仿高德地图实现输入起点和终点规划路径并可切换

<template>
  <div class="container">
    <div class="query">
      <el-form :model="form" label-width="auto" class="query-form">
        <el-form-item label="起点" class="form-start-position">
          <el-autocomplete
            v-model="form.startPosition"
            :fetch-suggestions="querySearchStart"
            clearable
            placeholder="请输入起点位置"
            @select="handleSelectStart"
          >
            <template #default="{ item }">
              <div class="autocomplete-value">{{ item.value }}</div>
              <div class="autocomplete-address">{{ item.address }}</div>
            </template>
          </el-autocomplete>
        </el-form-item>
        <el-form-item label="终点" style="margin-bottom: 0" class="form-end-position">
          <el-autocomplete
            v-model="form.endPosition"
            :fetch-suggestions="querySearchEnd"
            clearable
            placeholder="请输入终点位置"
            @select="handleSelectEnd"
          >
            <template #default="{ item }">
              <div class="autocomplete-value">{{ item.value }}</div>
              <div class="autocomplete-address">{{ item.address }}</div>
            </template>
          </el-autocomplete>
        </el-form-item>
      </el-form>
      <div class="query-button">
        <el-button :disabled="!form.startPosition || !form.endPosition" class="query-button-inner" @click="queryRoute">
          查询
        </el-button>
        <!-- <el-button class="query-button-inner" @click="queryRoute">查询</el-button> -->
      </div>
    </div>
    <div class="map" id="map">
      <div class="routes" v-show="features.length > 0">
        <div
          v-for="(feature, index) of features"
          :key="index"
          :class="index === selectedIndex ? 'route active' : 'route'"
          @click="updateIndex(index)"
        >
          <div class="cost">{{ Math.ceil(feature.properties.cost / 60) }}分钟</div>
          <div>{{ feature.properties.distance }}公里</div>
          <div>{{ index === 0 ? '大众常选' : '方案' + index }}</div>
        </div>
      </div>
    </div>
  </div>
</template>

<script>


import { ElMessage } from 'element-plus'
import * as turf from '@turf/turf'

let map = null
const layerId = 'my-route'

function request(url, params) {
  const AK = '你申请的AK值'
  const BASE_URL = 'https://restapi.amap.com/'
  let fullUrl = url.indexOf('json') === -1 ? `${BASE_URL}${url}?key=${AK}` : url
  for (const key in params) {
    fullUrl += `&${key}=${params[key]}`
  }
  return new Promise((resolve, reject) => {
    fetch(fullUrl)
      .then(res => res.json())
      .then(res => {
        if (res.status === '1') resolve(res)
        else {
          ElMessage.error('接口请求失败')
          reject(res)
        }
      })
  })
}

export default {
  data() {
    return {
      center: [113.94150905808976, 22.523881824251347],
      form: {
        startPosition: '',
        endPosition: '',
        startCoord: [],
        endCoord: [],
      },
      cityInfo: {},
      features: [],
      selectedIndex: 0,
      path: null,
    }
  },
  mounted() {
    const that = this
    function successFunc(position) {
      const { longitude, latitude } = position.coords
      that.center = [longitude, latitude]
      that.initMap()
    }
    function errFunc() {
      that.initMap()
    }
    if (navigator.geolocation) {
      try {
        errFunc()
        navigator.geolocation.getCurrentPosition(successFunc, errFunc)
      } catch (e) {
        errFunc()
      }
    } else {
      errFunc()
    }
  },
  methods: {
    initMap() {
      map = new SFMap.Map({
        container: 'map',
        center: this.center,
        zoom: 17.1,
      })
      map.on('load', e => {
        map.addSource(layerId, {
          type: 'geojson',
          data: turf.featureCollection([]),
        })
        map.addSource(layerId + '-line', {
          type: 'geojson',
          data: turf.featureCollection([]),
        })
        map.addSource(layerId + '-border', {
          type: 'geojson',
          data: turf.featureCollection([]),
        })
        map.addLayer({
          id: layerId + '-border',
          type: 'line',
          source: layerId + '-border',
          layout: {
            'line-cap': 'round',
            'line-join': 'round',
          },
          paint: {
            'line-color': '#056113',
            'line-width': 13,
          },
        })
        map.addLayer({
          id: layerId + '-line',
          type: 'line',
          source: layerId + '-line',
          layout: {
            'line-cap': 'round',
            'line-join': 'round',
          },
          paint: {
            'line-color': '#80d18c',
            'line-width': 10,
          },
        })
        map.addLayer({
          id: layerId,
          type: 'line',
          source: layerId,
          layout: {
            'line-cap': 'round',
            'line-join': 'round',
          },
          paint: {
            'line-color': '#16ab2d',
            'line-width': 10,
          },
        })

