HV05系列高压贴片电阻核心解析与设计指南

​型号示例​：HV05W8J2003T5E（200kΩ±5%）、HV05W8J0105T5E（1MΩ±5%）

一、核心参数详解

HV05系列是厚声（UNI-ROYAL）针对400V级高压场景设计的0805封装贴片电阻，核心参数如下：

​参数类别​

​技术规格​

​备注​

​封装与尺寸​

0805（2.0mm×1.25mm×0.55mm）

兼容高密度SMT贴装，比常规0805电阻节省40% PCB空间 1

​电气特性​

额定电压：400V；最大过载电压：800V（脉宽＜10ms）；耐压：500V

支持4kV/2Ω雷击浪涌防护 1

​阻值与精度​

范围：150KΩ~3.3MΩ（E-24标准）；精度：±5%（J级）

编码规则：3位数字（例：2003=200kΩ） 1

​功率与温升​

额定功率：1/8W（0.125W@70℃）；降额曲线：100℃→0.1W，155℃→0.0625W

需增加散热铜箔或强制风冷 1

​温度特性​

温度系数（TCR）：±100ppm/℃；工作温度：-55℃~+155℃

极端温差阻值变化≤2.1% 1

​可靠性认证​

兼容AEC-Q200车规标准；通过ISO9001/TS16949体系认证

机械强度可承受3mm PCB弯曲 15

二、典型应用场景与方案设计

1. ​工业电源母线电压采样​
  • ​设计要点​：
    • 600V系统分压：3颗200kΩ（HV05W8J2003T5E）串联 → ​总耐压1200V​（安全余量200%）1 。
    • PCB爬电距离≥1.2mm，基板材耐压≥300V。
2. ​LED驱动浪涌防护​
  • ​设计要点​：
    • 串联470kΩ（HV05W8J4703T5E）限流 → 充电电流≤0.85mA（@400V），响应时间 ​​＜1μs​ 1 。
    • 并联TVS二极管（如SMCJ系列）吸收瞬态能量。
3. ​家电高压控制电路​
  • ​设计要点​：
    • 电磁炉IGBT栅极驱动：10kΩ（HV05W8J1003T5E）串联栅极，耐受10kV/μs dv/dt 1 。
    • 避免与发热源（如MOSFET）相邻布局，温升ΔT≤40℃。
4. ​开关电源RC滤波​
  • ​设计要点​：
    • 1MΩ（HV05W8J0105T5E） + 10nF/1kV MLCC → 截止频率 ​15.9Hz，抑制100kHz噪声＞12dB 1 。
    • 高频场景（＞500kHz）需仿真验证寄生电容（0.5pF）影响。

三、设计风险规避指南

​风险类型​

​安全阈值​

​规避方案​

​验证方法​

​电压超限​

工作电压≤320V（400V×80%）

预留20%余量；高压链路串联多电阻均压

耐压测试（2500V/1min） 1

​脉冲损伤​

瞬时电压≤800V

脉冲宽度＜10ms；布局时电阻间间距≥2mm

雷击测试（4kV/2Ω波形） 1

​高温失效​

155℃时功率≤0.0625W

环境温度＞70℃时按0.8倍降额；PCB增加散热铜箔

IR热成像仪监测温升 1

​高频失真​

适用频率≤500kHz

＞500kHz时选用薄膜电阻或仿真寄生电容影响

网络分析仪测试频响 1

​焊接不良​

回流焊峰值温度≤260℃

优化曲线：预热150℃→220℃（60s）→峰值260℃（＜5s）

焊点切片分析 1

四、选型与供应链建议

  1. ​阻值覆盖​：
    • 常用型号：200kΩ（HV05W8J2003T5E）、1MΩ（HV05W8J0105T5E）、3.3MΩ（HV05W8J3354T5E）6 7 8 。
  2. ​车规级应用​：
    • 优选AEC-Q200认证型号（如HV05W8J系列），适用于新能源车BMS电压采样、车载充电器反馈回路 5

