如何设计 AI 驱动的 OPS Agent：技术架构探索

App -depends_on-> Asset
BusinessService -served_by-> App
App -runs_in-> Environment
Case -targets-> {App|Asset|BusinessService}
Plan -implements-> Case
Observation -belongs_to-> {App|Asset|BusinessService}
Incident -correlates-> Observation
Experiment -scopes-> Environment
Verification -verifies-> {Plan|Experiment}

-- 资产与应用
CREATE TABLE assets (
  id BIGSERIAL PRIMARY KEY,
  kind TEXT NOT NULL,
  name TEXT NOT NULL,
  env TEXT NOT NULL,
  owner TEXT,
  labels JSONB DEFAULT '{}',
  spec JSONB,
  created_at TIMESTAMPTZ DEFAULT now(),
  UNIQUE(kind, name, env)
);

CREATE TABLE apps (
  id BIGSERIAL PRIMARY KEY,
  name TEXT NOT NULL,
  version TEXT,
  build_id TEXT,
  deps JSONB,
  created_at TIMESTAMPTZ DEFAULT now(),
  UNIQUE(name, version)
);

CREATE TABLE business_services (
  id BIGSERIAL PRIMARY KEY,
  domain TEXT,
  name TEXT NOT NULL,
  slo JSONB,
  owner TEXT,
  labels JSONB DEFAULT '{}'
);

-- Case / Plan / Execution / Verification
CREATE TABLE cases (
  id BIGSERIAL PRIMARY KEY,
  type TEXT NOT NULL,           -- deploy/change/incident/experiment
  subject_type TEXT NOT NULL,   -- App/Asset/BusinessService
  subject_id BIGINT NOT NULL,
  severity INT,                 -- 0..5
  priority INT,                 -- 0..5
  status TEXT NOT NULL,         -- state machine state
  confidence NUMERIC,           -- 0..1
  risk_score NUMERIC,           -- 0..1
  dedupe_key TEXT,
  created_by TEXT,
  created_at TIMESTAMPTZ DEFAULT now(),
  updated_at TIMESTAMPTZ DEFAULT now(),
  tags TEXT[]
);

CREATE TABLE plans (
  id BIGSERIAL PRIMARY KEY,
  case_id BIGINT REFERENCES cases(id) ON DELETE CASCADE,
  dsl JSONB NOT NULL,           -- Runbook/Plan DSL 编译后 AST
  status TEXT NOT NULL,
  risk JSONB,                   -- 计算明细
  approvals JSONB,
  created_by TEXT,
  created_at TIMESTAMPTZ DEFAULT now()
);

CREATE TABLE executions (
  id BIGSERIAL PRIMARY KEY,
  plan_id BIGINT REFERENCES plans(id) ON DELETE CASCADE,
  step INT NOT NULL,
  adapter TEXT NOT NULL,        -- gitops/k8s/ff/gateway/dbmigrator
  command JSONB NOT NULL,       -- 具体操作参数
  status TEXT NOT NULL,         -- pending/running/success/fail
  retries INT DEFAULT 0,
  started_at TIMESTAMPTZ,
  finished_at TIMESTAMPTZ,
  audit JSONB                   -- 请求/响应摘要、指纹、签名
);

CREATE TABLE verifications (
  id BIGSERIAL PRIMARY KEY,
  case_id BIGINT REFERENCES cases(id) ON DELETE CASCADE,
  gate JSONB NOT NULL,          -- KPI Gate 定义
  window INTERVAL NOT NULL,
  result TEXT,                  -- pass/fail/timeout
  details JSONB,
  created_at TIMESTAMPTZ DEFAULT now()
);

-- 原始指标表作为 hypertable
CREATE TABLE http_metrics (
  ts TIMESTAMPTZ NOT NULL,
  app_id BIGINT NOT NULL,
  route TEXT,
  status_code INT,
  latency_ms DOUBLE PRECISION
);
SELECT create_hypertable('http_metrics', 'ts', if_not_exists => TRUE);

-- 1 分钟 P95 连续聚合
CREATE MATERIALIZED VIEW http_p95_1m
WITH (timescaledb.continuous) AS
SELECT time_bucket('1 minute', ts) AS bucket,
       app_id,
       percentile_cont(0.95) WITHIN GROUP (ORDER BY latency_ms) AS p95
FROM http_metrics
GROUP BY bucket, app_id;

