基本上iPaaS平台都会通过提供预构建的连接器和适配器，简化系统和应用程序之间的连接。实现业务拉通和协同。Conductor里面的自定义Worker可以理解为业务的连接器。下面是英文的说明：

Simple Tasks or Worker Tasks are implemented by your application and run in a separate environment from Conductor. These tasks talk to the Conductor server via REST/gRPC to poll for tasks and update its status after execution.

1.增加conductor-client-spring 依赖在你的SpringBoot项目里面

<dependency>
    <groupId>org.conductoross</groupId>
    <artifactId>conductor-client-spring</artifactId>
    <version>4.0.1</version>
</dependency>

这里要用4.0.1版本，4.0版本不支持SpringBoot。

2.增加com.netflix.conductor component scan packages

import org.springframework.boot.autoconfigure.SpringBootApplication;;
import org.springframework.context.annotation.ComponentScan;

@SpringBootApplication
@ComponentScan(basePackages = {"com.netflix.conductor"})
public class MyApp {

}

3.在client项目里面配置application.properties

conductor.client.rootUri=http://localhost:8080/api

4.新建一个SampleWork 实现 Conductor Worker

@Component
public class SampleWorker implements Worker {

    @Override
    public String getTaskDefName() {
        return "sample-worker";
    }

    @Override
    public TaskResult execute(Task task) {
        log.info("sample-worker executed {}", task.getWorkflowInstanceId());
        return TaskResult.newTaskResult(TaskResult.Status.COMPLETED)
                .addOutputData("sample-worker", "successful");
    }


}

5.任务管理里面定义Task

{
	"name": "sample-worker",
	"description": "Edit or extend this sample task. Set the task name to get started",
	"retryCount": 3,
	"timeoutSeconds": 3600,
	"inputKeys": [],
	"outputKeys": [],
	"timeoutPolicy": "TIME_OUT_WF",
	"retryLogic": "FIXED",
	"retryDelaySeconds": 60,
	"responseTimeoutSeconds": 600,
	"inputTemplate": {},
	"rateLimitPerFrequency": 0,
	"rateLimitFrequencyInSeconds": 1,
	"ownerEmail": "xx@qq.com",
	"backoffScaleFactor": 1,
	"totalTimeoutSeconds": 0,
	"enforceSchema": false
}

6.WorkFlow引入对应的Task，对应的Type为SIMPLE

{
	"name": "workflow",
	"description": "test Workflow",
	"version": 1,
	"tasks": [{
		"name": "sample-worker",
		"taskReferenceName": "sample-worker",
		"inputParameters": {},
		"type": "SIMPLE"
	}],
	"outputParameters": {},
	"failureWorkflow": "",
	"restartable": true,
	"workflowStatusListenerEnabled": true,
	"ownerEmail": "conductor@example.com",
	"timeoutPolicy": "ALERT_ONLY",
	"timeoutSeconds": 0,
	"variables": {},
	"inputTemplate": {}
}

根据接口或者界面触发workflow就可以触发对应的自定义worker了。连接器作为iPaaS平台的核心组件之一，在其中扮演着至关重要的角色。它是一种预构建的组件，用于简化和加速不同应用程序、服务和系统之间的集成，无缝集成到企业的IT生态系统中。连接器的功能：