📦 ​五、全系阻值选型

型号

额定电压

系列

封装

阻值

功率额定值

容差

温度系数

最小工作温度

最大工作温度

应用

HV05S8F1003T5E

400 V

HV

0805

100 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1004T5E

400 V

HV

0805

1 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1005T5E

400 V

HV

0805

10 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1073T5E

400 V

HV

0805

107 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1103T5E

400 V

HV

0805

110 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1203T5E

400 V

HV

0805

120 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1204T5E

400 V

HV

0805

1.2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1304T5E

400 V

HV

0805

1.3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1433T5E

400 V

HV

0805

143 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1503T5E

400 V

HV

0805

150 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1504T5E

400 V

HV

0805

1.5 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1543T5E

400 V

HV

0805

154 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1653T5E

400 V

HV

0805

165 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1654T5E

400 V

HV

0805

1.65 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1803T5E

400 V

HV

0805

180 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F1804T5E

400 V

HV

0805

1.8 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2003T5E

400 V

HV

0805

200 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2004T5E

400 V

HV

0805

2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2204T5E

400 V

HV

0805

2.2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2373T5E

400 V

HV

0805

237 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2404T5E

400 V

HV

0805

2.4 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2493T5E

400 V

HV

0805

249 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2553T5E

400 V

HV

0805

255 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2703T5E

400 V

HV

0805

270 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2743T5E

400 V

HV

0805

274 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F2803T5E

400 V

HV

0805

280 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3003T5E

400 V

HV

0805

300 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3004T5E

400 V

HV

0805

3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3013T5E

400 V

HV

0805

301 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3243T5E

400 V

HV

0805

324 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3303T5E

400 V

HV

0805

330 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3304T5E

400 V

HV

0805

3.3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3323T5E

400 V

HV

0805

332 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3903T5E

400 V

HV

0805

390 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3904T5E

400 V

HV

0805

3.9 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F3923T5E

400 V

HV

0805

392 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4023T5E

400 V

HV

0805

402 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4123T5E

400 V

HV

0805

412 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4303T5E

400 V

HV

0805

430 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4533T5E

400 V

HV

0805

453 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4643T5E

400 V

HV

0805

464 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4703T5E

400 V

HV

0805

470 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F4993T5E

400 V

HV

0805

499 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F5103T5E

400 V

HV

0805

510 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F5104T5E

400 V

HV

0805

5.1 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F5493T5E

400 V

HV

0805

549 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F5603T5E

400 V

HV

0805

560 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F6043T5E

400 V

HV

0805

604 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F6203T5E

400 V

HV

0805

620 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F6493T5E

400 V

HV

0805

649 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F6803T5E

400 V

HV

0805

680 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F6813T5E

400 V

HV

0805

681 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F7503T5E

400 V

HV

0805

750 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F8203T5E

400 V

HV

0805

820 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F8253T5E

400 V

HV

0805

825 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8F8453T5E

400 V

HV

0805

845 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0104T5E

400 V

HV

0805

100 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0105T5E

400 V

HV

0805

1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0106T5E

400 V

HV

0805

10 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0114T5E

400 V

HV

0805

110 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0115T5E

400 V

HV

0805

1.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0124T5E

400 V

HV

0805

120 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0125T5E

400 V

HV

0805

1.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0134T5E

400 V

HV

0805

130 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0135T5E

400 V

HV

0805

1.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0154T5E

400 V

HV

0805

150 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0155T5E

400 V

HV

0805

1.5 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0164T5E

400 V

HV

0805

160 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0165T5E

400 V

HV

0805

1.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0184T5E

400 V

HV

0805

180 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0185T5E

400 V

HV

0805

1.8 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0204T5E

400 V

HV

0805

200 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0205T5E

400 V

HV

0805

2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0224T5E

400 V

HV

0805

220 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0225T5E

400 V

HV

0805

2.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0244T5E

400 V

HV

0805

240 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0245T5E

400 V

HV

0805

2.4 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0274T5E

400 V

HV

0805

270 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0275T5E

400 V

HV

0805

2.7 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0284T5E

400 V

HV

0805

280 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0304T5E

400 V

HV

0805

300 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0305T5E

