021_具身人工智能的安全开发生命周期与风险管理：从设计到部署的全流程保障

# 具身AI系统安全需求规格示例
class EmbodiedAISecurityRequirements:
    def __init__(self, project_name):
        """
        初始化具身AI系统安全需求规格
        参数:
            project_name: 项目名称
        """
        self.project_name = project_name
        self.version = "1.0"
        self.created_date = "2025-04-15"
        self.last_updated = "2025-04-15"
        self.document_status = "Draft"
        self.author = "安全需求团队"

        # 安全需求分类
        self.functional_safety = []
        self.information_security = []
        self.human_machine_safety = []
        self.environmental_safety = []
        self.compliance_requirements = []

        # 安全约束
        self.security_constraints = []

        # 风险评估结果
        self.risk_assessment = {}

        # 验收标准
        self.acceptance_criteria = []

    def add_functional_safety_requirement(self, req_id, title, description, priority, verification_method):
        """
        添加功能安全需求
        参数:
            req_id: 需求ID
            title: 需求标题
            description: 需求描述
            priority: 优先级 (Critical, High, Medium, Low)
            verification_method: 验证方法
        """
        requirement = {
            "id": req_id,
            "title": title,
            "description": description,
            "priority": priority,
            "verification_method": verification_method,
            "status": "Not Implemented"
        }
        self.functional_safety.append(requirement)

    def add_information_security_requirement(self, req_id, title, description, priority, verification_method):
        """
        添加信息安全需求
        """
        requirement = {
            "id": req_id,
            "title": title,
            "description": description,
            "priority": priority,
            "verification_method": verification_method,
            "status": "Not Implemented"
        }
        self.information_security.append(requirement)

    def add_human_machine_safety_requirement(self, req_id, title, description, priority, verification_method):
        """
        添加人机安全需求
        """
        requirement = {
            "id": req_id,
            "title": title,
            "description": description,
            "priority": priority,
            "verification_method": verification_method,
            "status": "Not Implemented"
        }
        self.human_machine_safety.append(requirement)

    def add_environmental_safety_requirement(self, req_id, title, description, priority, verification_method):
        """
        添加环境安全需求
        """
        requirement = {
            "id": req_id,
            "title": title,
            "description": description,
            "priority": priority,
            "verification_method": verification_method,
            "status": "Not Implemented"
        }
        self.environmental_safety.append(requirement)

    def add_compliance_requirement(self, req_id, title, description, standard_ref, priority):
        """
        添加合规性需求
        参数:
            req_id: 需求ID
            title: 需求标题
            description: 需求描述
            standard_ref: 标准引用
            priority: 优先级
        """
        requirement = {
            "id": req_id,
            "title": title,
            "description": description,
            "standard_reference": standard_ref,
            "priority": priority,
            "status": "Not Verified"
        }
        self.compliance_requirements.append(requirement)

    def add_security_constraint(self, constraint_id, description, impact, mitigation):
        """
        添加安全约束
        """
        constraint = {
            "id": constraint_id,
            "description": description,
            "impact": impact,
            "mitigation": mitigation
        }
        self.security_constraints.append(constraint)

    def set_risk_assessment(self, risk_id, asset, threat, vulnerability, impact, likelihood, risk_level, mitigation):
        """
        设置风险评估结果
        """
        if risk_id not in self.risk_assessment:
            self.risk_assessment[risk_id] = {}

        self.risk_assessment[risk_id] = {
            "asset": asset,
            "threat": threat,
            "vulnerability": vulnerability,
            "impact": impact,
            "likelihood": likelihood,
            "risk_level": risk_level,
            "mitigation": mitigation,
            "status": "Identified"
        }

    def add_acceptance_criterion(self, criterion_id, description, test_method, passing_standard):
        """
        添加验收标准
        """
        criterion = {
            "id": criterion_id,
            "description": description,
            "test_method": test_method,
            "passing_standard": passing_standard
        }
        self.acceptance_criteria.append(criterion)

