PXC 现场频繁死锁，某组件惨遭官方删除

2025-07-07T05:10:25.772284Z 0 [ERROR] [MY-012872] [InnoDB] [FATAL] Semaphore wait has lasted > 600 seconds. We intentionally crash the server because it appears to be hung.
2025-07-07T05:10:25.774138Z 0 [ERROR] [MY-013183] [InnoDB] Assertion failure: srv0srv.cc:2107:ib::fatal triggered thread 140395501549312
InnoDB: We intentionally generate a memory trap.
InnoDB: Submit a detailed bug report to http://bugs.mysql.com.
InnoDB: If you get repeated assertion failures or crashes, even
InnoDB: immediately after the mysqld startup, there may be
InnoDB: corruption in the InnoDB tablespace. Please refer to
InnoDB: http://dev.mysql.com/doc/refman/8.0/en/forcing-innodb-recovery.html
InnoDB: about forcing recovery.
2025-07-07T05:10:25Z UTC - mysqld got signal 6 ;
Most likely, you have hit a bug, but this error can also be caused by malfunctioning hardware.
BuildID[sha1]=3a37a99599e0a71e11a86a930d4974a17cf35a5b
Server Version: 8.0.33-25.1 Percona XtraDB Cluster binary (GPL) 8.0.33, Revision 0c56202, WSREP version 26.1.4.3, wsrep_26.1.4.3

----------
SEMAPHORES
----------
OS WAIT ARRAY INFO: reservation count 121
--Thread 140395688941312 has waited at buf0flu.cc line 1376 for 1190 seconds the semaphore:
SX-lock on RW-latch at 0x7fb06fd8cd58 created in file buf0buf.cc line 815
a writer (thread id 140395374548736) has reserved it in mode exclusive
number of readers 0, waiters flag 1, lock_word: 0
Last time read locked in file not yet reserved line 0
Last time write locked in file /mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/storage/innobase/include/trx0undo.ic line 126
--Thread 140395451193088 has waited at trx0rseg.ic line 51 for 1152 seconds the semaphore:
X-lock on RW-latch at 0x7fb06fd34f78 created in file buf0buf.cc line 815
a writer (thread id 140395374548736) has reserved it in mode exclusive
number of readers 0, waiters flag 1, lock_word: 0
Last time read locked in file not yet reserved line 0
Last time write locked in file /mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/storage/innobase/include/trx0rseg.ic line 51

---TRANSACTION 2998, ACTIVE (PREPARED) 1197 sec committing
4 lock struct(s), heap size 1128, 2 row lock(s), undo log entries 2
MySQL thread id 43, OS thread handle 140395374548736, query id 330 innobase_commit_low (191)

# at 40289
#250706 21:50:27 server id 30001  end_log_pos 40373 CRC32 0x9ddcce0c    GTID    last_committed=146      sequence_number=147     rbr_only=no     original_committed_timestamp=1751863827165363   immediate_commit_timestamp=1751863827756834     transaction_length=221
# original_commit_timestamp=1751863827165363 (2025-07-06 21:50:27.165363 PDT)
# immediate_commit_timestamp=1751863827756834 (2025-07-06 21:50:27.756834 PDT)
/*!80001 SET @@session.original_commit_timestamp=1751863827165363*//*!*/;
/*!80014 SET @@session.original_server_version=80033*//*!*/;
/*!80014 SET @@session.immediate_server_version=80033*//*!*/;
SET @@SESSION.GTID_NEXT= '00030001-1111-1111-1111-111111111111:128'/*!*/;
# at 40373
#250706 21:50:27 server id 30001  end_log_pos 40441 CRC32 0x53b220b7    Query   thread_id=42    exec_time=0     error_code=0
SETTIMESTAMP=1751863827/*!*/;
SET @@session.sql_mode=1168113696/*!*/;
BEGIN
/*!*/;
# at 40441
#250706 21:50:27 server id 30001  end_log_pos 40510 CRC32 0x32b78ce8    Query   thread_id=42    exec_time=0     error_code=0
SETTIMESTAMP=1751863827/*!*/;
COMMIT

