前言
InfluxDB 是一款高性能的时序数据库，见长于标量的时序存储
类似于 Elasticsearch 的 ELK 技术栈，InfluxDB 也有一套 TICK 技术栈
其中 Chronograf 是展示数据的前端 UI 组件
Chronograf is the user interface component of InfluxData’s TICK Stack. It makes the monitoring and alerting for your infrastructure easy to setup and maintain. It is simple to use and includes templates and libraries to allow you to rapidly build dashboards with real-time visualizations of your data
这里分享一下 Chronograf 的安装方法
Tip: 当前的版本为 chronograf-1.4.1.2
操作
环境
[root@much ~]# hostnamectl
Static hostname: much
Icon name: computer-vm
Chassis: vm
Machine ID: 33dc28f7e76c4903ad9b603b77e29a7c
Boot ID: 1f9d9f1fc29440c8874b993d9455c898
Virtualization: kvm
Operating System: CentOS Linux 7 (Core)
CPE OS Name: cpe:/o:centos:centos:7
Kernel: Linux 3.10.0-514.21.1.el7.x86_64
Architecture: x86-64
[root@much ~]# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN qlen 1
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
2: enp0s3: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000
link/ether 08:00:27:e3:df:87 brd ff:ff:ff:ff:ff:ff
inet 10.0.2.15/24 brd 10.0.2.255 scope global dynamic enp0s3
valid_lft 83032sec preferred_lft 83032sec
3: enp0s8: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000
link/ether 08:00:27:d3:ec:e7 brd ff:ff:ff:ff:ff:ff
inet 192.168.56.208/24 brd 192.168.56.255 scope global enp0s8
valid_lft forever preferred_lft forever
4: virbr0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN qlen 1000
link/ether 52:54:00:16:5e:11 brd ff:ff:ff:ff:ff:ff
inet 192.168.122.1/24 brd 192.168.122.255 scope global virbr0
valid_lft forever preferred_lft forever
5: virbr0-nic: <BROADCAST,MULTICAST> mtu 1500 qdisc pfifo_fast master virbr0 state DOWN qlen 1000
link/ether 52:54:00:16:5e:11 brd ff:ff:ff:ff:ff:ff
[root@much ~]#配置仓库
[root@much ~]# cat <<EOF | sudo tee /etc/yum.repos.d/influxdb.repo
> [influxdb]
> name = InfluxDB Repository - RHEL \$releasever
> baseurl = https://repos.influxdata.com/rhel/\$releasever/\$basearch/stable
> enabled = 1
> gpgcheck = 1
> gpgkey = https://repos.influxdata.com/influxdb.key
> EOF
[influxdb]
name = InfluxDB Repository - RHEL $releasever
baseurl = https://repos.influxdata.com/rhel/$releasever/$basearch/stable
enabled = 1
gpgcheck = 1
gpgkey = https://repos.influxdata.com/influxdb.key
[root@much ~]# cat /etc/yum.repos.d/influxdb.repo
[influxdb]
name = InfluxDB Repository - RHEL $releasever
baseurl = https://repos.influxdata.com/rhel/$releasever/$basearch/stable
enabled = 1
gpgcheck = 1
gpgkey = https://repos.influxdata.com/influxdb.key
[root@much ~]#依赖
在 TICK 技术栈中，Chronograf 的正常工作依赖 InfluxDB
Telegraf 是建议安装的，但并非必要，因为它可以为系统不断提供新数据
Kapacitor 是可选安装的，数据处理与报警处理等高级功能才需要依赖它
安装软件
[root@much telegraf]# rpm -qa | grep influx
influxdb-1.4.2-1.x86_64
[root@much telegraf]# yum list all | grep influx
influxdb.x86_64 1.4.2-1 @influxdb
telegraf.x86_64 1.5.2-1 @influxdb
chronograf.x86_64 1.4.0.0-1 influxdb
kapacitor.x86_64 1.4.0-1 influxdb
pcp-export-pcp2influxdb.x86_64 3.11.8-7.el7 base
[root@much telegraf]# yum install chronograf.x86_64
Loaded plugins: fastestmirror, langpacks
base | 3.6 kB 00:00:00
c7-media | 3.6 kB 00:00:00
epel/x86_64/metalink | 7.3 kB 00:00:00
epel | 4.7 kB 00:00:00
extras | 3.4 kB 00:00:00
influxdb | 2.5 kB 00:00:00
kibana-6.x | 1.3 kB 00:00:00
updates | 3.4 kB 00:00:00
(1/2): epel/x86_64/updateinfo | 880 kB 00:00:03
(2/2): epel/x86_64/primary_db | 6.2 MB 00:00:29
Loading mirror speeds from cached hostfile
* base: mirror.pregi.net
* c7-media:
* epel: mirror.pregi.net
* extras: mirror.pregi.net
* updates: mirror.pregi.net
Resolving Dependencies
--> Running transaction check
---> Package chronograf.x86_64 0:1.4.0.0-1 will be installed
--> Finished Dependency Resolution
Dependencies Resolved
==============================================================================================================
Package Arch Version Repository Size
==============================================================================================================
Installing:
chronograf x86_64 1.4.0.0-1 influxdb 7.6 M
Transaction Summary
==============================================================================================================
Install 1 Package
Total download size: 7.6 M
Installed size: 7.6 M
Is this ok [y/d/N]: y
Downloading packages:
chronograf-1.4.0.0.x86_64.rpm | 7.6 MB 00:00:22
Running transaction check
Running transaction test
Transaction test succeeded
Running transaction
Installing : chronograf-1.4.0.0-1.x86_64 1/1
Created symlink from /etc/systemd/system/multi-user.target.wants/chronograf.service to /usr/lib/systemd/system/chronograf.service.