    def generate_requirements_summary(self):
        """
        生成需求摘要报告
        """
        summary = {
            "project_info": {
                "name": self.project_name,
                "version": self.version,
                "status": self.document_status,
                "last_updated": self.last_updated
            },
            "requirements_count": {
                "functional_safety": len(self.functional_safety),
                "information_security": len(self.information_security),
                "human_machine_safety": len(self.human_machine_safety),
                "environmental_safety": len(self.environmental_safety),
                "compliance": len(self.compliance_requirements),
                "total": (len(self.functional_safety) + len(self.information_security) +
                          len(self.human_machine_safety) + len(self.environmental_safety) +
                          len(self.compliance_requirements))
            },
            "constraints_count": len(self.security_constraints),
            "risks_count": len(self.risk_assessment),
            "acceptance_criteria_count": len(self.acceptance_criteria)
        }

        # 统计各优先级需求数量
        priority_counts = {"Critical": 0, "High": 0, "Medium": 0, "Low": 0}

        all_requirements = (self.functional_safety + self.information_security +
                           self.human_machine_safety + self.environmental_safety +
                           self.compliance_requirements)

        for req in all_requirements:
            if "priority" in req and req["priority"] in priority_counts:
                priority_counts[req["priority"]] += 1

        summary["priority_distribution"] = priority_counts

        return summary

# 使用示例
def create_security_requirements_example():
    # 创建安全需求规格实例
    security_reqs = EmbodiedAISecurityRequirements("医疗辅助机器人系统")

    # 添加功能安全需求
    security_reqs.add_functional_safety_requirement(
        "FS-001",
        "紧急停止功能",
        "系统必须在任何情况下响应紧急停止指令，响应时间不超过100ms",
        "Critical",
        "功能测试、响应时间测量"
    )

    security_reqs.add_functional_safety_requirement(
        "FS-002",
        "碰撞检测与防护",
        "系统必须能够检测到与人类或障碍物的潜在碰撞，并立即采取防护措施",
        "Critical",
        "碰撞测试、场景模拟"
    )

    # 添加信息安全需求
    security_reqs.add_information_security_requirement(
        "IS-001",
        "患者数据加密",
        "所有患者数据必须使用AES-256加密算法进行加密存储和传输",
        "High",
        "加密强度测试、渗透测试"
    )

    security_reqs.add_information_security_requirement(
        "IS-002",
        "访问控制",
        "系统必须实施基于角色的访问控制，确保只有授权人员能够访问敏感功能",
        "High",
        "访问控制测试、权限验证"
    )

    # 添加人机安全需求
    security_reqs.add_human_machine_safety_requirement(
        "HMS-001",
        "人机交互安全",
        "系统在执行任务时必须保持安全的人机交互距离，默认最小距离为50cm",
        "Critical",
        "距离测量、交互测试"
    )

    # 添加环境安全需求
    security_reqs.add_environmental_safety_requirement(
        "ES-001",
        "异常环境检测",
        "系统必须能够检测异常环境条件（如火灾、气体泄漏）并采取相应安全措施",
        "Medium",
        "环境模拟测试"
    )

    # 添加合规性需求
    security_reqs.add_compliance_requirement(
        "CMP-001",
        "医疗设备安全标准",
        "系统设计必须符合ISO 14971医疗设备风险管理标准",
        "ISO 14971:2019",
        "Critical"
    )

    # 添加安全约束
    security_reqs.add_security_constraint(
        "SC-001",
        "实时性约束",
        "安全功能必须在100ms内响应，可能限制某些复杂安全算法的使用",
        "采用硬件加速和优化算法确保实时响应"
    )

    # 设置风险评估
    security_reqs.set_risk_assessment(
        "RISK-001",
        "机械臂执行器",
        "未检测到的障碍物导致碰撞",
        "传感器覆盖不足或故障",
        "人员受伤、设备损坏",
        "Medium",
        "High",
        "实施冗余传感器系统、边界检测算法、速度限制"
    )

