//设备接收队列，和 RPS 相关成员是 rps_map
/* This structure contains an instance of an RX queue. */
struct netdev_rx_queue {
#ifdef CONFIG_RPS
    struct rps_map __rcu        *rps_map;
    struct rps_dev_flow_table __rcu *rps_flow_table;
#endif
    struct kobject          kobj;
    struct net_device       *dev;
} ____cacheline_aligned_in_smp;

//存放配置RPS的值，假如/sys/class/net/(dev)/queues/rx-(n)/rps_cpus=f，则
/len=4, cpus指向额外分配的内存数组，每个元素保存一个cpu值
struct rps_map {
    unsigned int len;
    struct rcu_head rcu;
    u16 cpus[0];
};

store_rps_map
    for_each_cpu_and(cpu, mask, cpu_online_mask)
      map->cpus[i++] = cpu;
    if (i)
      map->len = i;
   //将map赋值到queue->rps_map中，在get_rps_cpu中会使用到
   rcu_assign_pointer(queue->rps_map, map);

    if (map)
        //使能RPS
        static_key_slow_inc(&rps_needed);

static inline __u32 skb_get_hash(struct sk_buff *skb)
{
  if (!skb->l4_hash && !skb->sw_hash)
    __skb_get_hash(skb);

  return skb->hash;
}

/*
 * get_rps_cpu is called from netif_receive_skb and returns the target
 * CPU from the RPS map of the receiving queue for a given skb.
 * rcu_read_lock must be held on entry.
 */
static int get_rps_cpu(struct net_device *dev, struct sk_buff *skb,
               struct rps_dev_flow **rflowp)
{
    struct netdev_rx_queue *rxqueue;
    struct rps_map *map;
    struct rps_dev_flow_table *flow_table;
    struct rps_sock_flow_table *sock_flow_table;
    int cpu = -1;
    u16 tcpu;
    u32 hash;

    //skb->queue_mapping+1 记录了skb从哪个队列接收上来
    if (skb_rx_queue_recorded(skb)) {
        //获取接收skb队列index
        u16 index = skb_get_rx_queue(skb);
        if (unlikely(index >= dev->real_num_rx_queues)) {
            WARN_ONCE(dev->real_num_rx_queues > 1,
                  "%s received packet on queue %u, but number "
                  "of RX queues is %u\n",
                  dev->name, index, dev->real_num_rx_queues);
            goto done;
        }
        //根据index，获取rxqueue
        rxqueue = dev->_rx + index;
    } else
        //这里应该是queue 0吧
        rxqueue = dev->_rx;

    map = rcu_dereference(rxqueue->rps_map);
    if (map) {
        //如果rps_map只配置了一个CPU，并且没有配置rps_flow_table，
        //并且rps_sock_flow_entries 配置的这个cpu在线，则直接使用这个cpu。
        //如果这个cpu不在线，则返回-1.
        if (map->len == 1 &&
            !rcu_access_pointer(rxqueue->rps_flow_table)) {
            tcpu = map->cpus[0];
            if (cpu_online(tcpu))
                cpu = tcpu;
            goto done;
        }
    //没有配置 rps_map，也没有配置 rps_flow_table
    } else if (!rcu_access_pointer(rxqueue->rps_flow_table)) {
        goto done;
    }

    skb_reset_network_header(skb);
    //根据skb获取hash值。如果在RSS模式下，可以直接使用网
    //卡计算的hash值，否则需要根据数据包信息计算一个
    hash = skb_get_hash(skb);
    if (!hash)
        goto done;
    //flow_table 和 sock_flow_table 是RFS的流程，暂时忽略
    flow_table = rcu_dereference(rxqueue->rps_flow_table);
    sock_flow_table = rcu_dereference(rps_sock_flow_table);
    if (flow_table && sock_flow_table) {
       /* ... */
    }
    //如果没有在设备流表rps_flow_table和全局流表
    //rps_sock_flow_table中找到目标cpu，则使用hash在
    //rps_map中找一个cpu即可。
    if (map) {
        tcpu = map->cpus[reciprocal_scale(hash, map->len)];
        if (cpu_online(tcpu)) {
            cpu = tcpu;
            goto done;
        }
    }

done:
    return cpu;
}

/*
 * The rps_sock_flow_table contains mappings of flows to the last CPU
 * on which they were processed by the application (set in recvmsg).
 */
struct rps_sock_flow_table {
  unsigned int mask;
  u16 ents[0]; // 弹性数组，key 是 flow hash，value 是流渴望被处理的CPU，也就是应用所在的CPU
};

static inline void rps_record_sock_flow(struct rps_sock_flow_table *table,
          u32 hash)
{
  if (table && hash) {
    unsigned int cpu, index = hash & table->mask;

