Spring入门:Resource

作者头像
WEBJ2EE
发布于 2019-08-14 12:25:22
发布于 2019-08-14 12:25:22
90200
代码可运行
举报
文章被收录于专栏:WebJ2EEWebJ2EE
运行总次数:0
代码可运行

1. Resource ?

Spring 把所有能记录信息的载体,如各种类型的文件、二进制流等都称为资源,对 Spring 开发者来说,最常用的资源就是 Spring 配置文件(通常是一份 XML 格式的文件)。 Spring 资源访问剖析和策略模式应用(李刚)

2. 为什么 Spring 要搞 Resource ?

一方面:增强 Java 原生的资源访问能力

Spring 需要与各式各样的资源打交道:

  • Url 资源(网络资源)
  • classpath 资源(类加载路径里的资源)
  • File 资源(文件系统
  • SerlvetContext 资源(相对于 ServletContext 路径里的资源)
  • 自定义资源(开发通过 ByteArray、InputStream 自由构造)

然而,用 Java 的 File、URL 访问这些底层资源的步骤过于繁琐。Spring 为资源访问提供了一个 Resource 接口,该接口提供了更强的资源访问能力。

图:Resource 接口

另一方面:对资源进行统一抽象,屏蔽资源访问细节

Resource 接口就是策略模式的典型应用,应用只和 Resource 接口耦合,并不知道底层采用何种资源访问策略,这样应用可以在不同的资源访问策略之间自由切换。

Spring 为 Resource 接口提供了如下实现类:

  • UrlResource:用于访问网络资源
  • ClassPathResource:用于访问类加载路径中资源
  • FileSystemResource:用于访问文件系统中资源
  • ServletContextResource:用于 ServletContext 路径中的资源
  • InputStreamResource:用于自定义资源来源
  • ByteArrayResource:用于自定义资源来源

3. Resource 应用示例

Resource 不仅可在 Spring 的项目中使用,也可直接作为资源访问的工具类使用。意思是说:即使不使用 Spring 框架,也可以使用 Resource 作为工具类,用来代替 URL。当然,使用 Resource 接口会让代码与 Spring 的接口耦合在一起,但这种耦合只是部分工具集的耦合,不会造成太大的代码污染。

示例1:FileSystemResource

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
import org.apache.commons.io.IOUtils;import org.springframework.core.io.FileSystemResource;
import java.io.IOException;import java.util.Date;
public class ResourceDemo {    public static void main(String[] args) throws IOException {        FileSystemResource fsr = new FileSystemResource("E:/springdemo/src/main/resources/webj2ee.txt");        System.out.println("exists: "+fsr.exists());        System.out.println("readable: "+fsr.isReadable());        System.out.println("writable: "+fsr.isWritable());        System.out.println("path: "+fsr.getPath());        System.out.println("fileName: "+fsr.getFilename());        System.out.println("lastModified: "+new Date(fsr.lastModified()));        System.out.println("description: "+fsr.getDescription());        System.out.println("content: "+IOUtils.toString(fsr.getInputStream(), "UTF-8"));    }}

示例2:ClassPathResource

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
import org.apache.commons.io.IOUtils;import org.springframework.core.io.ClassPathResource;
import java.io.IOException;import java.util.Date;
public class ResourceDemo {    public static void main(String[] args) throws IOException {
        ClassPathResource fsr = new ClassPathResource("webj2ee/webj2ee.txt");        System.out.println("exists: "+fsr.exists());        System.out.println("readable: "+fsr.isReadable());        System.out.println("isFile: "+fsr.isFile());        System.out.println("path: "+fsr.getPath());        System.out.println("fileName: "+fsr.getFilename());        System.out.println("lastModified: "+new Date(fsr.lastModified()));        System.out.println("description: "+fsr.getDescription());        System.out.println("content: "+IOUtils.toString(fsr.getInputStream(), "UTF-8"));    }}