-- Top‑K（最近 5 分钟）
CREATE MATERIALIZED VIEW app_p95_topk_5m
WITH (timescaledb.continuous) AS
SELECT bucket, app_id, p95,
       ROW_NUMBER() OVER (PARTITION BY bucket ORDER BY p95 DESC) AS rk
FROM http_p95_1m
WHERE bucket >= now() - INTERVAL '5 minutes';

-- 创建图
SELECT create_graph('ops');

-- 载入节点/边（示例）
SELECT * FROM cypher('ops', $$
  CREATE (a:App {id:1, name:'payments'})-[:DEPENDS_ON]->(b:Asset {id:42, kind:'postgres'})
$$) as (v agtype);

-- k‑hop 依赖展开
SELECT * FROM cypher('ops', $$
 MATCH (a:App {name:'payments'})-[:DEPENDS_ON*1..3]->(n)
 RETURN n
$$) AS (n agtype);

CREATE EXTENSION IF NOT EXISTS vector;
CREATE TABLE kb_chunks (
  id BIGSERIAL PRIMARY KEY,
  title TEXT,
  doc_url TEXT,
  text TEXT,
  embedding vector(1536),
  tags TEXT[],
  rating INT DEFAULT 0
);
CREATE INDEX ON kb_chunks USING hnsw (embedding vector_cosine_ops);

-- 语义相似检索
SELECT id, title, doc_url
FROM kb_chunks
ORDER BY embedding <#> $1
LIMIT 10;

{
  "case_id": "C-202508-00123",
  "type": "incident",
  "subject": {"type": "App", "id": 1, "name": "payments"},
  "severity": 3,
  "priority": 2,
  "dedupe_key": "payments-5xx-spike",
  "status": "Analyze",
  "evidence": {
    "topk": [{"app_id":1, "p95": 1260}],
    "graph": {"k_hop": [42]},
    "similar": [{"kb_id": 991, "score": 0.83}]
  },
  "ts": "2025-08-27T07:00:00Z"
}

apiVersion: ops/v1
kind: Runbook
metadata:
  name: rollback-payments-to-1.2.3
  labels:
    case: C-202508-00123
spec:
  strategy:
    mode: gitops          # gitops | direct
    autonomy: L2          # L0 提示, L1 需审批, L2 条件自动, L3 全自动
  risk:
    impact: medium
    recoverability: high
    complexity: low
    timeWindow: "22:00-06:00 Asia/Tokyo"
  steps:
    - name: bump-helm-values
      adapter: gitops
      with:
        repo: https://git/repo/payments-infra
        path: charts/payments/values.yaml
        changes:
          image.tag: 1.2.3
      rollback:
        changes:
          image.tag: 1.2.2
    - name: argo-sync-wait
      adapter: argocd
      with:
        app: payments
        timeout: 600s
  gates:
    - name: http-latency-p95
      type: timescale.query
      with:
        sql: |
          SELECT avg(p95) AS p95
          FROM http_p95_1m
          WHERE app_id = ${app_id}
            AND bucket >= now() - INTERVAL '5 minutes';
      assert: "p95 < 900"    # ms
  approvals:
    required: [team-payments-oncall]

risk = w1*impact + w2*(1-recoverability) + w3*complexity + w4*time_window_penalty + w5*compliance_level
建议默认: w1=0.35, w2=0.25, w3=0.15, w4=0.15, w5=0.10
阈值 τ： ≤0.35 自动执行；(0.35,0.6] 需审批；>0.6 严禁自动。

package ops.autonomy

default allow = false

allow {
  input.plan.strategy.autonomy == "L2"
  input.risk_score <= 0.35
  time.hour(now) >= 22; time.hour(now) < 6
  not forbidden_window
}

forbidden_window {
  input.subject.env == "prod"
  weekday(now) == 5   # Friday
}

WITH before AS (
  SELECT avg(p95) AS p95
  FROM http_p95_1m
  WHERE app_id=$1 AND bucket BETWEEN now()-interval '10 min' AND now()-interval '5 min'
), after AS (
  SELECT avg(p95) AS p95
  FROM http_p95_1m
  WHERE app_id=$1 AND bucket >= now()-interval '5 min'
)
SELECT (b.p95 - a.p95)/b.p95 AS improvement
FROM before b, after a;
-- 要求 improvement >= 0.1 即改善≥10%

系统：你是 OPS Planner。仅输出 Plan DSL。白名单动作：Scale/Flag/Traffic/Helm/DBMigrate。
输入包含：TopK、Graph、SimilarCases。不得包含任何秘密或凭据。

idempotency_key = sha256(adapter + serialized_command + target + window)