    /* We only give a hint, preemption can change cpu under us */
        /*当前CPU*/
    cpu = raw_smp_processor_id();
    /*ents存放当前cpu*/
    if (table->ents[index] != cpu)
      table->ents[index] = cpu;
  }
}

struct netdev_rx_queue {
  struct rps_map __rcu    *rps_map;
    /*设备流表*/
  struct rps_dev_flow_table __rcu  *rps_flow_table;
  struct kobject      kobj;
  struct net_device    *dev;
} ____cacheline_aligned_in_smp;

struct rps_dev_flow_table {
  unsigned int mask;
  struct rcu_head rcu;
  struct rps_dev_flow flows[0];  //弹性数组
};

struct rps_dev_flow {
  u16 cpu;  /* 处理该流的cpu */
  u16 filter;
  unsigned int last_qtail;  /* sd->input_pkt_queue队列的尾部索引，即该队列长度 */
};

//设置  /sys/class/net/<dev>/queues/rx-<n>/rps_flow_cnt 时
store_rps_dev_flow_table_cnt
    table->mask = mask;
    for (count = 0; count <= mask; count++)
        table->flows[count].cpu = RPS_NO_CPU;

/*
 * get_rps_cpu is called from netif_receive_skb and returns the target
 * CPU from the RPS map of the receiving queue for a given skb.
 * rcu_read_lock must be held on entry.
 */
static int get_rps_cpu(struct net_device *dev, struct sk_buff *skb,
               struct rps_dev_flow **rflowp)
{
    struct netdev_rx_queue *rxqueue;
    struct rps_map *map;
    struct rps_dev_flow_table *flow_table;
    struct rps_sock_flow_table *sock_flow_table;
    int cpu = -1;
    u16 tcpu;
    u32 hash;

    /* ... */

    map = rcu_dereference(rxqueue->rps_map);

    /* ... */

    skb_reset_network_header(skb);
    hash = skb_get_hash(skb);
    if (!hash)
        goto done;

    flow_table = rcu_dereference(rxqueue->rps_flow_table);
    sock_flow_table = rcu_dereference(rps_sock_flow_table);
    if (flow_table && sock_flow_table) {
        u16 next_cpu;
        struct rps_dev_flow *rflow;
        // tcpu记录的是处理数据包的cpu
        rflow = &flow_table->flows[hash & flow_table->mask];
        tcpu = rflow->cpu;
        // next_cpu 记录的是运行 application 的 cpu
        next_cpu = sock_flow_table->ents[hash & sock_flow_table->mask];

        /*
         * If the desired CPU (where last recvmsg was done) is
         * different from current CPU (one in the rx-queue flow
         * table entry), switch if one of the following holds:
         *   - Current CPU is unset (equal to RPS_NO_CPU).
         *   - Current CPU is offline.
         *   - The current CPU's queue tail has advanced beyond the
         *     last packet that was enqueued using this table entry.
         *     This guarantees that all previous packets for the flow
         *     have been dequeued, thus preserving in order delivery.
         */
        if (unlikely(tcpu != next_cpu) &&
            (tcpu == RPS_NO_CPU || !cpu_online(tcpu) ||
             ((int)(per_cpu(softnet_data, tcpu).input_queue_head -
              rflow->last_qtail)) >= 0)) {
            tcpu = next_cpu;
            rflow = set_rps_cpu(dev, skb, rflow, next_cpu);
        }

        if (tcpu != RPS_NO_CPU && cpu_online(tcpu)) {
            *rflowp = rflow;
            cpu = tcpu;
            goto done;
        }
    }

    // 如果没有在设备流表rps_flow_table和全局流表rps_sock_flow_table中找到目标cpu，
    // 则使用hash在rps_map中找一个cpu即可。
    if (map) {
        tcpu = map->cpus[reciprocal_scale(hash, map->len)];
        if (cpu_online(tcpu)) {
            cpu = tcpu;
            goto done;
        }
    }

done:
    return cpu;
}

static struct rps_dev_flow *
set_rps_cpu(struct net_device *dev, struct sk_buff *skb,
        struct rps_dev_flow *rflow, u16 next_cpu)
{
    if (next_cpu != RPS_NO_CPU) {
        rflow->last_qtail =
            per_cpu(softnet_data, next_cpu).input_queue_head;
    }

    rflow->cpu = next_cpu;
    return rflow;
}
