VL53L0X激光测距传感器.ESP32使用篇

云深无际

发布于 2020-12-15 10:02:50

3.3K00

代码可运行

文章被收录于专栏：云深之无迹云深之无迹

运行总次数：0

代码可运行

昨天对传感器的使用,还缺一个ESP32.这里补一下

首先把网站贴上

然后安装

注意这里的串口的打印波特率,错了会乱码

注意选对串口

https://github.com/espressif/arduino-esp32

项目使用了 221281 字节，占用了 (16%) 程序存储空间。最大为 1310720 字节。
全局变量使用了16092字节，(4%)的动态内存，余留311588字节局部变量。最大为327680字节。
esptool.py v2.6
Serial port COM4
Connecting.....
Chip is ESP32D0WDQ6 (revision 1)
Features: WiFi, BT, Dual Core, 240MHz, VRef calibration in efuse, Coding Scheme None
MAC: f0:08:d1:d1:7d:c4
Uploading stub...
Running stub...
Stub running...
Changing baud rate to 921600
Changed.
Configuring flash size...
Auto-detected Flash size: 4MB
Compressed 8192 bytes to 47...
Wrote 8192 bytes (47 compressed) at 0x0000e000 in 0.0 seconds (effective 5461.4 kbit/s)...
Hash of data verified.
Compressed 15856 bytes to 10276...
Wrote 15856 bytes (10276 compressed) at 0x00001000 in 0.1 seconds (effective 991.0 kbit/s)...
Hash of data verified.
Compressed 221392 bytes to 114130...
Wrote 221392 bytes (114130 compressed) at 0x00010000 in 1.7 seconds (effective 1065.0 kbit/s)...
Hash of data verified.
Compressed 3072 bytes to 128...
Wrote 3072 bytes (128 compressed) at 0x00008000 in 0.0 seconds (effective 1638.4 kbit/s)...
Hash of data verified.
Leaving...
Hard resetting via RTS pin...

#include <Wire.h>

void setup() {
  Wire.begin();
  Serial.begin(115200);
  Serial.println("\nI2C Scanner");
}

void loop() {
  byte error, address;
  int nDevices;
  Serial.println("Scanning...");
  nDevices = 0;
  for(address = 1; address < 127; address++ ) {
    Wire.beginTransmission(address);
    error = Wire.endTransmission();
    if (error == 0) {
      Serial.print("I2C device found at address 0x");
      if (address<16) {
        Serial.print("0");
      }
      Serial.println(address,HEX);
      nDevices++;
    }
    else if (error==4) {
      Serial.print("Unknow error at address 0x");
      if (address<16) {
        Serial.print("0");
      }
      Serial.println(address,HEX);
    }
  }
  if (nDevices == 0) {
    Serial.println("No I2C devices found\n");
  }
  else {
    Serial.println("done\n");
  }
  delay(5000);
}

将ESP32与Arduino IDE搭配使用时，默认的I2C引脚为 GPIO 22 （SCL）和 GPIO 21 （SDA）

懂？

以上的程序是对打印i2C所在的地址

拔了i2c的器件,就没有了.插上就又可以打印出来.程序我就不分析了.以后分析

ESP32使用不同的I2C引脚（更改默认I2C引脚）

使用ESP32，你几乎可以将任何引脚设置为具有I2C功能，你只需要在代码中进行设置即可。

当将ESP32与Arduino IDE搭配使用时，请使用 wire库以使用I2C与设备通信。使用此库，你可以按以下方式初始化I2C：

Wire.begin(I2C_SDA, I2C_SCL);

