瑞芯微RK3506核心板详细规格参数

SOC

RockChip RK3506B/RK3506J

CPU

三核 Cortex-A7+单核Cortex-M0, 主频最高1.5GHz

GPU

2D Graphic Engine

内存

256MB/512MB/1GB DDR3/DDR3L 16bit

存储

1256MB/512MB NAND 28GB eMMC以上配置二选一

硬件参数

以太网

2 × RMII 扩展2路百兆以太网

显示接口

视频输出：1 x RGB (1280×1280@60fps)1 x MIPI_DSI_TX(2Lane Ouput/1.5Gbps per Lane,1280×1280@60fps)

音频接口

4 × SAI1 × PDM2 x DSM2 x SPDIF1 x MIC

USB

2 × USB2.0 OTG

扩展接口

6 × UART3 × SPI2 × CAN FD3 × I2C12 × PWM4 × SARADC1 × FLEXBUS1 × FSPI（和NAND FLASH版本复用）1 × SDIO（和eMMC版本复用）93 × GPIO

其他

主板尺寸

38mm × 38mm × 2.6mm

接口类型

128Pin 间距1.1mm邮票孔

PCB规格

板厚 1.4mm , 8 层板 高Tg材质，沉金工艺

工作温度

-20~+80℃(RK3506B 宽温级)-40~+85℃ (RK3506J 工业级)