(gdb) p/x 140395374548736
$1 = 0x7fb0586d9700
(gdb) thread find 0x7fb0586d9700
Thread 49 has target id 'Thread 0x7fb0586d9700 (LWP 10982)'
(gdb) thread 49
[Switching to thread 49 (Thread 0x7fb0586d9700 (LWP 10982))]
#0  0x00007fb0b324c48c in pthread_cond_wait@@GLIBC_2.3.2 () from /lib64/libpthread.so.0

(gdb) set filename-display basename
(gdb) bt
#0  0x00007fb0b324c48c in pthread_cond_wait@@GLIBC_2.3.2 () from /lib64/libpthread.so.0
#1  0x00000000012578f0 in native_cond_wait (mutex=<optimized out>, cond=<optimized out>) at thr_cond.h:161
#2  my_cond_wait (mp=<optimized out>, cond=<optimized out>) at thr_cond.h:161
#3  inline_mysql_cond_wait (that=<optimized out>, mutex=<optimized out>,
    src_file=0x33f0598 "/mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/sql/wsrep_binlog.cc", src_line=468)
    at mysql_cond.h:198
#4  wsrep_wait_for_turn_in_group_commit (thd=0x7fb08800d430) at wsrep_binlog.cc:468
#5  0x000000000242b5a8 in trx_sys_update_wsrep_checkpoint (xid=0x7fb078016680, sys_header=0x0, mtr=0x7fb0586d6c90, recovery=<optimized out>)
    at current_thd.h:33
#6  0x0000000002438303 in trx_write_serialisation_history (trx=0x7fb0948d0558, mtr=0x7fb0586d6c90) at trx0trx.cc:1746
#7  0x000000000243b5aa in trx_commit_low (trx=trx@entry=0x7fb0948d0558, mtr=0x7fb0586d6c90) at trx0trx.cc:2287
#8  0x000000000243bc94 in trx_commit (trx=0x7fb0948d0558) at trx0trx.cc:2364
#9  0x000000000243bfcc in trx_commit_for_mysql (trx=trx@entry=0x7fb0948d0558) at trx0trx.cc:2616
#10 0x000000000224a672 in innobase_commit_low (trx=trx@entry=0x7fb0948d0558) at ha_innodb.cc:6266
#11 0x0000000002279eb9 in innobase_commit (hton=<optimized out>, thd=0x7fb08800d430, commit_trx=<optimized out>) at ha_innodb.cc:6543
#12 0x0000000000d9379e in ha_commit_low (thd=0x7fb08800d430, all=true, run_after_commit=<optimized out>) at handler.cc:2045
#13 0x00000000011f4b4d in trx_coordinator::commit_in_engines (run_after_commit=<optimized out>, all=<optimized out>, thd=<optimized out>) at tc_log.cc:148
#14 trx_coordinator::commit_in_engines (thd=<optimized out>, all=<optimized out>, run_after_commit=<optimized out>) at tc_log.cc:138
#15 0x0000000001e0e2e8 in (anonymous namespace)::finish_transaction_in_engines (thd=thd@entry=0x7fb08800d430, all=<optimized out>, run_after_commit=false)
    at binlog.cc:12576
#16 0x0000000001e18276 in MYSQL_BIN_LOG::process_commit_stage_queue (this=0x43d5b00 <mysql_bin_log>, thd=0x7fb08003dcd0, first=0x7fb08003dcd0)
    at binlog.cc:9096
#17 0x0000000001e2e80b in MYSQL_BIN_LOG::ordered_commit (this=0x43d5b00 <mysql_bin_log>, thd=0x7fb08003dcd0, all=<optimized out>,
    skip_commit=<optimized out>) at binlog.cc:9650
#18 0x0000000001e30cf6 in MYSQL_BIN_LOG::commit (this=0x43d5b00 <mysql_bin_log>, thd=0x7fb08003dcd0, all=<optimized out>) at binlog.cc:8841
#19 0x0000000000d952e1 in ha_commit_trans (thd=thd@entry=0x7fb08003dcd0, all=all@entry=true, ignore_global_read_lock=ignore_global_read_lock@entry=false)
    at handler.cc:1878
#20 0x00000000011f809b in trans_commit (thd=thd@entry=0x7fb08003dcd0, ignore_global_read_lock=ignore_global_read_lock@entry=false) at transaction.cc:271
#21 0x0000000001e39b8b in Xid_log_event::do_commit (this=0x7fb07b4786d0, thd_arg=0x7fb08003dcd0) at log_event.cc:6272
#22 0x0000000001e39cc7 in Xid_apply_log_event::do_apply_event_worker (this=0x7fb07b478740, w=0x7fb07aecfd00) at log_event.cc:6367
#23 0x0000000001eee06f in slave_worker_exec_job_group (worker=worker@entry=0x7fb07aecfd00, rli=rli@entry=0x7fb07c691ac0) at rpl_rli_pdb.cc:2517
#24 0x0000000001ef609b in handle_slave_worker (arg=arg@entry=0x7fb07aecfd00) at rpl_replica.cc:6289
#25 0x000000000264d5b5 in pfs_spawn_thread (arg=0x7fb07ae28e20) at pfs.cc:3043
#26 0x00007fb0b32461ca in start_thread () from /lib64/libpthread.so.0
#27 0x00007fb0b13bd8d3 in clone () from /lib64/libc.so.6

