实验室多工位监测：UDP协议以太网温湿度记录仪，轻量服务器接收程序

┌─────────────────────────────────────────────────────────────────────┐
│ 实验室A（恒温实验室）                                               │
│                                                                     │
│  [工位1] 温箱#1 ──┐                                                 │
│  [工位2] 温箱#2 ──┤                                                 │
│  [工位3] 恒温槽#1 ─┼── 实验室交换机 ──┐                            │
│  [工位4] 培养箱#3 ─┘                 │                            │
│                                      │                            │
├──────────────────────────────────────┼────────────────────────────┤
│ 实验室B（老化实验室）                 │                            │
│                                      │                            │
│  [工位5-20] 老化架×4 ──── 交换机 ───┼── 核心交换机               │
│                                      │                            │
├──────────────────────────────────────┼────────────────────────────┤
│ 实验室C（EMC实验室）                  │                            │
│                                      │                            │
│  [工位21-30] 屏蔽室内的设备 ── 光纤 ─┘                            │
│                                                                     │
└─────────────────────────────────────────────────────────────────────┘
                              │
                    ┌─────────▼─────────┐
                    │ 轻量接收服务器     │
                    │ (Linux, 无显示器) │
                    │                   │
                    │  udp_recv (主程序) │
                    │  ├── UDP监听      │
                    │  ├── 报文解析     │
                    │  ├── 实验会话管理 │
                    │  ├── SQLite存储   │
                    │  └── HTTP API     │
                    │                   │
                    │  资源占用:         │
                    │  CPU < 2%         │
                    │  RAM < 30MB       │
                    │  Disk ~按实验规模  │
                    └─────────┬─────────┘
                              │
              ┌───────────────┼───────────────┐
              │               │               │
        ┌─────▼─────┐  ┌─────▼─────┐  ┌─────▼─────┐
        │ 实验员PC  │  │ 实验员PC  │  │  数据导出  │
        │ 浏览器    │  │ 浏览器    │  │  CSV/Excel │
        │ 实时查看  │  │ 实时查看  │  │  实验报告  │
        └───────────┘  └───────────┘  └───────────┘

┌──────────┬──────────┬────────────┬──────────────────────────────────┐
│ 偏移     │ 长度     │ 字段       │ 说明                             │
├──────────┼──────────┼────────────┼──────────────────────────────────┤
│ 0        │ 2        │ 魔数       │ 0x55AA（帧同步）                 │
│ 2        │ 1        │ 版本       │ 0x01                            │
│ 3        │ 1        │ 设备类型   │ 0x20=实验室记录仪               │
│ 4        │ 4        │ 设备ID     │ 唯一标识（MAC后4字节或自编）     │
│ 8        │ 4        │ 序列号     │ 设备内递增，用于去重             │
│ 12       │ 4        │ 温度       │ IEEE754 float, ℃                │
│ 16       │ 4        │ 湿度       │ IEEE754 float, %RH              │
│ 20       │ 2        │ 状态字     │ Bit0=正常, Bit1=低温告警...     │
│ 22       │ 4        │ 时间戳     │ Unix时间戳（设备RTC）            │
│ 26       │ 2        │ CRC16      │ 校验（含魔数到时间戳全部字节）    │
│ 总计     │ 28字节   │            │                                  │
└──────────┴──────────┴────────────┴──────────────────────────────────┘

// 设备固件中的UDP发送代码（伪代码）
void send_env_udp(void) {
    static uint32_t seq = 0;
    env_packet_t pkt;

    pkt.magic = 0x55AA;
    pkt.version = 0x01;
    pkt.dev_type = 0x20;
    pkt.dev_id = get_dev_id();  // 从Flash或MAC获取
    pkt.seq = seq++;
    pkt.temp = read_temperature();
    pkt.humi = read_humidity();
    pkt.status = get_status();
    pkt.timestamp = get_rtc_unix();
    pkt.crc = crc16((uint8_t*)&pkt, 26);

    // 发送到组播地址（实验室网络推荐组播而非广播）
    udp_send(&pkt, sizeof(pkt),
              MCAST_IP,  // 239.255.2.100
              MCAST_PORT // 9100
    );
}

