单细胞测序—亚群比例图绘制

DimPlot(sce.all.int, reduction = "tsne",raster = F,group.by = 'RNA_snn_res.0.6',
        label = T,repel = T) +
  DimPlot(sce.all.int, reduction = "tsne",raster = F,group.by = 'celltype',
          label = T,repel = T)
ggsave(paste('paper_anno_and_tsne.pdf'),width  = 12,height = 10)

df=data.frame(clu=names(table(sce.all.int$seurat_clusters)),
                per=sprintf("%1.2f%%",100*table(sce.all.int$seurat_clusters)/length(sce.all.int$seurat_clusters)))
sce.all.int$per=df[match(sce.all.int$seurat_clusters,df$clu),2]
sce.all.int$new=paste0(sce.all.int$seurat_clusters,":",sce.all.int$celltype,"(",sce.all.int$per,")")
table(sce.all.int$new)
DimPlot(sce.all.int,reduction='tsne',
        group.by='new',
        label.box=T,label=T,repel=T)
ggsave(paste('paper_anno_percentage.pdf'),width  = 12,height = 10)

PropPlot <- function(object, groupBy){
  # (1)获取绘图数据
  plot_data = object@meta.data %>%
    dplyr::select(orig.ident, {{groupBy}}) %>%
    dplyr::rename(group = as.name(groupBy))

  # (2)绘图
  figure = ggbarstats(data = plot_data,
                      x = group, y = orig.ident,
                      package = 'ggsci',
                      palette = 'category20c_d3',
                      results.subtitle = FALSE,
                      bf.message = FALSE,
                      proportion.test = FALSE,
                      label.args = list(size = 2,
                                        fill = 'white',
                                        alpha = 0.85,
                                        family = 'Arial',
                                        fontface = 'bold'),
                      perc.k = 2,
                      title = '',
                      xlab = '',
                      legend.title = 'Seurat Cluster',
                      ggtheme = ggpubr::theme_pubclean()) +
    theme(axis.ticks.x = element_blank(),
          axis.ticks.y = element_line(color = 'black', lineend = 'round'),
          legend.position = 'right',
          axis.text.x = element_text(size = 15, color = 'black', family = 'Arial'),
          axis.text.y = element_text(size = 15, color = 'black', family = 'Arial'),
          legend.text = element_text(family = 'Arial', size = 10, color = 'black'),
          legend.title = element_text(family = 'Arial', size = 13, color = 'black'))

  # (3)去除柱子下面的样本量标识：
  gginnards::delete_layers(x = figure, match_type = 'GeomText')
}

#调用函数
library(gginnards)
PropPlot(object  =  sce.all.int,  groupBy  =  'celltype')