工作湿度

5%~90% RH 非冷凝

存储温度

-40℃～+85℃

1

Linux

/

2

OpenHarmony

L1小型系统

VCC5V0_SYS

4.5V

5.0V

5.4V

120mA

15mA

VCC_1V8_OUT

1.7V

1.8V

1.9V

100mA

VCC_3V3_OUT

3.0V

3.3V

3.6V

100mA

IDO-SOM3506-S1-D256N256-C

256MB

256MB

-20℃～+80℃

IDO-SOM3506-S1-D256N512-C

256MB

512MB

-20℃～+80℃

IDO-SOM3506-S1-D512N512-C

512MB

512MB

-20℃～+80℃

IDO-SOM3506-S1-D512E8-C

512MB

8GB

-20℃～+80℃

IDO-SOM3506-S1-D256N256-I

256MB

256MB

-40℃～+85℃

IDO-SOM3506-S1-D256N512-I

256MB

512MB

-40℃～+85℃

IDO-SOM3506-S1-D512N512-I

512MB

512MB

-40℃～+85℃

IDO-SOM3506-S1-D512E8-I

512MB

8GB

-40℃～+85℃

VCC5V0_SYS

4.5V

5.0V

5.4V

120mA

15mA

VCC_1V8_OUT

1.7V

1.8V

1.9V

100mA

VCC_3V3_OUT

3.0V

3.3V

3.6V

100mA

IDO-SOM3506-S1-D256N256-C

256MB

256MB

-20℃～+80℃

IDO-SOM3506-S1-D256N512-C

256MB

512MB

-20℃～+80℃

IDO-SOM3506-S1-D512N512-C

512MB

512MB

-20℃～+80℃

IDO-SOM3506-S1-D512E8-C

512MB

8GB

-20℃～+80℃

IDO-SOM3506-S1-D256N256-I

256MB

256MB

-40℃～+85℃

IDO-SOM3506-S1-D256N512-I

256MB

512MB

-40℃～+85℃

IDO-SOM3506-S1-D512N512-I

512MB

512MB

-40℃～+85℃

IDO-SOM3506-S1-D512E8-I

512MB

8GB

-40℃～+85℃

VCC5V0_SYS

4.5V

5.0V

5.4V

120mA

15mA

VCC_1V8_OUT

1.7V

1.8V

1.9V

100mA

VCC_3V3_OUT

3.0V

3.3V

3.6V

100mA

IDO-SOM3506-S1-D256N256-C

256MB

256MB

-20℃～+80℃

IDO-SOM3506-S1-D256N512-C

256MB

512MB

-20℃～+80℃

IDO-SOM3506-S1-D512N512-C

512MB

512MB

-20℃～+80℃

IDO-SOM3506-S1-D512E8-C

512MB

8GB

-20℃～+80℃

IDO-SOM3506-S1-D256N256-I

256MB

256MB

-40℃～+85℃

IDO-SOM3506-S1-D256N512-I

256MB

512MB

-40℃～+85℃

IDO-SOM3506-S1-D512N512-I

512MB

512MB

-40℃～+85℃

IDO-SOM3506-S1-D512E8-I

512MB

8GB

-40℃～+85℃

Signal Name

Mode

1

DSMC_SLV_D2/FLEXBUS0_D7/DSMC_D11/VO_LCDC_D7/GPIO1_C4_d

C1

DSMC_SLV_D2

3.3v

FLEXBUS0_D7

DSMC_D11

VO_LCDC_D7

Default

GPIO1_C4_d

2

DSMC_SLV_D3/FLEXBUS0_D6/DSMC_D12/VO_LCDC_D6/GPIO1_C5_d

D3

DSMC_SLV_D3

3.3v

FLEXBUS0_D6

DSMC_D12

VO_LCDC_D6

Default

GPIO1_C5_d

3

DSMC_SLV_D4/FLEXBUS0_D5/DSMC_D13/VO_LCDC_D5/GPIO1_C6_d

E3

DSMC_SLV_D4

3.3v

FLEXBUS0_D5

DSMC_D13

VO_LCDC_D5

Default

GPIO1_C6_d

4

DSMC_SLV_D5/FLEXBUS0_D4/DSMC_D14/VO_LCDC_D4/GPIO1_C7_d

E2

DSMC_SLV_D5

3.3v

FLEXBUS0_D4

DSMC_D14

VO_LCDC_D4

Default

GPIO1_C7_d

5

GND5

GND5

GND

6

DSMC_SLV_D6/DSM_AUD_LN_M0/FLEXBUS0_D3/DSMC_D15/VO_LCDC_D3/GPIO1_D0_d

E1

DSMC_SLV_D6

3.3v

DSM_AUD_LN_M0

FLEXBUS0_D3

DSMC_D15

VO_LCDC_D3

Default

GPIO1_D0_d

7

DSMC_SLV_D7/RM_IO29/UART5_RTSN_M1/DSM_AUD_LP_M0/FLEXBUS0_D2/DSMC_DQS1/VO_LCDC_D2/GPIO1_D1_d

F3

DSMC_SLV_D7

3.3v

RM_IO29

UART5_RTSN_M1

DSM_AUD_LP_M0

FLEXBUS0_D2

DSMC_DQS1

VO_LCDC_D2

Default

GPIO1_D1_d

8

DSMC_SLV_CSN0/RM_IO30/UART5_TX_M1/FLEXBUS0_D1/DSMC_CSN2/VO_LCDC_D1/GPIO1_D2_d

F2

DSMC_SLV_CSN0

3.3v

RM_IO30

UART5_TX_M1

FLEXBUS0_D1

DSMC_CSN2

VO_LCDC_D1

Default

GPIO1_D2_d

9

DSMC_SLV_RDYN/RM_IO31/UART5_RX_M1/FLEXBUS0_D0/DSMC_CSN3/VO_LCDC_D0/GPIO1_D3_d

G3

DSMC_SLV_RDYN

3.3v

RM_IO31

UART5_RX_M1

FLEXBUS0_D0

DSMC_CSN3

VO_LCDC_D0

Default

GPIO1_D3_d

10

GND10

GND10

GND

11

REF_CLK0_OUT/OSC_CLK_OUT/GPIO0_D0_d

G1

REF_CLK0_OUT

