什么是RPC？

RPC全称Remote Procedure Call，即远程方法调用。它的表现形式是：

一个RPC请求从客户端初始化，并发送到远程服务器，执行远程服务器上的方法，远程服务器处理完成之后会把响应返回给客户端，然后客户端的应用程序继续执行。RPC的意义是实现一种调用执行远程方法的协议，让你在本地调用远程的方法，而对你来说这个调用是透明的，就向调用本地方法一样。通过RPC能解耦服务，当server需要对方法的实现进行修改时，client完全感知不到，不用做任何变更。

RPC的使用场景探讨

假设我们有两个数据中心，一个是US，一个是CN。我们的需求是产生的数据需要在US和CN之间进行同步。我们最初的方案是在US环境搭建服务，并在US数据库生成数据。然后再从US和CN的数据库层面进行数据的同步，US和CN背后通过V**的方式连接。这个方案是可行的，但是突然有一天V**坏了，不能再继续使用了，US和CN的数据不能同步了。我们怎么办？从对现有代码修改的成本角度来考虑，我们希望代码改动尽可能小，业务逻辑也能更多确保其正确性。我们的解决方案就是使用RPC，现在的问题是CN的数据没有办法同步，如果我们在CN环境使用相同的代码搭建CN服务，并直接连接CN的数据库。US的服务调用data层方法时候，能够同时调用US本地方法并RPC调用CN服务的data层方法，这样US和CN就会同时产生数据了，数据也就一致了，我们的需求也就解决了。

使用WebService实现RPC

创建一个web服务：RpcWebService.asmx，并部署在远程服务器上。这个服务会对来自客户端的调用，使用反射技术进行还原并调用本地的方法，并把本地的执行结果返回给客户端。在客户端里面需要做一个AOP代理层，从原来的只有调用本地方法变成调用远程方法。我们实现依赖了这些package：

Castle.Core: AOP类库

Newtonsoft.Json：序列化类库

客户端和服务器之间的关系，请看下图：

具体的代码改动：

1. 服务端添加WebService，处理客户端的请求。

2. 客户端添加AOP代理层。

3. 客户端代码修改成RPC的调用形式。

1. 服务端添加WebService，用来处理来自客户端的请求：

/// <summary>
/// Summary description for RpcWebService
/// </summary>
[WebService(Namespace = "http://tempuri.org/")]
[WebServiceBinding(ConformsTo = WsiProfiles.BasicProfile1_1)]
[System.ComponentModel.ToolboxItem(false)]
// To allow this Web Service to be called from script, using ASP.NET AJAX, uncomment the following line.
// [System.Web.Script.Services.ScriptService]
public class RpcWebService : System.Web.Services.WebService
{
    [WebMethod]
    public RpcServiceResult CallMethod(RpcServiceContext callContext)
    {
        RpcServiceResult rpcResult = new RpcServiceResult();

        try
        {
            // validate interface/class type
            Type type = Type.GetType(callContext.MethodInstanceTypeName);
            if (type == null)
            {
                throw new InvalidOperationException("Failed to locate type:" + callContext.MethodInstanceTypeName);
            }

            // extract arguments information
            var arguments = callContext.Arguments
                .Select(args =>
                    new
                    {
                        TypeName = args.TypeName,
                        Type = Type.GetType(args.TypeName),
                        Value = RpcJsonSerializer.Deserialize(args.Value, Type.GetType(args.TypeName))
                    });

            // validate arguments
            if (arguments.Any())
            {
                var badTypes = arguments.Where(t => t.Type == null).Select(t => t.TypeName);
                if (badTypes.Any())
                {
                    var msg = string.Join(",", badTypes.ToArray());
                    throw new InvalidOperationException("Failed to locate parameter types:" + badTypes);
                }
            }

            // validate method
            Type[] argsTypes = arguments.Select(t => t.Type).ToArray();
            MethodInfo method = type.GetMethod(callContext.MethodName, argsTypes);
            if (method == null)
            {
                throw new InvalidOperationException(string.Format("Failed to find method named:{0}, with parameters:{1}", callContext.MethodName, string.Join(",", argsTypes.Select(t => t.FullName).ToArray())));
            }

            // invoke method on local instance
            var instance = Activator.CreateInstance(type);
            if (instance == null)
            {
                throw new InvalidOperationException("Failed to create instance for type:" + type.AssemblyQualifiedName);
            }

            var methodResult = method.Invoke(instance, arguments.Select(args => args.Value).ToArray());
            rpcResult.Result = RpcJsonSerializer.Serialize(methodResult);
            rpcResult.ResultTypeName = method.ReturnType.FullName;
            rpcResult.ResultFormat = RpcResultFormat.Json;
            rpcResult.IsSuccess = true;
        }
        catch (Exception ex)
        {
            rpcResult.IsSuccess = false;
            rpcResult.ErrorMessage = ex.Message;
        }

        return rpcResult;
    }
}

public class RpcServiceResult
{
    public bool IsSuccess { get; set; }

    /// <summary>
    /// Serialized result of the method call.
    /// </summary>
    public string Result { get; set; }

    /// <summary>
    /// Name of the type of method return value.
    /// </summary>
    public string ResultTypeName { get; set; }

    /// <summary>
    /// In which the result is formatted.
    /// </summary>
    public RpcResultFormat ResultFormat { get; set; }

    public string ErrorMessage { get; set; }
}

public class RpcServiceContext
{
    /// <summary>
    /// Name of the type where the method is obtained.
    /// </summary>
    public string MethodInstanceTypeName { get; set; }