File: sql/wsrep_binlog.cc
457:   while (true) {
458:     if (thd == wsrep_group_commit_queue.front()) {
459:       WSREP_DEBUG("Thread with id (%d) granted turn to proceed",
460:                   thd->thread_id());
461:       break;
462:     } else {
463:       WSREP_DEBUG(
464:           "Thread with id (%d) waiting for its turns in wsrep group"
465:           " commit queue - waiting for (%d)",
466:           thd->thread_id(),
467:           wsrep_group_commit_queue.front()->thread_id());
468:       mysql_cond_wait(&COND_wsrep_group_commit, &LOCK_wsrep_group_commit);
469:     }
470:   }

static std::queue<THD *> wsrep_group_commit_queue;

void wsrep_unregister_from_group_commit(THD *thd) {
  DBUG_TRACE;
if (wsrep_emulate_bin_log || thd == NULL) {
    /* Binlog is off, no need to maintain group commit queue */
    /* thd can be NULL if the transaction is being committed
       during recovery using XID. */
    return;
  }

  MUTEX_LOCK(guard, &LOCK_wsrep_group_commit);

if (!thd->wsrep_enforce_group_commit) {
    /* Said handler was not register for wsrep group commit */
    return;
  }

  thd->wsrep_enforce_group_commit = false;
  assert(wsrep_group_commit_queue.front() == thd);
  wsrep_group_commit_queue.pop();
  WSREP_DEBUG(
      "Un-Registering thread with id (%d) from wsrep group commit"
      " queue",
      thd->thread_id());
  mysql_cond_broadcast(&COND_wsrep_group_commit);
return;
}

mysql> set global wsrep_debug = "server";

mysql > update t set d = 1 where id = 6;
Query OK, 1 row affected (0.09 sec)
Rows matched: 1  Changed: 1  Warnings: 0

2025-07-14T04:07:04.388360Z 20 [Note] [MY-000000] [WSREP] wsrep_before_prepare: 1
2025-07-14T04:07:04.389203Z 20 [Note] [MY-000000] [WSREP] wsrep: replicating and certifying write set(-1)
2025-07-14T04:07:04.413971Z 20 [Note] [MY-000000] [WSREP] wsrep: write set replicated and certified (781)
2025-07-14T04:07:04.414795Z 20 [Note] [MY-000000] [WSREP] wsrep_after_prepare: 1
2025-07-14T04:07:04.415519Z 20 [Note] [MY-000000] [WSREP] wsrep_before_commit: 1, 781
2025-07-14T04:07:04.417004Z 20 [Note] [MY-000000] [WSREP] wsrep_ordered_commit: 1
2025-07-14T04:07:04.417208Z 20 [Note] [MY-000000] [WSREP] Registering thread with id (20) in wsrep group commit queue
2025-07-14T04:07:04.447810Z 20 [Note] [MY-000000] [WSREP] Updating WSREPXid: 8322eb1e-5acf-11f0-8691-e63683345e0b:781
2025-07-14T04:07:04.448029Z 20 [Note] [MY-000000] [WSREP] Thread with id (20) granted turn to proceed
2025-07-14T04:07:04.448153Z 20 [Note] [MY-000000] [WSREP] Un-Registering thread with id (20) from wsrep group commit queue
2025-07-14T04:07:04.449338Z 20 [Note] [MY-000000] [WSREP] wsrep_after_commit: 1, 1, 781, 1

