sparksql源码系列 | 一文搞懂with one count distinct 执行原理

数据仓库践行者

发布于 2022-06-09 13:34:49

1.2K00

代码可运行

文章被收录于专栏：数据仓库践行者数据仓库践行者

运行总次数：0

代码可运行

今天下午的源码课，主要是对上两次课程中留的作业的讲解，除了几个逻辑执行计划的优化器外，重点是planAggregateWithOneDistinct（有一个count distinct情况下生成物理执行计划的原理）。

在面试时，或多或少会被问到有关count distinct的优化，现在离线任务用到的基本就是hivesql和sparksql，那sparksql中有关count distinct做了哪些优化呢？

实际上sparksql中count distinct执行原理可以从两个点来说明：

with one count distinct
more than one count distinct

这篇文章主要聊一聊 with one count distinct，如果你正好也想了解这块，就点赞、收藏吧

本文基于spark 3.2

本文大纲

1、Aggregate函数的几种mode2、生成WithOneDistinct物理执行计划的几个阶段3、除了count distinct，没有其他非distinct聚合函数的情况的执行原理4、除了count distinct，有其他非distinct聚合函数的情况的执行原理5、关键点调试6、总结

1、Aggregate函数的几种mode

Partial: 局部数据的聚合。会根据读入的原始数据更新对应的聚合缓冲区，当处理完所有的输入数据后，返回的是局部聚合的结果

PartialMerge: 主要是对Partial返回的聚合缓冲区（局部聚合结果）进行合并，但此时仍不是最终结果，还要经过Final才是最终结果(count distinct 类型)

Final: 起到的作用是将聚合缓冲区的数据进行合并，然后返回最终的结果

Complete: 不进行局部聚合计算，应用在不支持Partial模式的聚合函数上（比如求百分位percentile_approx）

非distinct类的聚合函数的路线：Partial --> Final

distinct类的聚合函数的路线：Partial --> PartialMerge --> Partial --> Final

2、生成WithOneDistinct物理执行计划的几个阶段

partialAggregate
partialMergeAggregate
partialDistinctAggregate
finalAggregate

3、没有其他非distinct聚合函数的情况下执行原理

sql：

select a,count(distinct b )  from testdata2 group by a

Optimized Logical Plan-->Physical Plan-->executedPlan：

== Optimized Logical Plan ==
Aggregate [a#3], [a#3, count(distinct b#4) AS count(DISTINCT b)#11L]
+- SerializeFromObject [knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).a AS a#3, knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).b AS b#4]
   +- ExternalRDD [obj#2]

== Physical Plan ==
HashAggregate(keys=[a#3], functions=[count(distinct b#4)], output=[a#3, count(DISTINCT b)#11L])
+- HashAggregate(keys=[a#3], functions=[partial_count(distinct b#4)], output=[a#3, count#16L])
   +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
      +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
         +- SerializeFromObject [knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).a AS a#3, knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).b AS b#4]
            +- Scan[obj#2]

== executedPlan ==
AdaptiveSparkPlan isFinalPlan=false
+- HashAggregate(keys=[a#3], functions=[count(distinct b#4)], output=[a#3, count(DISTINCT b)#11L])
   +- Exchange hashpartitioning(a#3, 5), ENSURE_REQUIREMENTS, [id=#28]
      +- HashAggregate(keys=[a#3], functions=[partial_count(distinct b#4)], output=[a#3, count#16L])
         +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
            +- Exchange hashpartitioning(a#3, b#4, 5), ENSURE_REQUIREMENTS, [id=#24]
               +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
                  +- SerializeFromObject [knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).a AS a#3, knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).b AS b#4]
                     +- Scan[obj#2]

四个阶段的运行原理：

4、有其他非distinct聚合函数的情况下执行原理

sql：

select a,count(distinct b),max(b) from testdata2 group by a

Optimized Logical Plan-->Physical Plan-->executedPlan：

== Optimized Logical Plan ==
Aggregate [a#3], [a#3, count(distinct b#4) AS count(DISTINCT b)#12L, max(b#4) AS max(b)#13]
+- SerializeFromObject [knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).a AS a#3, knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).b AS b#4]
   +- ExternalRDD [obj#2]