┌────────────────────────────────────────────────────────────┐
│ udp_recv (单进程，事件驱动)                               │
│                                                            │
│  ┌─────────────┐    ┌──────────────┐    ┌──────────────┐ │
│  │ UDP接收线程  │───▶│ 解析/去重    │───▶│ 会话路由     │ │
│  │ (非阻塞IO)  │    │ (CRC+序列号) │    │ (dev→session)│ │
│  └─────────────┘    └──────────────┘    └──────┬───────┘ │
│                                                  │         │
│  ┌─────────────┐    ┌──────────────┐           │         │
│  │ HTTP API    │◀───│ 查询/导出    │◀──────────┘         │
│  │ (内置)      │    │ (SQLite)     │                     │
│  └─────────────┘    └──────────────┘                     │
│                                                            │
│  ┌─────────────┐                                          │
│  │ 会话管理    │  实验开始→创建session→绑定设备           │
│  │ (内存表)    │  实验结束→关闭session→导出数据           │
│  └─────────────┘                                          │
└────────────────────────────────────────────────────────────┘

// session.h
#ifndef SESSION_H
#define SESSION_H

#include <stdint.h>
#include <time.h>

#define MAX_DEVICES_PER_SESSION  32
#define MAX_SESSIONS             16
#define DEV_ID_LEN               8

typedef struct {
    uint32_t dev_id;
    char     dev_label[32];      // 用户自定义标签，如"温箱#3-上层"
    uint32_t last_seq;           // 去重：上次收到的序列号
    time_t   last_recv_time;     // 最后收到数据的时间
    int      active;             // 是否活跃
} device_slot_t;

typedef struct {
    uint32_t session_id;
    char     session_name[64];   // 实验名称，如"高温老化-20250115"
    char     operator_name[32];  // 操作人
    time_t   start_time;
    time_t   end_time;
    int      active;             // 1=进行中, 0=已结束
    int      device_count;
    device_slot_t devices[MAX_DEVICES_PER_SESSION];
    char     db_path[256];       // 该session对应的SQLite文件路径
} session_t;

#endif

// udp_recv.c
#include <arpa/inet.h>
#include <fcntl.h>
#include <netinet/in.h>
#include <pthread.h>
#include <sqlite3.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <sys/socket.h>
#include <unistd.h>
#include "session.h"

#define LISTEN_PORT     9100
#define BUF_SIZE        1024
#define MAX_PACKETS     1000000

// 全局状态
static session_t sessions[MAX_SESSIONS];
static int session_count = 0;
static pthread_mutex_t sessions_mutex = PTHREAD_MUTEX_INITIALIZER;
static sqlite3 *current_db = NULL;  // 当前活跃session的数据库

// UDP报文结构
#pragma pack(push, 1)
typedef struct {
    uint16_t magic;
    uint8_t  version;
    uint8_t  dev_type;
    uint32_t dev_id;
    uint32_t seq;
    float    temp;
    float    humi;
    uint16_t status;
    uint32_t timestamp;
    uint16_t crc;
} env_packet_t;
#pragma pack(pop)

// CRC16-CCITT
static uint16_t crc16_ccitt(const uint8_t *data, size_t len) {
    uint16_t crc = 0xFFFF;
    for (size_t i = 0; i < len; i++) {
        crc ^= (uint16_t)data[i] << 8;
        for (int j = 0; j < 8; j++) {
            if (crc & 0x8000)
                crc = (crc << 1) ^ 0x1021;
            else
                crc <<= 1;
        }
    }
    return crc & 0xFFFF;
}

// 查找设备所在的session
static session_t *find_session_for_device(uint32_t dev_id) {
    for (int i = 0; i < session_count; i++) {
        if (!sessions[i].active) continue;
        for (int j = 0; j < sessions[i].device_count; j++) {
            if (sessions[i].devices[j].dev_id == dev_id)
                return &sessions[i];
        }
    }
    return NULL;
}

// 初始化SQLite数据库（新session）
static int init_session_db(session_t *sess) {
    char db_name[256];
    snprintf(db_name, sizeof(db_name),
             "/var/lib/udp_recv/%s_%lu.db",
             sess->session_name, (unsigned long)sess->start_time);
    strncpy(sess->db_path, db_name, sizeof(sess->db_path) - 1);

    if (current_db) {
        sqlite3_close(current_db);
    }

    if (sqlite3_open(db_name, &current_db) != SQLITE_OK) {
        fprintf(stderr, "Cannot open database: %s\n", sqlite3_errmsg(current_db));
        return -1;
    }

    const char *sql =
        "CREATE TABLE IF NOT EXISTS env_data ("
        "  id INTEGER PRIMARY KEY AUTOINCREMENT,"
        "  dev_id INTEGER,"
        "  dev_label TEXT,"
        "  timestamp INTEGER,"
        "  temp REAL,"
        "  humi REAL,"
        "  status INTEGER,"
        "  seq INTEGER,"
        "  received_at INTEGER"
        ");"
        "CREATE INDEX IF NOT EXISTS idx_timestamp ON env_data(timestamp);"
        "CREATE INDEX IF NOT EXISTS idx_dev_id ON env_data(dev_id);";