示例3:ServletContextResource

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
package webj2ee;
import org.apache.commons.io.IOUtils;import org.springframework.web.context.support.ServletContextResource;
import javax.servlet.ServletException;import javax.servlet.annotation.WebServlet;import javax.servlet.http.HttpServlet;import javax.servlet.http.HttpServletRequest;import javax.servlet.http.HttpServletResponse;import java.io.IOException;import java.util.Date;
@WebServlet(name = "SCRDemo",urlPatterns = {"/SCRDemo"})public class SCRDemo extends HttpServlet {    @Override    protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {        ServletContextResource fsr = new ServletContextResource(request.getServletContext(), "webj2ee-servletcontext/webj2ee.txt");        System.out.println("exists: " + fsr.exists());        System.out.println("readable: " + fsr.isReadable());        System.out.println("path: " + fsr.getPath());        System.out.println("URL: "+fsr.getURL());        System.out.println("URI: "+fsr.getURI());        System.out.println("fileName: " + fsr.getFilename());        System.out.println("lastModified: " + new Date(fsr.lastModified()));        System.out.println("description: " + fsr.getDescription());        System.out.println("content: " + IOUtils.toString(fsr.getInputStream(), "UTF-8"));    }}

总结:Spring 提供的各种 Resource 实现类非常实用,避免了直接使用 URL、File 的繁琐、复杂,建议在项目中直接使用。

4. Resource 基本原理

Resource 的各实现类

涉及IO、NIO、JAR、File、Classpath 众多技术细节

留待后续文章详细分析

Resource 总体架构:

InputStreamSource.java 源码:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
package org.springframework.core.io;
import java.io.IOException;import java.io.InputStream;
/** * Simple interface for objects that are sources for an {@link InputStream}. * * <p>This is the base interface for Spring's more extensive {@link Resource} interface. * * <p>For single-use streams, {@link InputStreamResource} can be used for any * given {@code InputStream}. Spring's {@link ByteArrayResource} or any * file-based {@code Resource} implementation can be used as a concrete * instance, allowing one to read the underlying content stream multiple times. * This makes this interface useful as an abstract content source for mail * attachments, for example. */public interface InputStreamSource {  /**   * Return an {@link InputStream} for the content of an underlying resource.   * <p>It is expected that each call creates a <i>fresh</i> stream.   * <p>This requirement is particularly important when you consider an API such   * as JavaMail, which needs to be able to read the stream multiple times when   * creating mail attachments. For such a use case, it is <i>required</i>   * that each {@code getInputStream()} call returns a fresh stream.   * @return the input stream for the underlying resource (must not be {@code null})   * @throws java.io.FileNotFoundException if the underlying resource doesn't exist   * @throws IOException if the content stream could not be opened   */  InputStream getInputStream() throws IOException;}

