华为Datacom-HCIP实验拓扑练习

R1

[]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 192.168.1.254 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 12.1.1.1 24

[liushuo-Ethernet0/0/1]q

[liushuo]ip route-static 192.168.2.0 24 e0/0/1 12.1.1.2

R2

[liushuo]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 12.1.1.2 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 192.168.2.254 24

[liushuo-Ethernet0/0/1]q

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 12.1.1.1

R3

[liushuo]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 192.168.1.254 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 12.1.1.1 24

[liushuo-Ethernet0/0/1]int g0/0/0

[liushuo-GigabitEthernet0/0/0]ip ad 23.1.1.1 24

[liushuo-GigabitEthernet0/0/0]q

[liushuo]ip route-static 192.168.2.0 24 e0/0/1 12.1.1.2

[liushuo]ip route-static 192.168.2.0 24 g0/0/0 23.1.1.2

R4

[liushuo]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 12.1.1.2 24

[liushuo-Ethernet0/0/0]int g0/0/0

[liushuo-GigabitEthernet0/0/0]ip ad 23.1.1.2 24

[liushuo-GigabitEthernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 192.168.2.254 24

[liushuo-Ethernet0/0/1]q

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 12.1.1.1

[liushuo]ip route-static 192.168.1.0 24 g0/0/0 23.1.1.1

R5

<Huawei>undo t m

<Huawei>sy

[Huawei]int e0/0/0

[Huawei-Ethernet0/0/0]ip ad 192.168.1.254 24

[Huawei-Ethernet0/0/0]int e0/0/1

[Huawei-Ethernet0/0/1]ip ad 12.1.1.1 24

[Huawei-Ethernet0/0/1]q

[Huawei]ip route-static 192.168.2.0 24 e0/0/1 12.1.1.2

[Huawei]ip route-static 192.168.3.0 24 e0/0/1 12.1.1.2

[Huawei]ip route-static 192.168.4.0 24 e0/0/1 12.1.1.2

R6

<Huawei>

<Huawei>undo t m

<Huawei>sy

[Huawei]sy liushuo

[liushuo]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 12.1.1.2 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 192.168.3.254 24

[liushuo-Ethernet0/0/1]int g0/0/1

[liushuo-GigabitEthernet0/0/1]ip ad 192.168.2.254 24

[liushuo-GigabitEthernet0/0/1]int g0/0/0

[liushuo-GigabitEthernet0/0/0]ip ad 192.168.4.254 24

[liushuo-GigabitEthernet0/0/0]q

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 12.1.1.1

R7

<Huawei>undo t m

<Huawei>sy

[Huawei]sy liushuo

[liushuo]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 192.168.1.254 24

[liushuo-Ethernet0/0/0]int g0/0/0

[liushuo-GigabitEthernet0/0/0]ip ad 23.1.1.1 24

[liushuo-GigabitEthernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 12.1.1.1 24

[liushuo-Ethernet0/0/1]q

[liushuo]ip route-static 0.0.0.0 0 g0/0/0 23.1.1.2

[liushuo]ip route-static 0.0.0.0 0 e0/0/1 12.1.1.2

R8

[liushuo]int g0/0/2

[liushuo-GigabitEthernet0/0/2]ip ad 23.1.1.2 24

[liushuo-GigabitEthernet0/0/2]int e0/0/0

[liushuo-Ethernet0/0/0]ip ad 12.1.1.2 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 192.168.2.254 24

[liushuo-Ethernet0/0/1]int g0/0/0

[liushuo-GigabitEthernet0/0/0]ip ad 192.168.3.254 24

[liushuo-GigabitEthernet0/0/0]int g0/0/1

[liushuo-GigabitEthernet0/0/1]ip ad 192.168.4.254 24

[liushuo-GigabitEthernet0/0/1]q

[liushuo]ip route-static 192.168.1.0 24 g0/0/2 23.1.1.1

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 12.1.1.1

R9

<Huawei>

<Huawei>undo t m

<Huawei>sy

[Huawei]int e0/0/0

[Huawei-Ethernet0/0/0]ip ad 192.168.1.254 24

[Huawei-Ethernet0/0/0]int e0/0/1

[Huawei-Ethernet0/0/1]ip ad 12.1.1.1 24

[Huawei-Ethernet0/0/1]q

[Huawei]sy liushuo

[liushuo]ip route-static 192.168.2.0 24 e0/0/1 12.1.1.2

R10

<Huawei>undo t m

<Huawei>sy

[Huawei]int e0/0/0

[Huawei-Ethernet0/0/0]ip ad 12.1.1.2 24

[Huawei-Ethernet0/0/0]int e0/0/1

[Huawei-Ethernet0/0/1]ip ad 23.1.1.1 24

[Huawei-Ethernet0/0/1]q

[Huawei]sy liushuo

[liushuo]ip route-static 192.168.2.0 24 e0/0/1 23.1.1.2

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 12.1.1.1

R11

<Huawei>

<Huawei>undo t m

<Huawei>sy

[Huawei]sy liushuo

[liushuo]int  e0/0/00

[liushuo-Ethernet0/0/0]ip ad 23.1.1.2 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 13.1.1.1 24

[liushuo-Ethernet0/0/1]q

[liushuo]ip route-static 192.168.2.0 24 e0/0/1 13.1.1.2

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 23.1.1.1

R12

<Huawei>undo t m

<Huawei>sy

[Huawei]sy liushuo

[liushuo]int e0/0/00

[liushuo-Ethernet0/0/0]ip ad 13.1.1.2 24

[liushuo-Ethernet0/0/0]int e0/0/1

[liushuo-Ethernet0/0/1]ip ad 192.168.2.254 24

[liushuo-Ethernet0/0/1]q

[liushuo]ip route-static 192.168.1.0 24 e0/0/0 13.1.1.1
