207.HarmonyOS NEXT系列教程之 TabsConcaveCircle组件完整源码解析

import animator, { AnimatorResult } from '@ohos.animator';
import componentUtils from '@ohos.arkui.componentUtils';
import inspector from '@ohos.arkui.inspector';
import { CanvasClipGroove, CanvasCreateRectangle, getImageUrl } from '../../utils/tabbar/Functions';
import { TabMenusInterfaceIRequired } from '../../types/TabMenusInterface';
import { ConcaveCircle } from '../../utils/tabbar/CircleClass';

@Component
export struct TabsConcaveCircle {
  @Link @Watch("getAnimateSelectIndex") selectIndex: number;
  @State animateSelectIndex: number = 0;
  @Prop tabHeight: number = 60;
  @Link tabsMenu: TabMenusInterfaceIRequired[];
  @Prop tabsBgColor: string = "rgb(255, 255, 255)";
  @Prop tabsSelectBgColor: Color | number | string | Resource = "rgba(92, 187, 183,1)";
  @Prop tabsFontColor: Color = Color.Black;
  @Prop tabsSelectFontColor: Color = Color.Black;

private settings: RenderingContextSettings = new RenderingContextSettings(true);
private context: CanvasRenderingContext2D = new CanvasRenderingContext2D(this.settings);

createCanvas() {
  if (this.circleInfo) {
    this.context.reset()
    CanvasCreateRectangle({
      context: this.context,
      tabsBgColor: this.tabsBgColor
    })
    CanvasClipGroove({
      context: this.context,
      menuLength: this.tabsMenu.length,
      center: this.animationPositionX,
    })
  }
}

createAnimation() {
  if (!this.circleInfo) {
    return;
  }
  this.canvasAnimator = animator.create({
    duration: this.animateTime,
    easing: "ease",
    delay: 0,
    fill: "forwards",
    direction: "normal",
    iterations: 1,
    begin: this.animationPositionX,
    end: this.circleInfo?.getMenuCenterX(this.selectIndex)
  })

  this.canvasAnimator.onFrame = (value: number) => {
    this.animationPositionX = value;
    this.circleInfo?.setPositionXY({ x: value - this.circleInfo.circleRadius })
    this.createCanvas()
  }

  this.canvasAnimator.play()
}