    # 添加验收标准
    security_reqs.add_acceptance_criterion(
        "AC-001",
        "紧急停止功能测试",
        "在各种操作场景下测试紧急停止按钮的响应时间",
        "100%测试场景中响应时间<100ms"
    )

    # 生成需求摘要
    summary = security_reqs.generate_requirements_summary()
    print(f"项目: {summary['project_info']['name']}")
    print(f"总需求数: {summary['requirements_count']['total']}")
    print(f"优先级分布: {summary['priority_distribution']}")

    return security_reqs

# 具身AI系统安全监控框架示例
class EmbodiedAISecurityMonitoringSystem:
    def __init__(self, system_id, config):
        """
        初始化安全监控系统
        参数:
            system_id: 被监控系统的ID
            config: 监控系统配置
        """
        self.system_id = system_id
        self.config = config

        # 监控模块
        self.monitoring_modules = {
            "physical": PhysicalSecurityMonitor(config.get("physical_monitoring", {})),
            "perception": PerceptionSecurityMonitor(config.get("perception_monitoring", {})),
            "control": ControlSecurityMonitor(config.get("control_monitoring", {})),
            "communication": CommunicationSecurityMonitor(config.get("communication_monitoring", {})),
            "system": SystemSecurityMonitor(config.get("system_monitoring", {}))
        }

        # 告警管理器
        self.alert_manager = AlertManager(config.get("alert_config", {}))

        # 事件记录器
        self.event_logger = SecurityEventLogger(config.get("logging_config", {}))

        # 安全分析器
        self.security_analyzer = SecurityAnalyzer(config.get("analysis_config", {}))

        # 监控状态
        self.monitoring_status = {
            "overall_status": "stopped",
            "module_statuses": {},
            "last_update": None,
            "active_alerts": 0,
            "security_score": 100.0
        }

        # 历史数据存储
        self.history = {
            "events": [],
            "alerts": [],
            "security_scores": []
        }

    def start_monitoring(self):
        """
        启动安全监控
        """
        # 启动所有监控模块
        for module_name, module in self.monitoring_modules.items():
            module.start()
            self.monitoring_status["module_statuses"][module_name] = "running"

        # 更新整体状态
        self.monitoring_status["overall_status"] = "running"
        self.monitoring_status["last_update"] = self._get_current_timestamp()

        # 记录启动事件
        self._log_system_event("monitoring_started", {
            "system_id": self.system_id,
            "timestamp": self.monitoring_status["last_update"]
        })

        return self.monitoring_status

    def stop_monitoring(self):
        """
        停止安全监控
        """
        # 停止所有监控模块
        for module_name, module in self.monitoring_modules.items():
            module.stop()
            self.monitoring_status["module_statuses"][module_name] = "stopped"

        # 更新整体状态
        self.monitoring_status["overall_status"] = "stopped"
        self.monitoring_status["last_update"] = self._get_current_timestamp()

        # 记录停止事件
        self._log_system_event("monitoring_stopped", {
            "system_id": self.system_id,
            "timestamp": self.monitoring_status["last_update"]
        })

        return self.monitoring_status

    def collect_metrics(self):
        """
        收集所有模块的监控指标
        """
        metrics = {}

        # 从各模块收集指标
        for module_name, module in self.monitoring_modules.items():
            if self.monitoring_status["module_statuses"].get(module_name) == "running":
                module_metrics = module.collect_metrics()
                metrics[module_name] = module_metrics

        # 更新最后更新时间
        self.monitoring_status["last_update"] = self._get_current_timestamp()

        return metrics

    def analyze_security_state(self):
        """
        分析系统整体安全状态
        """
        # 收集最新指标
        metrics = self.collect_metrics()

        # 分析安全状态
        analysis_result = self.security_analyzer.analyze(metrics)

        # 更新安全分数
        self.monitoring_status["security_score"] = analysis_result.get("security_score", 100.0)

        # 处理检测到的异常
        anomalies = analysis_result.get("anomalies", [])
        for anomaly in anomalies:
            # 创建告警
            alert = self._create_alert(anomaly)
            self.alert_manager.process_alert(alert)