(gdb) p wsrep_group_commit_queue
$2 = std::queue wrapping: std::deque with 4 elements = {0x7fb08c0298c0, 0x7fb08800d430, 0x7fb08414faf0,
  0x7fb09021c3f0}

(gdb) p ((THD*)0x7fb08c0298c0)->m_thread_id
$3 = 42
(gdb) p ((THD*)0x7fb08c0298c0)->real_id
$4 = 140395373491968
(gdb) p/x  ((THD*)0x7fb08c0298c0)->real_id
$5 = 0x7fb0585d7700
(gdb) thread find 0x7fb0585d7700
Thread 50 has target id 'Thread 0x7fb0585d7700 (LWP 10983)'

(gdb) set filename-display basename
(gdb) bt
#0  0x00007fb0b324c48c in pthread_cond_wait@@GLIBC_2.3.2 () from /lib64/libpthread.so.0
#1  0x0000000001e60040 in native_cond_wait (
    mutex=0x43d6cb0 <Commit_stage_manager::get_instance()::shared_instance+336>,
    cond=0x43d6c40 <Commit_stage_manager::get_instance()::shared_instance+224>) at thr_cond.h:161
#2  my_cond_wait (mp=0x43d6cb0 <Commit_stage_manager::get_instance()::shared_instance+336>,
    cond=0x43d6c40 <Commit_stage_manager::get_instance()::shared_instance+224>) at thr_cond.h:161
#3  inline_mysql_cond_wait (
    src_file=0x34dec40 "/mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/sql/rpl_commit_stage_manager.cc", src_line=417,
    mutex=0x43d6cb0 <Commit_stage_manager::get_instance()::shared_instance+336>,
    that=0x43d6c40 <Commit_stage_manager::get_instance()::shared_instance+224>) at mysql_cond.h:198
#4  Commit_stage_manager::enroll_for (
    this=0x43d6b60 <Commit_stage_manager::get_instance()::shared_instance>,
    stage=stage@entry=Commit_stage_manager::BINLOG_FLUSH_STAGE, thd=thd@entry=0x7fb08c0298c0,
    stage_mutex=stage_mutex@entry=0x0, enter_mutex=enter_mutex@entry=0x43d5b08 <mysql_bin_log+8>)
    at rpl_commit_stage_manager.cc:417
#5  0x0000000001e18660 in MYSQL_BIN_LOG::change_stage (this=this@entry=0x43d5b00 <mysql_bin_log>,
    thd=thd@entry=0x7fb08c0298c0, stage=stage@entry=Commit_stage_manager::BINLOG_FLUSH_STAGE,
    queue=queue@entry=0x7fb08c0298c0, leave_mutex=leave_mutex@entry=0x0,
    enter_mutex=enter_mutex@entry=0x43d5b08 <mysql_bin_log+8>) at binlog.cc:9173
#6  0x0000000001e2e34f in MYSQL_BIN_LOG::ordered_commit (this=0x43d5b00 <mysql_bin_log>,
    thd=0x7fb08c0298c0, all=<optimized out>, skip_commit=<optimized out>) at binlog.cc:9475
#7  0x0000000001e30cf6 in MYSQL_BIN_LOG::commit (this=0x43d5b00 <mysql_bin_log>, thd=0x7fb08c0298c0,
    all=<optimized out>) at binlog.cc:8841
#8  0x0000000001e3168d in MYSQL_BIN_LOG::gtid_end_transaction (this=<optimized out>,
    thd=thd@entry=0x7fb08c0298c0) at binlog.cc:2011
#9  0x0000000001e39ba9 in Xid_log_event::do_commit (this=0x7fb07ac916a0, thd_arg=0x7fb08c0298c0)
    at log_event.cc:6278
#10 0x0000000001e39cc7 in Xid_apply_log_event::do_apply_event_worker (this=0x7fb07ac91710, w=0x7fb07ae33360) at log_event.cc:6367
#11 0x0000000001eee06f in slave_worker_exec_job_group (worker=worker@entry=0x7fb07ae33360, rli=rli@entry=0x7fb07c691ac0) at rpl_rli_pdb.cc:2517
#12 0x0000000001ef609b in handle_slave_worker (arg=arg@entry=0x7fb07ae33360) at rpl_replica.cc:6289
#13 0x000000000264d5b5 in pfs_spawn_thread (arg=0x7fb07af21190) at pfs.cc:3043
#14 0x00007fb0b32461ca in start_thread () from /lib64/libpthread.so.0
#15 0x00007fb0b13bd8d3 in clone () from /lib64/libc.so.6