    char *errmsg = NULL;
    if (sqlite3_exec(current_db, sql, NULL, NULL, &errmsg) != SQLITE_OK) {
        fprintf(stderr, "SQL error: %s\n", errmsg);
        sqlite3_free(errmsg);
        return -1;
    }

    printf("Session DB created: %s\n", db_name);
    return 0;
}

// 写入数据到SQLite
static int write_to_db(session_t *sess, device_slot_t *dev,
                       env_packet_t *pkt, time_t received_at) {
    if (!current_db) return -1;

    sqlite3_stmt *stmt;
    const char *sql =
        "INSERT INTO env_data (dev_id, dev_label, timestamp, temp, humi, status, seq, received_at) "
        "VALUES (?, ?, ?, ?, ?, ?, ?, ?)";

    if (sqlite3_prepare_v2(current_db, sql, -1, &stmt, NULL) != SQLITE_OK) {
        return -1;
    }

    sqlite3_bind_int(stmt, 1, pkt->dev_id);
    sqlite3_bind_text(stmt, 2, dev->dev_label, -1, SQLITE_STATIC);
    sqlite3_bind_int(stmt, 3, pkt->timestamp);
    sqlite3_bind_double(stmt, 4, pkt->temp);
    sqlite3_bind_double(stmt, 5, pkt->humi);
    sqlite3_bind_int(stmt, 6, pkt->status);
    sqlite3_bind_int(stmt, 7, pkt->seq);
    sqlite3_bind_int(stmt, 8, (int)received_at);

    int rc = sqlite3_step(stmt);
    sqlite3_finalize(stmt);

    return (rc == SQLITE_DONE) ? 0 : -1;
}

// 创建新session（通过命令行或HTTP API调用）
int create_session(const char *name, const char *operator,
                   uint32_t *dev_ids, int dev_count, char **labels) {
    pthread_mutex_lock(&sessions_mutex);

    if (session_count >= MAX_SESSIONS) {
        pthread_mutex_unlock(&sessions_mutex);
        return -1;
    }

    session_t *sess = &sessions[session_count];
    memset(sess, 0, sizeof(session_t));
    sess->session_id = session_count + 1;
    strncpy(sess->session_name, name, sizeof(sess->session_name) - 1);
    strncpy(sess->operator_name, operator, sizeof(sess->operator_name) - 1);
    sess->start_time = time(NULL);
    sess->active = 1;
    sess->device_count = dev_count;

    for (int i = 0; i < dev_count && i < MAX_DEVICES_PER_SESSION; i++) {
        sess->devices[i].dev_id = dev_ids[i];
        sess->devices[i].active = 1;
        if (labels && labels[i])
            strncpy(sess->devices[i].dev_label, labels[i],
                    sizeof(sess->devices[i].dev_label) - 1);
    }

    session_count++;
    pthread_mutex_unlock(&sessions_mutex);

    // 初始化数据库
    init_session_db(sess);

    printf("Session created: %s (ID=%u, devices=%d)\n",
           name, sess->session_id, dev_count);
    return sess->session_id;
}

// 关闭session
int close_session(int session_id) {
    pthread_mutex_lock(&sessions_mutex);

    for (int i = 0; i < session_count; i++) {
        if (sessions[i].session_id == session_id && sessions[i].active) {
            sessions[i].active = 0;
            sessions[i].end_time = time(NULL);
            printf("Session closed: %s (duration: %lds)\n",
                   sessions[i].session_name,
                   sessions[i].end_time - sessions[i].start_time);

            // 关闭数据库
            if (current_db) {
                sqlite3_close(current_db);
                current_db = NULL;
            }
            pthread_mutex_unlock(&sessions_mutex);
            return 0;
        }
    }

    pthread_mutex_unlock(&sessions_mutex);
    return -1;
}

// UDP接收主循环
static void *udp_receive_loop(void *arg) {
    int sockfd;
    struct sockaddr_in servaddr, cliaddr;
    socklen_t len = sizeof(cliaddr);
    char buffer[BUF_SIZE];

    // 创建UDP socket
    if ((sockfd = socket(AF_INET, SOCK_DGRAM, 0)) < 0) {
        perror("socket creation failed");
        pthread_exit(NULL);
    }

    // 设置SO_REUSEADDR
    int reuse = 1;
    setsockopt(sockfd, SOL_SOCKET, SO_REUSEADDR, &reuse, sizeof(reuse));