Verifying : chronograf-1.4.0.0-1.x86_64 1/1
Installed:
chronograf.x86_64 0:1.4.0.0-1
Complete!
[root@much telegraf]# echo $?
0
[root@much telegraf]# rpm -qa | grep chronograf
chronograf-1.4.0.0-1.x86_64
[root@much telegraf]#可以看看有些什么东西
[root@much telegraf]# rpm -ql chronograf-1.4.0.0-1.x86_64
/etc/logrotate.d/chronograf
/usr/bin/chronograf
/usr/lib/chronograf/scripts/chronograf.service
/usr/lib/chronograf/scripts/init.sh
/usr/share/chronograf/canned/apache.json
/usr/share/chronograf/canned/consul.json
/usr/share/chronograf/canned/consul_agent.json
/usr/share/chronograf/canned/consul_cluster.json
/usr/share/chronograf/canned/consul_election.json
/usr/share/chronograf/canned/consul_http.json
/usr/share/chronograf/canned/consul_leadership.json
/usr/share/chronograf/canned/consul_serf_events.json
/usr/share/chronograf/canned/cpu.json
/usr/share/chronograf/canned/disk.json
/usr/share/chronograf/canned/diskio.json
/usr/share/chronograf/canned/docker.json
/usr/share/chronograf/canned/docker_blkio.json
/usr/share/chronograf/canned/docker_net.json
/usr/share/chronograf/canned/elasticsearch.json
/usr/share/chronograf/canned/haproxy.json
/usr/share/chronograf/canned/influxdb_database.json
/usr/share/chronograf/canned/influxdb_httpd.json
/usr/share/chronograf/canned/influxdb_queryExecutor.json
/usr/share/chronograf/canned/influxdb_write.json
/usr/share/chronograf/canned/kubernetes_node.json
/usr/share/chronograf/canned/kubernetes_pod_container.json
/usr/share/chronograf/canned/kubernetes_pod_network.json
/usr/share/chronograf/canned/kubernetes_system_container.json
/usr/share/chronograf/canned/load.json
/usr/share/chronograf/canned/mem.json
/usr/share/chronograf/canned/memcached.json
/usr/share/chronograf/canned/mesos.json
/usr/share/chronograf/canned/mongodb.json
/usr/share/chronograf/canned/mysql.json
/usr/share/chronograf/canned/net.json
/usr/share/chronograf/canned/netstat.json
/usr/share/chronograf/canned/nginx.json
/usr/share/chronograf/canned/nsq_channel.json
/usr/share/chronograf/canned/nsq_server.json
/usr/share/chronograf/canned/nsq_topic.json
/usr/share/chronograf/canned/phpfpm.json
/usr/share/chronograf/canned/ping.json
/usr/share/chronograf/canned/postgresql.json
/usr/share/chronograf/canned/processes.json
/usr/share/chronograf/canned/procstat.json
/usr/share/chronograf/canned/rabbitmq.json
/usr/share/chronograf/canned/redis.json
/usr/share/chronograf/canned/riak.json
/usr/share/chronograf/canned/varnish.json
/usr/share/chronograf/canned/win_cpu.json
/usr/share/chronograf/canned/win_mem.json
/usr/share/chronograf/canned/win_net.json
/usr/share/chronograf/canned/win_system.json
/usr/share/chronograf/canned/win_websvc.json
/var/lib/chronograf
/var/log/chronograf
[root@much telegraf]#启动服务
[root@much telegraf]# systemctl status chronograf.service
● chronograf.service - Open source monitoring and visualization UI for the entire TICK stack.