            # 记录告警
            self.history["alerts"].append(alert)

        # 更新活跃告警数量
        self.monitoring_status["active_alerts"] = self.alert_manager.get_active_alerts_count()

        # 保存历史安全分数
        self.history["security_scores"].append({
            "timestamp": self.monitoring_status["last_update"],
            "score": self.monitoring_status["security_score"]
        })

        return {
            "security_state": self.monitoring_status,
            "analysis_result": analysis_result,
            "anomalies": anomalies,
            "timestamp": self.monitoring_status["last_update"]
        }

    def _create_alert(self, anomaly):
        """
        根据异常创建告警
        """
        severity_mapping = {
            "critical": "critical",
            "high": "high",
            "medium": "medium",
            "low": "low"
        }

        severity = severity_mapping.get(anomaly.get("severity"), "medium")

        alert = {
            "alert_id": f"ALERT-{self.system_id}-{self._get_current_timestamp()}",
            "system_id": self.system_id,
            "timestamp": self._get_current_timestamp(),
            "source": anomaly.get("source", "unknown"),
            "type": anomaly.get("type", "security_anomaly"),
            "severity": severity,
            "description": anomaly.get("description", "Detected security anomaly"),
            "details": anomaly.get("details", {}),
            "recommended_actions": anomaly.get("recommended_actions", []),
            "status": "new"
        }

        return alert

    def respond_to_alert(self, alert_id, action):
        """
        响应告警
        参数:
            alert_id: 告警ID
            action: 采取的行动
        """
        # 更新告警状态
        response_result = self.alert_manager.update_alert(alert_id, {
            "status": "responded",
            "action_taken": action,
            "response_timestamp": self._get_current_timestamp()
        })

        # 记录响应事件
        self._log_system_event("alert_responded", {
            "alert_id": alert_id,
            "action": action,
            "timestamp": self._get_current_timestamp()
        })

        return response_result

    def generate_security_report(self, time_range=None):
        """
        生成安全报告
        参数:
            time_range: 可选的时间范围
        """
        # 分析当前安全状态
        current_analysis = self.analyze_security_state()

        # 过滤历史数据（如果提供了时间范围）
        if time_range:
            filtered_events = [event for event in self.history["events"]
                              if time_range["start"] <= event["timestamp"] <= time_range["end"]]
            filtered_alerts = [alert for alert in self.history["alerts"]
                             if time_range["start"] <= alert["timestamp"] <= time_range["end"]]
            filtered_scores = [score for score in self.history["security_scores"]
                              if time_range["start"] <= score["timestamp"] <= time_range["end"]]
        else:
            filtered_events = self.history["events"]
            filtered_alerts = self.history["alerts"]
            filtered_scores = self.history["security_scores"]

        # 统计告警数据
        alert_stats = {
            "total": len(filtered_alerts),
            "by_severity": {
                "critical": len([a for a in filtered_alerts if a["severity"] == "critical"]),
                "high": len([a for a in filtered_alerts if a["severity"] == "high"]),
                "medium": len([a for a in filtered_alerts if a["severity"] == "medium"]),
                "low": len([a for a in filtered_alerts if a["severity"] == "low"])
            },
            "by_source": {}
        }

        # 按来源统计告警
        for alert in filtered_alerts:
            source = alert.get("source", "unknown")
            if source not in alert_stats["by_source"]:
                alert_stats["by_source"][source] = 0
            alert_stats["by_source"][source] += 1

        # 计算平均安全分数
        if filtered_scores:
            avg_security_score = sum(s["score"] for s in filtered_scores) / len(filtered_scores)
        else:
            avg_security_score = 100.0

        # 生成报告
        report = {
            "report_id": f"REPORT-{self.system_id}-{self._get_current_timestamp()}",
            "system_id": self.system_id,
            "generated_at": self._get_current_timestamp(),
            "time_range": time_range,
            "current_security_status": current_analysis["security_state"],
            "current_anomalies": current_analysis["anomalies"],
            "alert_statistics": alert_stats,
            "event_count": len(filtered_events),
            "average_security_score": avg_security_score,
            "trending": self._analyze_trending(filtered_scores),
            "recommendations": self._generate_recommendations(filtered_alerts, avg_security_score)
        }

        return report

    def _analyze_trending(self, security_scores):
        """
        分析安全分数趋势
        """
        if len(security_scores) < 2:
            return "insufficient_data"