File: sql/rpl_commit_stage_manager.cc
396:   /*
397:     If the queue was not empty, we're a follower and wait for the
398:     leader to process the queue. If we were holding a mutex, we have
399:     to release it before going to sleep.
400:   */
401:   if (!leader) {
402:     CONDITIONAL_SYNC_POINT_FOR_TIMESTAMP("before_follower_wait");
403:     mysql_mutex_lock(&m_lock_done);
404: #ifndef NDEBUG
405:     /*
406:       Leader can be awaiting all-clear to preempt follower's execution.
407:       With setting the status the follower ensures it won't execute anything
408:       including thread-specific code.
409:     */
410:     thd->get_transaction()->m_flags.ready_preempt = true;
411:     if (leader_await_preempt_status) mysql_cond_signal(&m_cond_preempt);
412: #endif
413:     while (thd->tx_commit_pending) {
414:       if (stage == COMMIT_ORDER_FLUSH_STAGE) {
415:         mysql_cond_wait(&m_stage_cond_commit_order, &m_lock_done);
416:       } else {
417:         mysql_cond_wait(&m_stage_cond_binlog, &m_lock_done);
418:       }
419:     }

shell> gdb ~/opt/mysql/pxc8.0.33/bin/mysqld core.2035 --batch -ex "thread apply all bt" &> threads.log
shell> source /usr/bin/pt-pmp
shell> cat threads.log | aggregate_stacktrace  > aggregate.log
shell> grep MYSQL_BIN_LOG::ordered_commit aggregate.log | grep -v enroll | tr ",""\n"
            1 pthread_cond_wait
native_cond_wait(thr_cond.h:161)
my_cond_wait(thr_cond.h:161)
inline_mysql_cond_wait(mysql_cond.h:198)
wsrep_wait_for_turn_in_group_commit(wsrep_binlog.cc:468)
trx_sys_update_wsrep_checkpoint(current_thd.h:33)
trx_write_serialisation_history(trx0trx.cc:1746)
trx_commit_low(trx0trx.cc:2287)
trx_commit(trx0trx.cc:2364)
trx_commit_for_mysql(trx0trx.cc:2616)
innobase_commit_low(ha_innodb.cc:6266)
innobase_commit(ha_innodb.cc:6543)
ha_commit_low(handler.cc:2045)
trx_coordinator::commit_in_engines(tc_log.cc:148)
trx_coordinator::commit_in_engines(tc_log.cc:138)
(anonymous(binlog.cc:12576)
MYSQL_BIN_LOG::process_commit_stage_queue(binlog.cc:9096)
MYSQL_BIN_LOG::ordered_commit(binlog.cc:9650)
MYSQL_BIN_LOG::commit(binlog.cc:8841)
ha_commit_trans(handler.cc:1878)
trans_commit(transaction.cc:271)
Xid_log_event::do_commit(log_event.cc:6272)
Xid_apply_log_event::do_apply_event_worker(log_event.cc:6367)
slave_worker_exec_job_group(rpl_rli_pdb.cc:2517)
handle_slave_worker(rpl_replica.cc:6289)
pfs_spawn_thread(pfs.cc:3043)
start_thread(libpthread.so.0)
clone(libc.so.6)

#15 0x0000000001e0e2e8 in (anonymous namespace)::finish_transaction_in_engines (thd=thd@entry=0x7fb08800d430, all=<optimized out>, run_after_commit=false)
    at binlog.cc:12576
#16 0x0000000001e18276 in MYSQL_BIN_LOG::process_commit_stage_queue (this=0x43d5b00 <mysql_bin_log>, thd=0x7fb08003dcd0, first=0x7fb08003dcd0)
    at binlog.cc:9096

  for (THD *head = first; head; head = head->next_to_commit) {
    Thd_backup_and_restore switch_thd(thd, head);
...
    ::finish_transaction_in_engines(head, all, false);

...
}

(gdb) p first
$6 = (THD *) 0x7fb08003dcd0

(gdb) p first->next_to_commit
$7 = (THD *) 0x7fb08c0298c0
(gdb) p first->next_to_commit->next_to_commit
$8 = (THD *) 0x7fb08800d430
(gdb) p first->next_to_commit->next_to_commit->next_to_commit
$9 = (THD *) 0x0

  /**
    Try to attach the POSIX thread to a session.