400 V

HV

0805

3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0334T5E

400 V

HV

0805

330 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0335T5E

400 V

HV

0805

3.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0364T5E

400 V

HV

0805

360 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0365T5E

400 V

HV

0805

3.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0394T5E

400 V

HV

0805

390 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0395T5E

400 V

HV

0805

3.9 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0434T5E

400 V

HV

0805

430 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0435T5E

400 V

HV

0805

4.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0474T5E

400 V

HV

0805

470 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0475T5E

400 V

HV

0805

4.7 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0514T5E

400 V

HV

0805

510 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0515T5E

400 V

HV

0805

5.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0564T5E

400 V

HV

0805

560 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0565T5E

400 V

HV

0805

5.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0624T5E

400 V

HV

0805

620 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0625T5E

400 V

HV

0805

6.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0684T5E

400 V

HV

0805

680 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0685T5E

400 V

HV

0805

6.8 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0754T5E

400 V

HV

0805

750 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0755T5E

400 V

HV

0805

7.5 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0824T5E

400 V

HV

0805

820 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0825T5E

400 V

HV

0805

8.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0914T5E

400 V

HV

0805

910 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05S8J0915T5E

400 V

HV

0805

9.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1003T5E

400 V

HV

0805

100 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1004T5E

400 V

HV

0805

1 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1005T5E

400 V

HV

0805

10 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1073T5E

400 V

HV

0805

107 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1103T5E

400 V

HV

0805

110 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1203T5E

400 V

HV

0805

120 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1204T5E

400 V

HV

0805

1.2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1304T5E

400 V

HV

0805

1.3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1433T5E

400 V

HV

0805

143 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1503T5E

400 V

HV

0805

150 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1504T5E

400 V

HV

0805

1.5 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1543T5E

400 V

HV

0805

154 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1653T5E

400 V

HV

0805

165 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1654T5E

400 V

HV

0805

1.65 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1803T5E

400 V

HV

0805

180 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F1804T5E

400 V

HV

0805

1.8 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2003T5E

400 V

HV

0805

200 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2004T5E

400 V

HV

0805

2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2204T5E

400 V

HV

0805

2.2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2373T5E

400 V

HV

0805

237 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2404T5E

400 V

HV

0805

2.4 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2493T5E

400 V

HV

0805

249 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2553T5E

400 V

HV

0805

255 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2703T5E

400 V

HV

0805

270 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2743T5E

400 V

HV

0805

274 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F2803T5E

400 V

HV

0805

280 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3003T5E

400 V

HV

0805

300 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3004T5E

400 V

HV

0805

3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3013T5E

400 V

HV

0805

301 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3243T5E

400 V

HV

0805

324 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3303T5E

400 V

HV

0805

330 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3304T5E

400 V

HV

0805

3.3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3323T5E

400 V

HV

0805

332 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3903T5E

400 V

HV

0805

390 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3904T5E

400 V

HV

0805

3.9 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F3923T5E

400 V

HV

0805

392 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4023T5E

400 V

HV

0805

402 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4123T5E

400 V

HV

0805

412 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4303T5E

400 V

HV

0805

430 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4533T5E

400 V

HV

0805

453 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4643T5E

400 V

HV

0805

464 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4703T5E

400 V

HV

0805

470 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F4993T5E

400 V

HV

0805

499 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F5103T5E

400 V

HV

0805

510 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F5104T5E

400 V

HV

0805

5.1 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F5493T5E

400 V

HV

0805

549 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F5603T5E

400 V

HV

0805

560 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F6043T5E

400 V

HV

0805

604 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F6203T5E

400 V

HV

0805

620 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F6493T5E

400 V

HV

0805

649 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F6803T5E

400 V

HV

0805

680 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F6813T5E

400 V

HV

0805

681 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F7503T5E

400 V

HV

0805

750 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F8203T5E

400 V

HV

0805

820 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F8253T5E

400 V

HV

0805

825 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8F8453T5E

400 V

HV

0805

845 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0104T5E

400 V

HV

0805

100 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0105T5E

400 V