Loaded: loaded (/usr/lib/systemd/system/chronograf.service; enabled; vendor preset: disabled)
Active: inactive (dead)
Docs: https://www.influxdata.com/time-series-platform/chronograf/
[root@much telegraf]# systemctl start chronograf.service
[root@much telegraf]# systemctl status chronograf.service
● chronograf.service - Open source monitoring and visualization UI for the entire TICK stack.
Loaded: loaded (/usr/lib/systemd/system/chronograf.service; enabled; vendor preset: disabled)
Active: active (running) since 三 2018-02-14 22:58:22 CST; 2s ago
Docs: https://www.influxdata.com/time-series-platform/chronograf/
Main PID: 5066 (chronograf)
CGroup: /system.slice/chronograf.service
└─5066 /usr/bin/chronograf --host 0.0.0.0 --port 8888 -b /var/lib/chronograf/chronograf-v1.db -c...
2月 14 22:58:22 much systemd[1]: Started Open source monitoring and visualization UI for the entire T...ack..
2月 14 22:58:22 much systemd[1]: Starting Open source monitoring and visualization UI for the entire ...k....
2月 14 22:58:22 much chronograf[5066]: time="2018-02-14T22:58:22+08:00" level=info msg="Serving chrono...rver
2月 14 22:58:22 much chronograf[5066]: time="2018-02-14T22:58:22+08:00" level=info msg="Reporting usag...ime"
Hint: Some lines were ellipsized, use -l to show in full.
[root@much telegraf]# ps faux | grep chronograf
root 5084 0.0 0.0 112660 1020 pts/0 S+ 22:58 0:00 \_ grep --color=auto chronograf
chronog+ 5066 0.5 0.2 218840 10852 ? Ssl 22:58 0:00 /usr/bin/chronograf --host 0.0.0.0 --port 8888 -b /var/lib/chronograf/chronograf-v1.db -c /usr/share/chronograf/canned
[root@much telegraf]# netstat -antp
Active Internet connections (servers and established)
Proto Recv-Q Send-Q Local Address Foreign Address State PID/Program name
tcp 0 0 127.0.0.1:9200 0.0.0.0:* LISTEN 1318/java
tcp 0 0 127.0.0.1:9300 0.0.0.0:* LISTEN 1318/java
tcp 0 0 192.168.122.1:53 0.0.0.0:* LISTEN 1544/dnsmasq
tcp 0 0 0.0.0.0:22 0.0.0.0:* LISTEN 1317/sshd
tcp 0 0 127.0.0.1:631 0.0.0.0:* LISTEN 1313/cupsd
tcp 0 0 127.0.0.1:8088 0.0.0.0:* LISTEN 1320/influxd
tcp 0 0 10.0.2.15:50254 104.131.151.204:443 ESTABLISHED 5066/chronograf
tcp 0 0 127.0.0.1:49498 127.0.0.1:8086 ESTABLISHED 4943/telegraf
tcp 0 0 192.168.56.208:22 192.168.56.1:44842 ESTABLISHED 1876/sshd: root@pts
tcp6 0 0 :::8086 :::* LISTEN 1320/influxd
tcp6 0 0 :::22 :::* LISTEN 1317/sshd
tcp6 0 0 :::8888 :::* LISTEN 5066/chronograf
tcp6 0 0 :::3000 :::* LISTEN 1319/grafana-server
tcp6 0 0 127.0.0.1:8086 127.0.0.1:49498 ESTABLISHED 1320/influxd
[root@much telegraf]#可以看到 chronograf 监听在了本地的 8888 端口
打开防火墙
[root@much telegraf]# firewall-cmd --list-all
public (active)
target: default
icmp-block-inversion: no
interfaces: enp0s3 enp0s8
sources:
services: dhcpv6-client ssh
ports: 3000/tcp 8080/tcp 5601/tcp
protocols:
masquerade: no
forward-ports:
sourceports:
icmp-blocks:
rich rules:
[root@much telegraf]# firewall-cmd --add-port 8888/tcp --permanent
success
[root@much telegraf]# firewall-cmd --reload
success
[root@much telegraf]# firewall-cmd --list-all
public (active)
target: default
icmp-block-inversion: no
interfaces: enp0s3 enp0s8
sources:
services: dhcpv6-client ssh
ports: 3000/tcp 8888/tcp 8080/tcp 5601/tcp
protocols:
masquerade: no
forward-ports:
sourceports:
icmp-blocks:
rich rules:
[root@much telegraf]#进行访问
Username 和 Password 可以为空
查看 hostlist
进入可以查看主机的负载信息(由telegraf在默认配置下收集的标量信息)
也可以交互式探索数据
非常直观易用，上面是查询语句，中间是标量信息，下面是图形
总结
chronograf 作为 influxdb 的前端数据展示组件，与 influxdb 的对接非常简单(默认不作配置都是直接连接的本地 influxdb)
界面简洁美观，和 grafana 风格比较像