    // 增大接收缓冲区
    int rcvbuf = 16 * 1024 * 1024;  // 16MB
    setsockopt(sockfd, SOL_SOCKET, SO_RCVBUF, &rcvbuf, sizeof(rcvbuf));

    memset(&servaddr, 0, sizeof(servaddr));
    servaddr.sin_family = AF_INET;
    servaddr.sin_addr.s_addr = INADDR_ANY;
    servaddr.sin_port = htons(LISTEN_PORT);

    if (bind(sockfd, (const struct sockaddr *)&servaddr, sizeof(servaddr)) < 0) {
        perror("bind failed");
        close(sockfd);
        pthread_exit(NULL);
    }

    printf("UDP receiver listening on port %d\n", LISTEN_PORT);

    while (1) {
        int n = recvfrom(sockfd, buffer, BUF_SIZE, 0,
                         (struct sockaddr *)&cliaddr, &len);
        if (n < sizeof(env_packet_t)) {
            continue;  // 报文太短，丢弃
        }

        env_packet_t *pkt = (env_packet_t *)buffer;

        // 验证魔数
        if (pkt->magic != 0x55AA) {
            continue;
        }

        // CRC校验
        uint16_t calc_crc = crc16_ccitt((uint8_t *)pkt,
                                         sizeof(env_packet_t) - 2);
        if (calc_crc != pkt->crc) {
            continue;  // CRC错误，丢弃
        }

        // 查找该设备所属的session
        pthread_mutex_lock(&sessions_mutex);
        session_t *sess = find_session_for_device(pkt->dev_id);
        if (!sess) {
            pthread_mutex_unlock(&sessions_mutex);
            continue;  // 设备未绑定到任何session，丢弃
        }

        // 查找设备槽位
        device_slot_t *dev = NULL;
        for (int i = 0; i < sess->device_count; i++) {
            if (sess->devices[i].dev_id == pkt->dev_id) {
                dev = &sess->devices[i];
                break;
            }
        }

        if (!dev) {
            pthread_mutex_unlock(&sessions_mutex);
            continue;
        }

        // 去重（序列号检查）
        if (dev->last_seq == pkt->seq) {
            pthread_mutex_unlock(&sessions_mutex);
            continue;  // 重复包，丢弃
        }

        dev->last_seq = pkt->seq;
        dev->last_recv_time = time(NULL);
        pthread_mutex_unlock(&sessions_mutex);

        // 写入数据库
        time_t now = time(NULL);
        write_to_db(sess, dev, pkt, now);

        // 控制台输出（可选，生产环境可关闭）
        printf("[%u] dev=%08X temp=%.1f humi=%.1f seq=%u\n",
               (unsigned)sess->session_id, pkt->dev_id,
               pkt->temp, pkt->humi, pkt->seq);
    }

    close(sockfd);
    return NULL;
}

// HTTP API线程（轻量实现，使用libmicrohttpd）
#ifdef ENABLE_HTTP
#include <microhttpd.h>

static enum MHD_Result http_handler(void *cls, struct MHD_Connection *connection,
                                     const char *url, const char *method,
                                     const char *version, const char *upload_data,
                                     size_t *upload_data_size, void **con_cls) {
    // 处理API请求：
    // GET  /api/sessions          - 列出所有session
    // POST /api/sessions          - 创建新session
    // POST /api/sessions/{id}/close - 关闭session
    // GET  /api/sessions/{id}/data - 查询数据
    // GET  /api/sessions/{id}/export - 导出CSV

    // 具体实现略...
    return MHD_YES;
}
#endif

int main(int argc, char *argv[]) {
    printf("UDP Environment Data Receiver v1.0\n");
    printf("=====================================\n");

    // 创建数据目录
    system("mkdir -p /var/lib/udp_recv");

    // 启动UDP接收线程
    pthread_t udp_thread;
    pthread_create(&udp_thread, NULL, udp_receive_loop, NULL);

#ifdef ENABLE_HTTP
    // 启动HTTP服务器
    struct MHD_Daemon *httpd = MHD_start_daemon(
        MHD_USE_THREAD_PER_CONNECTION, 8080, NULL, NULL,
        &http_handler, NULL, MHD_OPTION_END);
    printf("HTTP API listening on port 8080\n");
#endif

    // 如果命令行指定了session，自动创建
    if (argc > 3) {
        // ./udp_recv "实验名称" "操作人" dev_id1,dev_id2,...
        // 解析参数并创建session
    }

    printf("Server running. Press Ctrl+C to stop.\n");