因此，你只需要在驱动器上设置所需的SDA和SCL GPIO即可。 I2C_SDA 和 I2C_SCL 变量。具体驱动这个的方法看我下面的文章

VL53L0X激光测距传感器.Arduino使用篇

这个地方,你需要将引脚地址指定

项目使用了 223345 字节，占用了 (17%) 程序存储空间。最大为 1310720 字节。
全局变量使用了16132字节，(4%)的动态内存，余留311548字节局部变量。最大为327680字节。
esptool.py v2.6
Serial port COM4
Connecting........_
Chip is ESP32D0WDQ6 (revision 1)
Features: WiFi, BT, Dual Core, 240MHz, VRef calibration in efuse, Coding Scheme None
MAC: f0:08:d1:d1:7d:c4
Uploading stub...
Running stub...
Stub running...
Changing baud rate to 921600
Changed.
Configuring flash size...
Auto-detected Flash size: 4MB
Compressed 8192 bytes to 47...
Wrote 8192 bytes (47 compressed) at 0x0000e000 in 0.0 seconds (effective 5957.9 kbit/s)...
Hash of data verified.
Compressed 15856 bytes to 10276...
Wrote 15856 bytes (10276 compressed) at 0x00001000 in 0.1 seconds (effective 998.8 kbit/s)...
Hash of data verified.
Compressed 223456 bytes to 115392...
Wrote 223456 bytes (115392 compressed) at 0x00010000 in 1.7 seconds (effective 1049.7 kbit/s)...
Hash of data verified.
Compressed 3072 bytes to 128...
Wrote 3072 bytes (128 compressed) at 0x00008000 in 0.0 seconds (effective 2234.2 kbit/s)...
Hash of data verified.

Leaving...
Hard resetting via RTS pin...

/*!
 * @file DFRobot_VL53L0X.ino
 * @brief DFRobot's Laser rangefinder library
 * @n The example shows the usage of VL53L0X in a simple way.

 * @copyright  [DFRobot](http://www.dfrobot.com), 2016
 * @copyright  GNU Lesser General Public License

 * @author [LiXin]
 * @version  V1.0
 * @date  2017-8-21
 * @https://github.com/DFRobot/DFRobot_VL53L0X
 timer*/
#include "Arduino.h"
#include "Wire.h"
#include "DFRobot_VL53L0X.h"

/*****************Keywords instruction*****************/
//Continuous--->Continuous measurement model
//Single------->Single measurement mode
//High--------->Accuracy of 0.25 mm
//Low---------->Accuracy of 1 mm
/*****************Function instruction*****************/
//setMode(ModeState mode, PrecisionState precision)
  //*This function is used to set the VL53L0X mode
  //*mode: Set measurement mode       Continuous or Single
  //*precision: Set the precision     High or Low
//void start()
  //*This function is used to enabled VL53L0X
//float getDistance()
  //*This function is used to get the distance
//uint16_t getAmbientCount()
  //*This function is used to get the ambient count
//uint16_t getSignalCount()
  //*This function is used to get the signal count
//uint8_t getStatus();
  //*This function is used to get the status
//void stop()
  //*This function is used to stop measuring

DFRobotVL53L0X sensor;


void setup() {
  //initialize serial communication at 9600 bits per second:
  Serial.begin(115200);
  //join i2c bus (address optional for master)
//  Wire.begin();
  Wire.begin(21, 22);
  //Set I2C sub-device address
  sensor.begin(0x50);
  //Set to Back-to-back mode and high precision mode
  sensor.setMode(Continuous,High);
  //Laser rangefinder begins to work
  sensor.start();
}

void loop()
{
  //Get the distance
  Serial.print("Distance: ");Serial.println(sensor.getDistance());
  //The delay is added to demonstrate the effect, and if you do not add the delay,
  //it will not affect the measurement accuracy
  delay(500);
}

改正了引脚就好了

这个是默认的I2C的引脚,看连接

https://github.com/SmartArduino/SZDOITWiKi/wiki/Programming-with-Lua

放大的引脚位置

然后进行更改引脚

成功使用

这个地方没有看懂

注意看宏定义,两个引脚

这个地方是我把TT拿出来了,改了引脚.上传倒是成功了.