        # 按时间排序
        sorted_scores = sorted(security_scores, key=lambda x: x["timestamp"])

        # 计算趋势
        oldest_score = sorted_scores[0]["score"]
        newest_score = sorted_scores[-1]["score"]

        change_percentage = ((newest_score - oldest_score) / oldest_score) * 100

        if change_percentage > 5:
            return "improving"
        elif change_percentage < -5:
            return "declining"
        else:
            return "stable"

    def _generate_recommendations(self, alerts, avg_score):
        """
        生成安全改进建议
        """
        recommendations = []

        # 基于告警严重性生成建议
        critical_alerts = [a for a in alerts if a["severity"] == "critical"]
        if critical_alerts:
            recommendations.append({
                "priority": "high",
                "area": "critical_incident_response",
                "description": "需要立即调查和解决所有严重级别的安全事件",
                "details": [f"告警ID: {a['alert_id']}, 类型: {a['type']}" for a in critical_alerts[:3]]
            })

        # 基于平均安全分数生成建议
        if avg_score < 70:
            recommendations.append({
                "priority": "high",
                "area": "overall_security_improvement",
                "description": "系统安全分数低于阈值，需要全面安全评估和改进",
                "suggested_actions": [
                    "进行全面的安全审计",
                    "更新安全策略和控制措施",
                    "加强监控和响应机制"
                ]
            })

        # 基于告警来源生成建议
        if alerts:
            # 找出告警最多的来源
            source_counts = {}
            for alert in alerts:
                source = alert.get("source", "unknown")
                source_counts[source] = source_counts.get(source, 0) + 1

            top_source = max(source_counts.items(), key=lambda x: x[1]) if source_counts else None

            if top_source and top_source[1] > len(alerts) * 0.3:  # 如果超过30%的告警来自同一来源
                recommendations.append({
                    "priority": "medium",
                    "area": f"{top_source[0]}_security_improvement",
                    "description": f"来源 {top_source[0]} 产生了过多告警 ({top_source[1]} 次)",
                    "suggested_actions": [
                        f"深入调查 {top_source[0]} 模块的安全问题",
                        "考虑增强监控或更新相关组件"
                    ]
                })

        # 添加常规建议
        recommendations.append({
            "priority": "low",
            "area": "ongoing_maintenance",
            "description": "定期安全维护和更新",
            "suggested_actions": [
                "定期进行安全漏洞扫描",
                "确保所有组件保持最新版本",
                "进行安全意识培训"
            ]
        })

        return recommendations

    def _log_system_event(self, event_type, details):
        """
        记录系统事件
        """
        event = {
            "event_id": f"EVENT-{self.system_id}-{self._get_current_timestamp()}",
            "timestamp": self._get_current_timestamp(),
            "event_type": event_type,
            "details": details
        }

        # 添加到历史记录
        self.history["events"].append(event)

        # 调用事件记录器
        self.event_logger.log_event(event)

    def _get_current_timestamp(self):
        """
        获取当前时间戳
        """
        import datetime
        return datetime.datetime.now().isoformat()

# 监控模块的简化实现
class PhysicalSecurityMonitor:
    def __init__(self, config):
        self.config = config
        self.status = "stopped"
    def start(self):
        self.status = "running"
    def stop(self):
        self.status = "stopped"
    def collect_metrics(self):
        return {"temperature": 45.0, "vibration": 0.02, "power_status": "normal"}

class PerceptionSecurityMonitor:
    def __init__(self, config):
        self.config = config
        self.status = "stopped"
    def start(self):
        self.status = "running"
    def stop(self):
        self.status = "stopped"
    def collect_metrics(self):
        return {"sensor_data_rate": 10.5, "sensor_errors": 0, "perception_latency": 5.2}

