现代软件架构演进：从单体到云原生 + 代码实战详解

# app.py (Monolith)
from flask import Flask, request, jsonify
import sqlite3

app = Flask(__name__)

def get_db():
    conn = sqlite3.connect('shop.db')
    conn.row_factory = sqlite3.Row
    return conn

@app.route('/users', methods=['POST'])
def create_user():
    data = request.json
    db = get_db()
    db.execute("INSERT INTO users (name, email) VALUES (?, ?)",
               (data['name'], data['email']))
    db.commit()
    return jsonify({"status": "created"}), 201

@app.route('/products')
def list_products():
    db = get_db()
    products = db.execute("SELECT * FROM products").fetchall()
    return jsonify([dict(p) for p in products])

@app.route('/orders', methods=['POST'])
def create_order():
    data = request.json
    db = get_db()
    # 原子性：下单时扣库存（简化版）
    db.execute("UPDATE products SET stock = stock - 1 WHERE id = ?", (data['product_id'],))
    db.execute("INSERT INTO orders (user_id, product_id) VALUES (?, ?)",
               (data['user_id'], data['product_id']))
    db.commit()
    return jsonify({"status": "ordered"}), 201

if __name__ == '__main__':
    app.run(debug=True)

syntax = "proto3";

package product;

service ProductService {
  rpc GetStock(GetStockRequest) returns (GetStockResponse);
  rpc DeductStock(DeductStockRequest) returns (DeductStockResponse);
}

message GetStockRequest { int32 product_id = 1; }
message GetStockResponse { int32 stock = 1; }

message DeductStockRequest { int32 product_id = 1; }
message DeductStockResponse { bool success = 1; }

# order_service.py
from fastapi import FastAPI, HTTPException
import grpc
from product_pb2 import DeductStockRequest
from product_pb2_grpc import ProductServiceStub

app = FastAPI()

@app.post("/orders")
def create_order(user_id: int, product_id: int):
    # 1. 调用 Product Service 扣库存
    with grpc.insecure_channel('product-service:50051') as channel:
        stub = ProductServiceStub(channel)
        resp = stub.DeductStock(DeductStockRequest(product_id=product_id))
        if not resp.success:
            raise HTTPException(status_code=400, detail="Insufficient stock")

    # 2. 本地记录订单（简化，实际应异步或事务补偿）
    # 此处省略数据库操作
    return {"order_id": "123", "status": "created"}

# product_service.py
import grpc
from concurrent import futures
from product_pb2 import DeductStockResponse
from product_pb2_grpc import ProductServiceServicer, add_ProductServiceServicer_to_server
import sqlite3

class ProductServicer(ProductServiceServicer):
    def DeductStock(self, request, context):
        conn = sqlite3.connect('product.db')
        cur = conn.cursor()
        cur.execute("SELECT stock FROM products WHERE id = ?", (request.product_id,))
        row = cur.fetchone()
        if not row or row[0] <= 0:
            return DeductStockResponse(success=False)
        cur.execute("UPDATE products SET stock = stock - 1 WHERE id = ?", (request.product_id,))
        conn.commit()
        return DeductStockResponse(success=True)

server = grpc.server(futures.ThreadPoolExecutor(max_workers=10))
add_ProductServiceServicer_to_server(ProductServicer(), server)
server.add_insecure_port('[::]:50051')
server.start()
server.wait_for_termination()

# Dockerfile for order-service
FROM python:3.11-slim
WORKDIR /app
COPY requirements.txt .
RUN pip install -r requirements.txt
COPY order_service.py .
CMD ["uvicorn", "order_service:app", "--host", "0.0.0.0", "--port", "8000"]

# templates/order-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: order-service
spec:
  replicas: 3
  selector:
    matchLabels:
      app: order-service
  template:
    metadata:
      labels:
        app: order-service
    spec:
      containers:
      - name: order
        image: my-registry/order-service:v1
        ports:
        - containerPort: 8000
        env:
        - name: PRODUCT_SERVICE_ADDR
          value: "product-service:50051"
---
apiVersion: v1
kind: Service
metadata:
  name: order-service
spec:
  selector:
    app: order-service
  ports:
    - protocol: TCP
      port: 8000
      targetPort: 8000

# destination-rule.yaml
apiVersion: networking.istio.io/v1beta1
kind: DestinationRule
metadata:
  name: product-service
spec:
  host: product-service
  trafficPolicy:
    connectionPool:
      tcp: { maxConnections: 100 }
      http: { http1MaxPendingRequests: 10 }
    outlierDetection:
      consecutive5xxErrors: 5
      interval: 30s
      baseEjectionTime: 30s

# order_service_with_metrics.py
from opentelemetry import metrics
from opentelemetry.exporter.prometheus import PrometheusMetricReader
from opentelemetry.sdk.metrics import MeterProvider
from prometheus_client import start_http_server

# 初始化 OpenTelemetry
reader = PrometheusMetricReader()
metrics.set_meter_provider(MeterProvider(metric_readers=[reader]))
meter = metrics.get_meter("order.meter")

# 创建计数器
order_counter = meter.create_counter(
    "orders_created_total",
    description="Total number of orders created"
)

@app.post("/orders")
def create_order(...):
    # ... 扣库存逻辑 ...
    order_counter.add(1, {"product_id": str(product_id)})
    return {"status": "created"}

# HELP orders_created_total Total number of orders created
# TYPE orders_created_total counter
orders_created_total{product_id="101"} 5.0

ecommerce-arch-demo/
├── monolith/
│   └── app.py
├── microservices/
│   ├── user-service/
│   ├── order-service/
│   └── product-service/
├── k8s/
│   ├── order-deployment.yaml
│   └── istio-rules/
└── observability/
    └── otel-config.yaml