        map.on('mousemove', layerId + '-line', e => {
          map.getCanvas().style.cursor = 'pointer'
        })
        map.on('mouseout', layerId + '-line', e => {
          map.getCanvas().style.cursor = ''
        })
        map.on('click', layerId + '-line', e => {
          const feature = e.features[0]
          this.selectedIndex = feature.properties.index
          this.setShowRoute()
        })
        map.loadImage(arrow, function (error, image) {
          if (error) throw error
          map.addImage(layerId + '-arrow', image)
          map.addLayer({
            id: layerId + '-line-arrow',
            source: layerId + '-line',
            type: 'symbol',
            layout: {
              'symbol-placement': 'line',
              'symbol-spacing': 50,
              'icon-image': layerId + '-arrow',
              'icon-size': 0.6,
              'icon-allow-overlap': true,
            },
          })
          map.addLayer({
            id: layerId + '-arrow',
            source: layerId,
            type: 'symbol',
            layout: {
              'symbol-placement': 'line',
              'symbol-spacing': 50,
              'icon-image': layerId + '-arrow',
              'icon-size': 0.6,
              'icon-allow-overlap': true,
            },
          })
        })
        request('v3/geocode/regeo', {
          location: this.center.join(','),
        }).then(res => {
          this.cityInfo = res.regeocode.addressComponent
        })
      })
    },
    querySearchStart(str, cb) {
      if (str) {
        request('v3/assistant/inputtips', {
          keywords: str,
          city: this.cityInfo?.city,
        }).then(res => {
          cb(
            res.tips.map(t => {
              t.value = t.name
              return t
            }),
          )
        })
      } else {
        cb([])
      }
    },
    querySearchEnd(str, cb) {
      if (str) {
        request('v3/assistant/inputtips', {
          keywords: str,
          city: this.cityInfo?.city,
        }).then(res => {
          cb(
            res.tips.map(t => {
              t.value = t.name
              return t
            }),
          )
        })
      } else {
        cb([])
      }
    },
    handleSelectStart(item) {
      this.form.startCoord = item.location.split(',').map(Number)
    },
    handleSelectEnd(item) {
      this.form.endCoord = item.location.split(',').map(Number)
    },
    queryRoute() {
      const { startCoord, endCoord } = this.form
      // request('./data.json', {
      // }).then(res => {
      request('v5/direction/driving', {
        origin: startCoord.join(','),
        destination: endCoord.join(','),
        show_fields: 'polyline,cost',
      }).then(res => {
        const paths = res.route.paths
        let features = paths.map((path, index) => {
          let coordinates = []
          path.steps.forEach(step => {
            const polyline = step.polyline.split(';').map(c => c.split(',').map(Number))
            coordinates = [...coordinates, ...polyline]
          })
          return {
            type: 'Feature',
            properties: {
              index,
              distance: path.distance,
              cost: path?.duration || path?.cost.duration,
            },
            geometry: {
              type: 'LineString',
              coordinates: coordinates,
            },
          }
        })
        this.features = features
        map.getSource(layerId + '-border').setData(turf.featureCollection(features))
        this.setShowRoute()
      })
    },
    updateIndex(index) {
      if (this.selectedIndex === index) return
      this.selectedIndex = index
      this.setShowRoute()
    },
    setShowRoute() {
      const feature = this.features[this.selectedIndex]
      this.path = feature.properties
      map.getSource(layerId).setData(feature)
      const features = this.features.filter((f, i) => i !== this.selectedIndex)
      map.getSource(layerId + '-line').setData(turf.featureCollection(features))
      map.fitBounds(turf.bbox(feature), { padding: { top: 50, bottom: 220, left: 50, right: 50 } })
    },
  },
}
</script>

<style scoped lang="scss">
.container {
  width: 100%;
  height: 100vh;
  overflow: hidden;
}
.query {
  padding: 0.8rem;
  overflow: hidden;
  background: #ccc;
  .query-form {
    width: calc(100% - 4rem);
    float: left;
  }
  .query-button {
    width: 4rem;
    height: 4.7rem;
    float: right;
    display: flex;
    justify-content: flex-end;
    align-items: center;
    .query-button-inner {
      width: 3.8rem;
      height: 100%;
    }
  }
}
.map {
  height: calc(100% - 6.4rem);
}

.autocomplete-value,
.autocomplete-address {
  white-space: nowrap;
  width: 100%;
  overflow: hidden;
  text-overflow: ellipsis;
}
.autocomplete-address {
  font-size: 0.8rem;
  color: #999;
  margin-top: -0.8rem;
  border-bottom: 1px solid #efefef;
}
.routes {
  position: absolute;
  bottom: 0;
  left: 0;
  width: 100%;
  z-index: 99;
  padding: 1rem;
  box-sizing: border-box;
  background: rgba(255, 255, 255, 0.9);
  text-align: left;
  display: flex;
  flex-direction: row;
  font-size: 0.95rem;
  .route {
    flex-grow: 1;
    border-radius: 0.5rem;
    line-height: 1.8;
    padding: 0.5rem 1rem;
    cursor: pointer;
    border-right: 1px solid #efefef;
    &:last-child {
      margin-right: 0;
      border-right: none;
    }
    .cost {
      font-size: 1.35rem;
      font-weight: bold;
    }
    &.active {
      color: #409eff;
      background: #e3effa;
    }
  }
}
:deep .el-form-item {
  margin-bottom: 0.5rem;
}
</style>
<style lang="scss">
.my-custom-popover-class {
  background-color: rgba(1, 122, 242, 0.8);
  color: #fff;

  .driver-popover-arrow-side-top {
    border-top-color: rgba(1, 122, 242, 0.8);
  }
  .driver-popover-arrow-side-bottom {
    border-bottom-color: rgba(1, 122, 242, 0.8);
  }
  .driver-popover-arrow-side-left {
    border-left-color: rgba(1, 122, 242, 0.8);
  }
  .driver-popover-arrow-side-right {
    border-right-color: rgba(1, 122, 242, 0.8);
  }

  .driver-popover-progress-text,
  .driver-popover-close-btn {
    color: #fff;
  }

  .driver-popover-prev-btn,
  .driver-popover-next-btn {
    border: 1px solid #fff;
    color: rgba(1, 122, 242, 1);
  }
}
</style>