    @param[in] backup_thd    The thd to restore to when object is destructed.
    @param[in] new_thd       The thd to attach to.
   */

  Thd_backup_and_restore(THD *backup_thd, THD *new_thd)
      : m_backup_thd(backup_thd),
        m_new_thd(new_thd),
        m_new_thd_old_real_id(new_thd->real_id),
        m_new_thd_old_thread_stack(new_thd->thread_stack) {
    assert(m_backup_thd != nullptr && m_new_thd != nullptr);
    // Reset the state of the current thd.
    m_backup_thd->restore_globals();

    m_new_thd->thread_stack = m_backup_thd->thread_stack;
    m_new_thd->store_globals();

  real_id = my_thread_self();

thd3 -> thd2 -> thd1

2025-07-14T10:12:45.798369Z 13 [Note] [MY-000000] [WSREP] Registering thread with id (13) in wsrep group commit queue

Thread 45 "connection" hit Breakpoint 3, (anonymous namespace)::finish_transaction_in_engines (
    thd=thd@entry=0x7ff743326ca0, all=false, run_after_commit=false)
    at /opt/rh/devtoolset-11/root/usr/include/c++/11/bits/unique_ptr.h:421
421     /opt/rh/devtoolset-11/root/usr/include/c++/11/bits/unique_ptr.h: No such file or directory.
(gdb) finish
Run till exit from #0  (anonymous namespace)::finish_transaction_in_engines (
    thd=thd@entry=0x7ff743326ca0, all=false, run_after_commit=false)
    at /opt/rh/devtoolset-11/root/usr/include/c++/11/bits/unique_ptr.h:421
MYSQL_BIN_LOG::process_commit_stage_queue (this=0x43d5b00 <mysql_bin_log>, thd=0x7ff743326ca0,
    first=0x7ff743326ca0)
    at /mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/sql/binlog.cc:9099

2025-07-14T10:12:51.423272Z 13 [Note] [MY-000000] [WSREP] Updating WSREPXid: 8322eb1e-5acf-11f0-8691-e63683345e0b:822
2025-07-14T10:12:51.423625Z 13 [Note] [MY-000000] [WSREP] Thread with id (13) granted turn to proceed
2025-07-14T10:12:51.423694Z 13 [Note] [MY-000000] [WSREP] Un-Registering thread with id (13) from wsrep group commit queue

(gdb) p ((THD*) 0x7fb08c0298c0)->m_thread_id
$9 = 42

#250706 21:50:27 server id 30001  end_log_pos 40510 CRC32 0x32b78ce8    Query   thread_id=42    exec_time=0     error_code=0

node1 [localhost:10001] {msandbox} (test) > update t set d = d where id = 6;
Query OK, 0 rows affected (0.01 sec)
Rows matched: 1  Changed: 0  Warnings: 0

node1 [localhost:10001] {msandbox} (test) > update t set d = 1 where id = 1;
Query OK, 1 row affected (0.03 sec)
Rows matched: 1  Changed: 1  Warnings: 0

master [localhost:30001] {msandbox} (test) > update t set d = 1 where id = 1;
Query OK, 1 row affected (0.03 sec)
Rows matched: 1  Changed: 1  Warnings: 0