HV

0805

1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0106T5E

400 V

HV

0805

10 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0114T5E

400 V

HV

0805

110 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0115T5E

400 V

HV

0805

1.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0124T5E

400 V

HV

0805

120 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0125T5E

400 V

HV

0805

1.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0134T5E

400 V

HV

0805

130 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0135T5E

400 V

HV

0805

1.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0154T5E

400 V

HV

0805

150 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0155T5E

400 V

HV

0805

1.5 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0164T5E

400 V

HV

0805

160 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0165T5E

400 V

HV

0805

1.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0184T5E

400 V

HV

0805

180 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0185T5E

400 V

HV

0805

1.8 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0204T5E

400 V

HV

0805

200 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0205T5E

400 V

HV

0805

2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0224T5E

400 V

HV

0805

220 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0225T5E

400 V

HV

0805

2.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0244T5E

400 V

HV

0805

240 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0245T5E

400 V

HV

0805

2.4 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0274T5E

400 V

HV

0805

270 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0275T5E

400 V

HV

0805

2.7 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0284T5E

400 V

HV

0805

280 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0304T5E

400 V

HV

0805

300 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0305T5E

400 V

HV

0805

3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0334T5E

400 V

HV

0805

330 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0335T5E

400 V

HV

0805

3.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0364T5E

400 V

HV

0805

360 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0365T5E

400 V

HV

0805

3.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0394T5E

400 V

HV

0805

390 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0395T5E

400 V

HV

0805

3.9 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0434T5E

400 V

HV

0805

430 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0435T5E

400 V

HV

0805

4.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0474T5E

400 V

HV

0805

470 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0475T5E

400 V

HV

0805

4.7 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0514T5E

400 V

HV

0805

510 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0515T5E

400 V

HV

0805

5.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0564T5E

400 V

HV

0805

560 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0565T5E

400 V

HV

0805

5.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0624T5E

400 V

HV

0805

620 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0625T5E

400 V

HV

0805

6.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0684T5E

400 V

HV

0805

680 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0685T5E

400 V

HV

0805

6.8 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0754T5E

400 V

HV

0805

750 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0755T5E

400 V

HV

0805

7.5 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0824T5E

400 V

HV

0805

820 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0825T5E

400 V

HV

0805

8.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0914T5E

400 V

HV

0805

910 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05W8J0915T5E

400 V

HV

0805

9.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1003T5E

400 V

HV

0805

100 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1004T5E

400 V

HV

0805

1 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1005T5E

400 V

HV

0805

10 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1073T5E

400 V

HV

0805

107 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1103T5E

400 V

HV

0805

110 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1203T5E

400 V

HV

0805

120 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1204T5E

400 V

HV

0805

1.2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1304T5E

400 V

HV

0805

1.3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1433T5E

400 V

HV

0805

143 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1503T5E

400 V

HV

0805

150 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1504T5E

400 V

HV

0805

1.5 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1543T5E

400 V

HV

0805

154 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1653T5E

400 V

HV

0805

165 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1654T5E

400 V

HV

0805

1.65 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1803T5E

400 V

HV

0805

180 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF1804T5E

400 V

HV

0805

1.8 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2003T5E

400 V

HV

0805

200 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2004T5E

400 V

HV

0805

2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2204T5E

400 V

HV

0805

2.2 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2373T5E

400 V

HV

0805

237 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2404T5E

400 V

HV

0805

2.4 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2493T5E

400 V

HV

0805

249 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2553T5E

400 V

HV

0805

255 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2703T5E

400 V

HV

0805

270 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2743T5E

400 V

HV

0805

274 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF2803T5E

400 V

HV

0805

280 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3003T5E

400 V

HV

0805

300 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3004T5E

400 V

HV

0805

3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3013T5E

400 V

HV

0805

301 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3243T5E

400 V

HV

0805

324 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3303T5E

400 V

HV

0805

330 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3304T5E

400 V

HV

0805

3.3 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3323T5E

400 V

HV

0805

332 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3903T5E

400 V

HV

0805