Resource.java 源码节选:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
package org.springframework.core.io;
import java.io.File;import java.io.IOException;import java.io.InputStream;import java.net.URI;import java.net.URL;import java.nio.channels.Channels;import java.nio.channels.ReadableByteChannel;
import org.springframework.lang.Nullable;
/** * Interface for a resource descriptor that abstracts from the actual * type of underlying resource, such as a file or class path resource. * * <p>An InputStream can be opened for every resource if it exists in * physical form, but a URL or File handle can just be returned for * certain resources. The actual behavior is implementation-specific. */public interface Resource extends InputStreamSource {
  /**   * Determine whether this resource actually exists in physical form.   * <p>This method performs a definitive existence check, whereas the   * existence of a {@code Resource} handle only guarantees a valid   * descriptor handle.   */  boolean exists();
  /**   * Indicate whether non-empty contents of this resource can be read via   * {@link #getInputStream()}.   * <p>Will be {@code true} for typical resource descriptors that exist   * since it strictly implies {@link #exists()} semantics as of 5.1.   * Note that actual content reading may still fail when attempted.   * However, a value of {@code false} is a definitive indication   * that the resource content cannot be read.   * @see #getInputStream()   * @see #exists()   */  default boolean isReadable() {    return exists();  }
  /**   * Indicate whether this resource represents a handle with an open stream.   * If {@code true}, the InputStream cannot be read multiple times,   * and must be read and closed to avoid resource leaks.   * <p>Will be {@code false} for typical resource descriptors.   */  default boolean isOpen() {    return false;  }
  /**   * Determine whether this resource represents a file in a file system.   * A value of {@code true} strongly suggests (but does not guarantee)   * that a {@link #getFile()} call will succeed.   * <p>This is conservatively {@code false} by default.   * @since 5.0   * @see #getFile()   */  default boolean isFile() {    return false;  }
  /**   * Return a URL handle for this resource.   * @throws IOException if the resource cannot be resolved as URL,   * i.e. if the resource is not available as descriptor   */  URL getURL() throws IOException;
  /**   * Return a URI handle for this resource.   * @throws IOException if the resource cannot be resolved as URI,   * i.e. if the resource is not available as descriptor   * @since 2.5   */  URI getURI() throws IOException;
  /**   * Return a File handle for this resource.   * @throws java.io.FileNotFoundException if the resource cannot be resolved as   * absolute file path, i.e. if the resource is not available in a file system   * @throws IOException in case of general resolution/reading failures   * @see #getInputStream()   */  File getFile() throws IOException;  /**   * Determine the content length for this resource.   * @throws IOException if the resource cannot be resolved   * (in the file system or as some other known physical resource type)   */  long contentLength() throws IOException;
  /**   * Determine the last-modified timestamp for this resource.   * @throws IOException if the resource cannot be resolved   * (in the file system or as some other known physical resource type)   */  long lastModified() throws IOException;
  /**   * Create a resource relative to this resource.   * @param relativePath the relative path (relative to this resource)   * @return the resource handle for the relative resource   * @throws IOException if the relative resource cannot be determined   */  Resource createRelative(String relativePath) throws IOException;
  /**   * Determine a filename for this resource, i.e. typically the last   * part of the path: for example, "myfile.txt".   * <p>Returns {@code null} if this type of resource does not   * have a filename.   */  @Nullable  String getFilename();
  /**   * Return a description for this resource,   * to be used for error output when working with the resource.   * <p>Implementations are also encouraged to return this value   * from their {@code toString} method.   * @see Object#toString()   */  String getDescription();}