class ControlSecurityMonitor:
    def __init__(self, config):
        self.config = config
        self.status = "stopped"
    def start(self):
        self.status = "running"
    def stop(self):
        self.status = "stopped"
    def collect_metrics(self):
        return {"command_execution_time": 3.1, "control_loop_stability": 0.99, "error_rate": 0.0}

class CommunicationSecurityMonitor:
    def __init__(self, config):
        self.config = config
        self.status = "stopped"
    def start(self):
        self.status = "running"
    def stop(self):
        self.status = "stopped"
    def collect_metrics(self):
        return {"data_transfer_rate": 100.2, "encryption_status": "enabled", "connection_count": 5}

class SystemSecurityMonitor:
    def __init__(self, config):
        self.config = config
        self.status = "stopped"
    def start(self):
        self.status = "running"
    def stop(self):
        self.status = "stopped"
    def collect_metrics(self):
        return {"cpu_usage": 35.5, "memory_usage": 42.3, "disk_space": 78.9, "running_processes": 42}

class AlertManager:
    def __init__(self, config):
        self.config = config
        self.alerts = []
    def process_alert(self, alert):
        self.alerts.append(alert)
        # 这里可以添加告警通知逻辑
        return alert
    def update_alert(self, alert_id, updates):
        for alert in self.alerts:
            if alert["alert_id"] == alert_id:
                alert.update(updates)
                return alert
        return None
    def get_active_alerts_count(self):
        return len([a for a in self.alerts if a["status"] == "new" or a["status"] == "investigating"])

class SecurityEventLogger:
    def __init__(self, config):
        self.config = config
    def log_event(self, event):
        # 这里可以实现将事件写入日志存储的逻辑
        print(f"记录安全事件: {event['event_id']} - {event['event_type']}")

class SecurityAnalyzer:
    def __init__(self, config):
        self.config = config
    def analyze(self, metrics):
        # 简化的安全分析逻辑
        anomalies = []
        security_score = 100.0

        # 检查物理安全指标
        if "physical" in metrics:
            physical_metrics = metrics["physical"]
            if physical_metrics["temperature"] > 80.0:
                anomalies.append({
                    "source": "physical",
                    "type": "high_temperature",
                    "severity": "high",
                    "description": "设备温度过高",
                    "details": {"temperature": physical_metrics["temperature"]},
                    "recommended_actions": ["检查冷却系统", "考虑降低负载"]
                })
                security_score -= 15

        # 其他简单检查...

        return {
            "security_score": security_score,
            "anomalies": anomalies,
            "timestamp": self._get_current_timestamp()
        }
    def _get_current_timestamp(self):
        import datetime
        return datetime.datetime.now().isoformat()

# 使用示例
def example_security_monitoring():
    # 配置监控系统
    monitoring_config = {
        "alert_config": {
            "notification_channels": ["email", "sms"],
            "alert_thresholds": {
                "critical": 90,
                "high": 80,
                "medium": 70
            }
        },
        "logging_config": {
            "log_level": "info",
            "retention_days": 90
        }
    }

    # 创建监控系统实例
    monitor = EmbodiedAISecurityMonitoringSystem("robot_arm_001", monitoring_config)

    # 启动监控
    print("启动安全监控...")
    monitor.start_monitoring()

    # 分析安全状态
    print("\n分析安全状态...")
    security_analysis = monitor.analyze_security_state()
    print(f"安全分数: {security_analysis['security_state']['security_score']}")
    print(f"活跃告警: {security_analysis['security_state']['active_alerts']}")

    # 生成安全报告
    print("\n生成安全报告...")
    report = monitor.generate_security_report()
    print(f"报告ID: {report['report_id']}")
    print(f"平均安全分数: {report['average_security_score']:.2f}")
    print(f"趋势: {report['trending']}")

    print("\n安全建议:")
    for i, rec in enumerate(report['recommendations'], 1):
        print(f"{i}. [{rec['priority'].upper()}] {rec['description']}")

    return report