# at 2011
#250714  5:06:54 server id 30001  end_log_pos 2095 CRC32 0xc2571d3f     GTID    last_committed=7        sequence_number=8       rbr_only=no original_committed_timestamp=1752494814375749   immediate_commit_timestamp=1752494814431609     transaction_length=221
# original_commit_timestamp=1752494814375749 (2025-07-14 05:06:54.375749 PDT)
# immediate_commit_timestamp=1752494814431609 (2025-07-14 05:06:54.431609 PDT)
/*!80001 SET @@session.original_commit_timestamp=1752494814375749*//*!*/;
/*!80014 SET @@session.original_server_version=80033*//*!*/;
/*!80014 SET @@session.immediate_server_version=80033*//*!*/;
SET @@SESSION.GTID_NEXT= '00030001-1111-1111-1111-111111111111:6'/*!*/;
# at 2095
#250714  5:06:54 server id 30001  end_log_pos 2163 CRC32 0x4a03e19e     Query   thread_id=11    exec_time=0     error_code=0
SET TIMESTAMP=1752494814/*!*/;
SET @@session.auto_increment_increment=1, @@session.auto_increment_offset=1/*!*/;
BEGIN
/*!*/;
# at 2163
#250714  5:06:54 server id 30001  end_log_pos 2232 CRC32 0x71e9ad2e     Query   thread_id=11    exec_time=0     error_code=0
SET TIMESTAMP=1752494814/*!*/;
COMMIT
/*!*/;
SET @@SESSION.GTID_NEXT= 'AUTOMATIC' /* added by mysqlbinlog */ /*!*/;
DELIMITER ;
# End of log file
/*!50003 SET COMPLETION_TYPE=@OLD_COMPLETION_TYPE*/;
/*!50530 SET @@SESSION.PSEUDO_SLAVE_MODE=0*/;

b wsrep_register_for_group_commit
commands
silent
printf"Id %d [ Xid %d ] register\n", thd->m_thread_id, thd->m_wsrep_client_state.transaction_.ws_meta_.gtid_.seqno_.seqno_
cont
end

b wsrep_unregister_from_group_commit
commands
silent
printf"Id %d [ Xid %d ] leaves\n", thd->m_thread_id, thd->m_wsrep_client_state.transaction_.ws_meta_.gtid_.seqno_.seqno_
cont
end

b wsrep_wait_for_turn_in_group_commit
commands
silent
printf"Id %d [ Xid %d ] wait\n", thd->m_thread_id, thd->m_wsrep_client_state.transaction_.ws_meta_.gtid_.seqno_.seqno_
cont
end


b innobase_commit
commands
silent
printf"Id %d [ Xid %d ] innobase_commit\n", thd->m_thread_id, thd->m_wsrep_client_state.transaction_.ws_meta_.gtid_.seqno_.seqno_
cont
end


b ha_commit_low
commands
silent
printf"Id %d [ Xid %d ] enters ha_commit_low\n", thd->m_thread_id, thd->m_wsrep_client_state.transaction_.ws_meta_.gtid_.seqno_.seqno_
cont
end

b sql/handler.cc:2012
commands
silent
printf"Id %d [ Xid %d ] ha_list is not null \n", thd->m_thread_id, thd->m_wsrep_client_state.transaction_.ws_meta_.gtid_.seqno_.seqno_
cont
end

Id 21 [ Xid 4302 ] register
Id 15 [ Xid 4303 ] register
Id 16 [ Xid 4304 ] register
Id 17 [ Xid 4305 ] register
Id 21 [ Xid 4302 ] enters ha_commit_low
Id 18 [ Xid 4306 ] register
Id 21 [ Xid 4302 ] ha_list is not null
Id 21 [ Xid 4302 ] innobase_commit
Id 21 [ Xid 4302 ] wait
Id 21 [ Xid 4302 ] leaves
Id 15 [ Xid 4303 ] enters ha_commit_low
Id 16 [ Xid 4304 ] enters ha_commit_low
Id 16 [ Xid 4304 ] ha_list is not null
Id 16 [ Xid 4304 ] innobase_commit
Id 16 [ Xid 4304 ] wait
Id 22 [ Xid 4307 ] register

dbdeployer deploy --topology=pxc replication --base-port=10000 --base-server-id=10000 pxc8.0.33
dbdeployer deploy --gtid replication --base-port=30000 --base-server-id=30000 pxc8.0.33

node1_port=10001   # the port of the node 1 in the PXC
master_port=30001  # the port of the master node in the replication

alias node1_cmd="mysql --prompt='(node1)[db: \d] ' -A -umsandbox -pmsandbox -h127.0.0.1 -P${node1_port}"
alias master_cmd="mysql --prompt='(master)[db: \d] ' -A -umsandbox -pmsandbox -h127.0.0.1 -P${master_port}"