AbstractResource.java 源码节选:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
package org.springframework.core.io;
import java.io.File;import java.io.FileNotFoundException;import java.io.IOException;import java.io.InputStream;import java.net.URI;import java.net.URISyntaxException;import java.net.URL;import java.nio.channels.Channels;import java.nio.channels.ReadableByteChannel;
import org.springframework.core.NestedIOException;import org.springframework.lang.Nullable;import org.springframework.util.ResourceUtils;
/** * Convenience base class for {@link Resource} implementations, * pre-implementing typical behavior. * * <p>The "exists" method will check whether a File or InputStream can * be opened; "isOpen" will always return false; "getURL" and "getFile" * throw an exception; and "toString" will return the description. * * @author Juergen Hoeller * @since 28.12.2003 */public abstract class AbstractResource implements Resource {
  /**   * This implementation checks whether a File can be opened,   * falling back to whether an InputStream can be opened.   * This will cover both directories and content resources.   */  @Override  public boolean exists() {    // Try file existence: can we find the file in the file system?    try {      return getFile().exists();    }    catch (IOException ex) {      // Fall back to stream existence: can we open the stream?      try {        getInputStream().close();        return true;      }      catch (Throwable isEx) {        return false;      }    }  }
  /**   * This implementation always returns {@code true} for a resource   * that {@link #exists() exists} (revised as of 5.1).   */  @Override  public boolean isReadable() {    return exists();  }
  /**   * This implementation always returns {@code false}.   */  @Override  public boolean isOpen() {    return false;  }
  /**   * This implementation always returns {@code false}.   */  @Override  public boolean isFile() {    return false;  }
  /**   * This implementation throws a FileNotFoundException, assuming   * that the resource cannot be resolved to a URL.   */  @Override  public URL getURL() throws IOException {    throw new FileNotFoundException(getDescription() + " cannot be resolved to URL");  }
  /**   * This implementation builds a URI based on the URL returned   * by {@link #getURL()}.   */  @Override  public URI getURI() throws IOException {    URL url = getURL();    try {      return ResourceUtils.toURI(url);    }    catch (URISyntaxException ex) {      throw new NestedIOException("Invalid URI [" + url + "]", ex);    }  }
  /**   * This implementation throws a FileNotFoundException, assuming   * that the resource cannot be resolved to an absolute file path.   */  @Override  public File getFile() throws IOException {    throw new FileNotFoundException(getDescription() + " cannot be resolved to absolute file path");  }
  /**   * This implementation returns {@link Channels#newChannel(InputStream)}   * with the result of {@link #getInputStream()}.   * <p>This is the same as in {@link Resource}'s corresponding default method   * but mirrored here for efficient JVM-level dispatching in a class hierarchy.   */  @Override  public ReadableByteChannel readableChannel() throws IOException {    return Channels.newChannel(getInputStream());  }
  /**   * This implementation reads the entire InputStream to calculate the   * content length. Subclasses will almost always be able to provide   * a more optimal version of this, e.g. checking a File length.   * @see #getInputStream()   */  @Override  public long contentLength() throws IOException {    InputStream is = getInputStream();    try {      long size = 0;      byte[] buf = new byte[256];      int read;      while ((read = is.read(buf)) != -1) {        size += read;      }      return size;    }    finally {      try {        is.close();      }      catch (IOException ex) {      }    }  }
  /**   * This implementation checks the timestamp of the underlying File,   * if available.   * @see #getFileForLastModifiedCheck()   */  @Override  public long lastModified() throws IOException {    File fileToCheck = getFileForLastModifiedCheck();    long lastModified = fileToCheck.lastModified();    if (lastModified == 0L && !fileToCheck.exists()) {      throw new FileNotFoundException(getDescription() +          " cannot be resolved in the file system for checking its last-modified timestamp");    }    return lastModified;  }
  /**   * Determine the File to use for timestamp checking.   * <p>The default implementation delegates to {@link #getFile()}.   * @return the File to use for timestamp checking (never {@code null})   * @throws FileNotFoundException if the resource cannot be resolved as   * an absolute file path, i.e. is not available in a file system   * @throws IOException in case of general resolution/reading failures   */  protected File getFileForLastModifiedCheck() throws IOException {    return getFile();  }
  /**   * This implementation throws a FileNotFoundException, assuming   * that relative resources cannot be created for this resource.   */  @Override  public Resource createRelative(String relativePath) throws IOException {    throw new FileNotFoundException("Cannot create a relative resource for " + getDescription());  }
  /**   * This implementation always returns {@code null},   * assuming that this resource type does not have a filename.   */  @Override  @Nullable  public String getFilename() {    return null;  }

  /**   * This implementation compares description strings.   * @see #getDescription()   */  @Override  public boolean equals(Object other) {    return (this == other || (other instanceof Resource &&        ((Resource) other).getDescription().equals(getDescription())));  }
  /**   * This implementation returns the description's hash code.   * @see #getDescription()   */  @Override  public int hashCode() {    return getDescription().hashCode();  }
  /**   * This implementation returns the description of this resource.   * @see #getDescription()   */  @Override  public String toString() {    return getDescription();  }}

参考:

https://docs.spring.io/spring-framework/docs/current/spring-framework-reference/core.html#resources https://www.ibm.com/developerworks/cn/java/j-lo-spring-resource/index.html https://tools.ietf.org/html/rfc3986