    // 等待信号
    while (1) {
        sleep(1);
    }

    return 0;
}

# 编译（需要SQLite3和可选的libmicrohttpd）
gcc -O2 -pthread -o udp_recv udp_recv.c -lsqlite3 -lmicrohttpd -DENABLE_HTTP

# 安装
cp udp_recv /usr/local/bin/
mkdir -p /var/lib/udp_recv
chmod 755 /usr/local/bin/udp_recv

# systemd服务文件
cat > /etc/systemd/system/udp-recv.service << 'EOF'
[Unit]
Description=UDP Environment Data Receiver
After=network.target

[Service]
Type=simple
ExecStart=/usr/local/bin/udp_recv
Restart=always
RestartSec=5
User=nobody
Group=nogroup
LimitNOFILE=65536

[Install]
WantedBy=multi-user.target
EOF

systemctl daemon-reload
systemctl enable udp-recv
systemctl start udp-recv

curl -X POST http://localhost:8080/api/sessions \
  -H "Content-Type: application/json" \
  -d '{
    "name": "高温老化-20250115",
    "operator": "张三",
    "devices": [
      {"id": 0x00000041, "label": "温箱#1-上层"},
      {"id": 0x00000042, "label": "温箱#1-下层"},
      {"id": 0x00000043, "label": "恒温槽#2"}
    ]
  }'

curl "http://localhost:8080/api/sessions/1/data?start=1700000000&end=1700086400&dev_id=0x00000041"

{
  "session": "高温老化-20250115",
  "device": "温箱#1-上层",
  "count": 2880,
  "data": [
    {"ts": 1700000000, "temp": 85.2, "humi": 45.0, "status": 1},
    {"ts": 1700000005, "temp": 85.3, "humi": 45.1, "status": 1}
  ]
}

curl "http://localhost:8080/api/sessions/1/export" > experiment_data.csv

timestamp,device,temperature,humidity,status
2025-01-15T08:00:00,温箱#1-上层,85.2,45.0,1
2025-01-15T08:00:05,温箱#1-上层,85.3,45.1,1
2025-01-15T08:00:10,温箱#1-上层,85.2,44.9,1

<!-- 内嵌在HTTP服务器中，访问 http://server:8080/ 即可 -->
<!DOCTYPE html>
<html>
<head>
<title>实验室环境监测</title>
<meta charset="utf-8">
<style>
body { font-family: Arial, sans-serif; margin: 20px; }
.session { border: 1px solid #ddd; padding: 15px; margin: 10px 0; }
.active { border-color: #4CAF50; }
.data-table { width: 100%; border-collapse: collapse; }
.data-table th, .data-table td { border: 1px solid #ddd; padding: 8px; }
.data-table th { background: #f2f2f2; }
.chart { width: 100%; height: 300px; }
</style>
</head>
<body>
<h1>实验室环境监测</h1>
<div id="sessions"></div>
<div id="chart"></div>

<script>
// 从API加载数据并绘制简单图表
fetch('/api/sessions')
  .then(r => r.json())
  .then(data => {
    const div = document.getElementById('sessions');
    data.sessions.forEach(s => {
      const cls = s.active ? 'session active' : 'session';
      div.innerHTML += `<div class="${cls}">
        <h3>${s.name}</h3>
        <p>操作人: ${s.operator}</p>
        <p>设备数: ${s.device_count}</p>
        <p>状态: ${s.active ? '进行中' : '已结束'}</p>
        <button onclick="exportCSV(${s.id})">导出CSV</button>
      </div>`;
    });
  });

function exportCSV(id) {
  window.open(`/api/sessions/${id}/export`);
}
</script>
</body>
</html>

场景：30台设备，每5秒上报一次

CPU:
  UDP接收: ~0.5% (单核)
  数据库写入: ~0.3% (批量提交)
  HTTP服务: ~0.2% (空闲时)
  总计: < 2%

内存:
  程序代码: ~2MB
  Session数据: ~4KB × 16 sessions = 64KB
  SQLite缓存: ~2MB (默认page_cache)
  总计: < 30MB

磁盘:
  单条记录: ~40字节 (SQLite行)
  30设备 × 每5秒1条 × 3600秒 = 21600条/小时 = ~840KB/小时
  24小时实验: ~20MB

# 查看UDP接收统计
cat /proc/net/udp

# 抓包验证
tcpdump -i eth0 udp port 9100 -vv

# 查看SQLite数据库内容
sqlite3 /var/lib/udp_recv/experiment.db
.tables
SELECT * FROM env_data LIMIT 10;

# 查看服务状态
systemctl status udp-recv
journalctl -u udp-recv -f