390 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3904T5E

400 V

HV

0805

3.9 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF3923T5E

400 V

HV

0805

392 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4023T5E

400 V

HV

0805

402 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4123T5E

400 V

HV

0805

412 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4303T5E

400 V

HV

0805

430 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4533T5E

400 V

HV

0805

453 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4643T5E

400 V

HV

0805

464 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4703T5E

400 V

HV

0805

470 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF4993T5E

400 V

HV

0805

499 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF5103T5E

400 V

HV

0805

510 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF5104T5E

400 V

HV

0805

5.1 MOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF5493T5E

400 V

HV

0805

549 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF5603T5E

400 V

HV

0805

560 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF6043T5E

400 V

HV

0805

604 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF6203T5E

400 V

HV

0805

620 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF6493T5E

400 V

HV

0805

649 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF6803T5E

400 V

HV

0805

680 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF6813T5E

400 V

HV

0805

681 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF7503T5E

400 V

HV

0805

750 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF8203T5E

400 V

HV

0805

820 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF8253T5E

400 V

HV

0805

825 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAF8453T5E

400 V

HV

0805

845 kOhms

125 mW (1/8 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0104T5E

400 V

HV

0805

100 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0105T5E

400 V

HV

0805

1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0106T5E

400 V

HV

0805

10 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0114T5E

400 V

HV

0805

110 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0115T5E

400 V

HV

0805

1.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0124T5E

400 V

HV

0805

120 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0125T5E

400 V

HV

0805

1.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0134T5E

400 V

HV

0805

130 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0135T5E

400 V

HV

0805

1.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0154T5E

400 V

HV

0805

150 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0155T5E

400 V

HV

0805

1.5 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0164T5E

400 V

HV

0805

160 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0165T5E

400 V

HV

0805

1.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0184T5E

400 V

HV

0805

180 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0185T5E

400 V

HV

0805

1.8 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0204T5E

400 V

HV

0805

200 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0205T5E

400 V

HV

0805

2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0224T5E

400 V

HV

0805

220 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0225T5E

400 V

HV

0805

2.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0244T5E

400 V

HV

0805

240 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0245T5E

400 V

HV

0805

2.4 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0274T5E

400 V

HV

0805

270 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0275T5E

400 V

HV

0805

2.7 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0284T5E

400 V

HV

0805

280 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0304T5E

400 V

HV

0805

300 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0305T5E

400 V

HV

0805

3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0334T5E

400 V

HV

0805

330 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0335T5E

400 V

HV

0805

3.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0364T5E

400 V

HV

0805

360 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0365T5E

400 V

HV

0805

3.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0394T5E

400 V

HV

0805

390 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0395T5E

400 V

HV

0805

3.9 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0434T5E

400 V

HV

0805

430 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0435T5E

400 V

HV

0805

4.3 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0474T5E

400 V

HV

0805

470 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0475T5E

400 V

HV

0805

4.7 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0514T5E

400 V

HV

0805

510 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0515T5E

400 V

HV

0805

5.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0564T5E

400 V

HV

0805

560 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0565T5E

400 V

HV

0805

5.6 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0624T5E

400 V

HV

0805

620 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0625T5E

400 V

HV

0805

6.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0684T5E

400 V

HV

0805

680 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0685T5E

400 V

HV

0805

6.8 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0754T5E

400 V

HV

0805

750 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0755T5E

400 V

HV

0805

7.5 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0824T5E

400 V

HV

0805

820 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0825T5E

400 V

HV

0805

8.2 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0914T5E

400 V

HV

0805

910 kOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV05WAJ0915T5E

400 V

HV

0805

9.1 MOhms

125 mW (1/8 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

原创声明：本文系作者授权腾讯云开发者社区发表，未经许可，不得转载。

如有侵权，请联系 cloudcommunity@tencent.com 删除。

芯片

原创声明：本文系作者授权腾讯云开发者社区发表，未经许可，不得转载。

如有侵权，请联系 cloudcommunity@tencent.com 删除。

芯片
评论
登录后参与评论
0 条评论
热度
最新
登录 后参与评论
推荐阅读
目录
  • HV05系列高压贴片电阻核心解析与设计指南
  • 一、核心参数详解
  • 二、典型应用场景与方案设计
    • 1. ​工业电源母线电压采样​
    • 2. ​LED驱动浪涌防护​
    • 3. ​家电高压控制电路​
    • 4. ​开关电源RC滤波​
  • 三、设计风险规避指南
  • 四、选型与供应链建议
领券

腾讯云开发者

扫码关注腾讯云开发者

扫码关注腾讯云开发者

领取腾讯云代金券

热门产品

热门推荐

更多推荐

Copyright © 2013 - 2025 Tencent Cloud. All Rights Reserved. 腾讯云 版权所有

深圳市腾讯计算机系统有限公司 ICP备案/许可证号：粤B2-20090059 深公网安备号 44030502008569

腾讯云计算（北京）有限责任公司 京ICP证150476号 |  京ICP备11018762号 | 京公网安备号11010802020287

问题归档专栏文章快讯文章归档关键词归档开发者手册归档开发者手册 Section 归档

Copyright © 2013 - 2025 Tencent Cloud.

All Rights Reserved. 腾讯云 版权所有

登录 后参与评论
