * FSBL handoff to valid handoff address or
	 * exit in JTAG
	 */
	FsblHandoff(HandoffAddress);

#else
	OutputStatus(NO_DDR);
	FsblFallback();
#endif

	return Status;
}