    /// <summary>
    /// Name of the method
    /// </summary>
    public string MethodName { get; set; }

    /// <summary>
    /// List of method argument
    /// </summary>
    public List<RpcServiceArgument> Arguments { get; set; }

    public RpcServiceContext()
    {
        this.Arguments = new List<RpcServiceArgument>();
    }
}

public class RpcServiceArgument
{
    /// <summary>
    /// Type of the argument
    /// </summary>
    public string TypeName { get; set; }

    /// <summary>
    /// Serialized value of argument
    /// </summary>
    public string Value { get; set; }
}

public enum RpcResultFormat
{
    /// <summary>
    /// Default & preferred
    /// </summary>
    Json
}

2. 客户端AOP代理层代码：

public static class ProxyFactory
{
    private static readonly ProxyGenerator _proxyGenerator = new ProxyGenerator();
    private static ConcurrentDictionary<string, object> _objectCache = new ConcurrentDictionary<string, object>(StringComparer.InvariantCultureIgnoreCase);

    public static T CreateProxy<T>(T target) where T : class
    {
        if (target == null)
        {
            throw new ArgumentNullException("target");
        }

        var proxy = _objectCache.GetOrAdd(typeof(T).AssemblyQualifiedName, (type) =>
        {
            var intercepter = new RemoteInvokeIntercepter();
            return _proxyGenerator.CreateInterfaceProxyWithTarget<T>(target, intercepter);
        }) as T;

        if (proxy == null)
        {
            throw new InvalidOperationException(string.Format("Failed to create proxy for Type: {0}", typeof(T).AssemblyQualifiedName));
        }

        return proxy;
    }
}

internal class RemoteInvokeIntercepter : IInterceptor
{
    private const int MAX_SERVICE_RETRY = 3;

    public RemoteInvokeIntercepter()
    {
    }

    public void Intercept(IInvocation invocation)
    {
        RpcServiceContext callContext = new RpcServiceContext()
        {
            MethodInstanceTypeName = invocation.InvocationTarget.GetType().AssemblyQualifiedName,
            MethodName = invocation.Method.Name,
        };

        callContext.Arguments = invocation.MethodInvocationTarget
            .GetParameters()
            .OrderBy(p => p.Position)
            .Select(p => new RpcServiceArgument()
            {
                TypeName = invocation.Arguments[p.Position] != null
                            ? invocation.Arguments[p.Position].GetType().AssemblyQualifiedName
                            : p.ParameterType.AssemblyQualifiedName,
                Value = RpcJsonSerializer.Serialize(invocation.Arguments[p.Position])
            })
            .ToArray();

        RpcWebServiceSoapClient proxy = new RpcWebServiceSoapClient();

        var returnValueResponse = CallWebServiceWithRetry(proxy.CallMethod, callContext);
        if (!returnValueResponse.IsSuccess)
        {
            throw new InvalidOperationException(string.Format("Failed to call service:{0}, remote error:{1}. Check the error log in rpc service for more details.", invocation.Method.Name, returnValueResponse.ErrorMessage));
        }

        if (invocation.Method.ReturnType.FullName.Equals("System.Void"))
        {
            return;
        }

        if (returnValueResponse.ResultFormat == RpcResultFormat.Json)
        {
            invocation.ReturnValue = RpcJsonSerializer.Deserialize(returnValueResponse.Result, invocation.Method.ReturnType);
        }
        else
        {
            throw new NotSupportedException(string.Format("RpcResultFormat '{0}' is not supported", returnValueResponse.ResultFormat));
        }
    }

    private RpcServiceResult CallWebServiceWithRetry(Func<RpcServiceContext, RpcServiceResult> service, RpcServiceContext args, int retryCountdown = MAX_SERVICE_RETRY)
    {
        try
        {
            return service.Invoke(args);
        }
        catch (Exception exception)
        {
            if (retryCountdown > 0)
            {
                return CallWebServiceWithRetry(service, args, --retryCountdown);
            }
            else
            {
                throw new Exception(string.Format("Failed to call service:{0}, with {1} retries.", service.Method.Name, MAX_SERVICE_RETRY - retryCountdown), exception);
            }
        }
    }
}

public static class RpcJsonSerializer
{
    /// <summary>
    /// Specificly for circular references.
    /// </summary>
    private static readonly JsonSerializer _jsonSerializer = JsonSerializer.Create(
        new JsonSerializerSettings()
        {
            PreserveReferencesHandling = PreserveReferencesHandling.Objects
        }
    );
    public static string Serialize(object obj)
    {
        StringBuilder sb = new StringBuilder();
        using (StringWriter sw = new StringWriter(sb))
        {
            _jsonSerializer.Serialize(sw, obj);
        }
        return sb.ToString();
    }
    public static object Deserialize(string jsonText, Type objectType)
    {
        var reader = new JsonTextReader(new StringReader(jsonText));
        return _jsonSerializer.Deserialize(reader, objectType);
    }
}

3. 客户端代码修改成RPC的调用形式：

public class MySvc : IMySvc
{
    private static readonly IMySvc instance = new MySvc();
    public static IMySvc RPCInstance
    {
        get
        {
            return ProxyFactory.CreateProxy(instance);
        }
    }
    public string GetString(int num)
    {
        return num.ToString();
    }
}

public class HomeController : Controller
{
    private IMySvc _mySvc;
    public HomeController()
    {
        _mySvc = MySvc.RPCInstance;
    }
    public ActionResult Index()
    {
        ViewBag.Hello = _mySvc.GetString(123);
        return View();
    }
}