cat << EOF | node1_cmd
CHANGE MASTER TO master_host="127.0.0.1",
MASTER_PORT=${master_port},
MASTER_USER="rsandbox",
MASTER_PASSWORD="rsandbox",
MASTER_AUTO_POSITION = 1;
start slave;
EOF

master_cmd -BNe "create table test.t (id int auto_increment, d int, primary key (id));insert into test.t (id,d) values (1,0);"

for i in {1..1000};
do
    node1_cmd  -BNe "update test.t set d = d+1 where id = 1;" &> /dev/null
    master_cmd -BNe "update test.t set d = d+1 where id = 1;" &> /dev/null
done

sysbench oltp_insert --threads=10 --time=600 --tables=1 --table-size=1000 \
--db-driver=mysql --mysql-db=test --mysql-storage-engine=innodb --report-interval=10 \
--mysql-user=msandbox --mysql-password=msandbox --mysql-host=127.0.0.1 --mysql-port=${node1_port} \
prepare
sysbench oltp_insert --threads=10 --time=600 --tables=1 --table-size=1000 \
--db-driver=mysql --mysql-db=test --mysql-storage-engine=innodb --report-interval=10 \
--mysql-user=msandbox --mysql-password=msandbox --mysql-host=127.0.0.1 --mysql-port=${node1_port} \
run

Initializing worker threads...

Threads started!

[ 10s ] thds: 10 tps: 42.77 qps: 42.77 (r/w/o: 0.00/42.77/0.00) lat (ms,95%): 623.33 err/s: 0.00 reconn/s: 0.00
[ 20s ] thds: 10 tps: 37.00 qps: 37.00 (r/w/o: 0.00/37.00/0.00) lat (ms,95%): 549.52 err/s: 0.00 reconn/s: 0.00
[ 30s ] thds: 10 tps: 23.40 qps: 23.40 (r/w/o: 0.00/23.40/0.00) lat (ms,95%): 634.66 err/s: 0.00 reconn/s: 0.00
[ 40s ] thds: 10 tps: 0.00 qps: 0.00 (r/w/o: 0.00/0.00/0.00) lat (ms,95%): 0.00 err/s: 0.00 reconn/s: 0.00
[ 50s ] thds: 10 tps: 0.00 qps: 0.00 (r/w/o: 0.00/0.00/0.00) lat (ms,95%): 0.00 err/s: 0.00 reconn/s: 0.00

--Thread 140617271166720 has waited at trx0rseg.ic line 51 for 13 seconds the semaphore:
X-lock on RW-latch at 0x7fe40fd3cdf8 created in file buf0buf.cc line 815
a writer (thread id 140617197684480) has reserved it in mode exclusive
number of readers 0, waiters flag 1, lock_word: 0
Last time read locked in file not yet reserved line 0
Last time write locked in file /mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/storage/innobase/include/trx0rseg.ic line 51
--Thread 140617724176128 has waited at buf0flu.cc line 1376 for 10 seconds the semaphore:
SX-lock on RW-latch at 0x7fe40fd3d0d8 created in file buf0buf.cc line 815
a writer (thread id 140617197684480) has reserved it in mode exclusive
number of readers 0, waiters flag 1, lock_word: 0
Last time read locked in file not yet reserved line 0
Last time write locked in file /mnt/jenkins/workspace/pxc80-autobuild-RELEASE/test/Percona-XtraDB-Cluster-8.0.33-25/storage/innobase/include/trx0undo.ic line 126

---TRANSACTION 4417, ACTIVE (PREPARED) 14 sec committing
mysql tables in use 1, locked 1
1 lock struct(s), heap size 1128, 0 row lock(s), undo log entries 1
MySQL thread id 70, OS thread handle 140617197684480, query id 1411 localhost 127.0.0.1 msandbox innobase_commit_low (1218)
INSERT INTO sbtest1 (id, k, c, pad) VALUES (0, 504, '57904754910-88624042600-21941801151-17844023199-16047046883-99245408053-22028087049-26597707866-59381249459-19610307722', '33663561666-47879788257-03701217268-04391412711-14170077666')
--------