== Physical Plan ==
HashAggregate(keys=[a#3], functions=[max(b#4), count(distinct b#4)], output=[a#3, count(DISTINCT b)#12L, max(b)#13])
+- HashAggregate(keys=[a#3], functions=[merge_max(b#4), partial_count(distinct b#4)], output=[a#3, max#18, count#21L])
   +- HashAggregate(keys=[a#3, b#4], functions=[merge_max(b#4)], output=[a#3, b#4, max#18])
      +- HashAggregate(keys=[a#3, b#4], functions=[partial_max(b#4)], output=[a#3, b#4, max#18])
         +- SerializeFromObject [knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).a AS a#3, knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).b AS b#4]
            +- Scan[obj#2]

== executedPlan ==
AdaptiveSparkPlan isFinalPlan=false
+- HashAggregate(keys=[a#3], functions=[max(b#4), count(distinct b#4)], output=[a#3, count(DISTINCT b)#12L, max(b)#13])
   +- Exchange hashpartitioning(a#3, 5), ENSURE_REQUIREMENTS, [id=#28]
      +- HashAggregate(keys=[a#3], functions=[merge_max(b#4), partial_count(distinct b#4)], output=[a#3, max#18, count#21L])
         +- HashAggregate(keys=[a#3, b#4], functions=[merge_max(b#4)], output=[a#3, b#4, max#18])
            +- Exchange hashpartitioning(a#3, b#4, 5), ENSURE_REQUIREMENTS, [id=#24]
               +- HashAggregate(keys=[a#3, b#4], functions=[partial_max(b#4)], output=[a#3, b#4, max#18])
                  +- SerializeFromObject [knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).a AS a#3, knownnotnull(assertnotnull(input[0, org.apache.spark.sql.test.SQLTestData$TestData2, true])).b AS b#4]
                     +- Scan[obj#2]

四个阶段的运行原理：

5、关键点调试

distinctAggregateExpressions-->带distinct聚合函数的表达式

distinctAggregateAttributes-->带distinct聚合函数的引用

val (distinctAggregateExpressions, distinctAggregateAttributes) =
        rewrittenDistinctFunctions.zipWithIndex.map { case (func, i) =>
          // We rewrite the aggregate function to a non-distinct aggregation because
          // its input will have distinct arguments.
          // We just keep the isDistinct setting to true, so when users look at the query plan,
          // they still can see distinct aggregations.
          val expr = AggregateExpression(func, Partial, isDistinct = true)
          // Use original AggregationFunction to lookup attributes, which is used to build
          // aggregateFunctionToAttribute
          val attr = functionsWithDistinct(i).resultAttribute
          (expr, attr)
      }.unzip

debug结果：

6、总结

我们对hive的count(distinct)做优化，怎么做？先group by，再count

Sparksql with one count(distinct) 的情况，相比于hive来说，做了优化


select a,count(distinct b)  from testdata2 group by a
等价于
select a,count(b) from (
select a,b  from testdata2 group by a,b
) tmp  group by a

HashAggregate(keys=[a#3], functions=[count(distinct b#4)], output=[a#3, count(DISTINCT b)#11L])
+- HashAggregate(keys=[a#3], functions=[partial_count(distinct b#4)], output=[a#3, count#16L])
   +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
      +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
         +- SerializeFromObject
            +- Scan[obj#2]
----------------------------------------------------------------------------
HashAggregate(keys=[a#3], functions=[count(1)], output=[a#3, count(b)#11L])
+- HashAggregate(keys=[a#3], functions=[partial_count(1)], output=[a#3, count#15L])
   +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3])
      +- HashAggregate(keys=[a#3, b#4], functions=[], output=[a#3, b#4])
         +- SerializeFromObject
            +- Scan[obj#2]