1.8V

OSC_CLK_OUT

GPIO0_D0_d

Default

12

GND12

GND12

GND

13

RM_IO23/JTAG_TMS_M1/UART0_RX_Debug/GPIO0_C7_u

J1

RM_IO23

3.3v

JTAG_TMS_M1

UART0_RX_Debug

Default

GPIO0_C7_u

14

RM_IO22/JTAG_TCK_M1/UART0_TX_Debug/GPIO0_C6_u

J2

RM_IO22

3.3v

JTAG_TCK_M1

UART0_TX_Debug

Default

GPIO0_C6_u

15

GND15

GND15

GND

16

NPOR_L

T3

NPOR_L

17

GND17

GND17

GND

18

RM_IO20/AUPLL_CLK_IN/ETH_CLK0_25M_OUT/GPIO0_C4_d

K2

RM_IO20

Default

3.3v

AUPLL_CLK_IN

ETH_CLK0_25M_OUT

GPIO0_C4_d

19

RM_IO19/SPI0_CSN0/ETH_CLK1_25M_OUT/GPIO0_C3_d

L2

RM_IO19

Default

3.3v

SPI0_CSN0

ETH_CLK1_25M_OUT

GPIO0_C3_d

20

RM_IO18/SPI0_MISO/REF_CLK1_OUT/GPIO0_C2_d

L1

RM_IO18

Default

3.3v

SPI0_MISO

REF_CLK1_OUT

GPIO0_C2_d

21

RM_IO17/SPI0_MOSI/GPIO0_C1_d

M3

RM_IO17

Default

3.3v

SPI0_MOSI

GPIO0_C1_d

22

RM_IO16/SPI0_CLK/GPIO0_C0_d

M2

RM_IO16

Default

SPI0_CLK

GPIO0_C0_d

23

GND23

GND23

GND

24

RM_IO15/SPI0_CSN1/SAI1_SDO3/GPIO0_B7_d

N2

RM_IO15

Default

3.3v

SPI0_CSN1

SAI1_SDO3

GPIO0_B7_d

25

RM_IO14/SPI1_CSN0/SAI1_SDO2/GPIO0_B6_d

N3

RM_IO14

Default

3.3v

SPI1_CSN0

SAI1_SDO2

GPIO0_B6_d

26

RM_IO13/SAI1_SDO1/GPIO0_B5_d

N1

RM_IO13

Default

3.3v

SAI1_SDO1

GPIO0_B5_d

27

RM_IO12/SAI1_SDO0/GPIO0_B4_d

P3

RM_IO12

3.3v

SAI1_SDO0

Default

GPIO0_B4_d

28

RM_IO11/SAI1_SDI/GPIO0_B3_d

P2

RM_IO11

3.3v

SAI1_SDI

Default

GPIO0_B3_d

29

RM_IO10/SPI1_MISO/SAI1_LRCK/GPIO0_B2_d

R3

RM_IO10

3.3v

SPI1_MISO

SAI1_LRCK

Default

GPIO0_B2_d

30

RM_IO9/SPI1_MOSI/SAI1_SCLK/GPIO0_B1_d

R1

RM_IO9

3.3v

SPI1_MOSI

SAI1_SCLK

Default

GPIO0_B1_d

31

RM_IO8/SPI1_CLK/SAI1_MCLK/GPIO0_B0_d

R2

RM_IO8

3.3v

SPI1_CLK

SAI1_MCLK

Default

GPIO0_B0_d

32

GND32

GND32

GND

33

VCCSYS_IN1

VCCSYS_IN1

34

VCCSYS_IN2

VCCSYS_IN2

35

GND35

GND35

GND

36

RM_IO7/SPI1_CSN1/SAI0_SDI3/GPIO0_A7_d

T2

RM_IO7

Default

3.3v

SPI1_CSN1

SAI0_SDI3

GPIO0_A7_d

37

RM_IO6/SAI0_SDI2/GPIO0_A6_d

U3

RM_IO6

Default

3.3v

SAI0_SDI2

GPIO0_A6_d

38

RM_IO5/SAI0_SDI1/GPIO0_A5_d

U1

RM_IO5

Default

3.3v

SAI0_SDI1

GPIO0_A5_d

39

RM_IO4/SAI0_SDI0/GPIO0_A4_d

U2

RM_IO4

Default

3.3v

SAI0_SDI0

GPIO0_A4_d

40

RM_IO3/SAI0_SDO/GPIO0_A3_d

V2

RM_IO3

Default

3.3v

SAI0_SDO

GPIO0_A3_d

41

RM_IO2/SAI0_MCLK/GPIO0_A2_u

W2

RM_IO2

Default

3.3v

SAI0_MCLK

GPIO0_A2_u

42

RM_IO1/SAI0_SCLK/GPIO0_A1_d

W1

RM_IO1

Default

3.3v

SAI0_SCLK

GPIO0_A1_d

43

RM_IO0/SAI0_LRCK/GPIO0_A0_u

V3

RM_IO0

Default

3.3v

SAI0_LRCK

GPIO0_A0_u

44

GND44

GND44

GND

45

ETH_RMII1_RXDVCRS/SAI2_MCLK_M0/GPIO3_B6_d

R22

ETH_RMII1_RXDVCRS

Default

1.8V/3.3V

SAI2_MCLK_M0

GPIO3_B6_d

46

ETH_RMII1_MDIO/UART5_RTSN_M0/ GPIO3_B5_d

P21

ETH_RMII1_MDIO

Default

1.8V/3.3V

UART5_RTSN_M0

GPIO3_B5_d

47

ETH_RMII1_MDC/UART5_TX_M0/GPIO3_B4_d

P23

ETH_RMII1_MDC

Default

1.8V/3.3V

UART5_TX_M0

GPIO3_B4_d

48

GND48

GND48

GND

49

ETH_RMII1_CLK/SAI2_SDO_M0/GPIO3_B0_d

M23

ETH_RMII1_CLK

Default

1.8V/3.3V

SAI2_SDO_M0

GPIO3_B0_d

50

ETH_RMII1_TXEN/UART5_RX_M0/GPIO3_B3_d

P22

ETH_RMII1_TXEN

Default

1.8V/3.3V

UART5_RX_M0

GPIO3_B3_d

51

ETH_RMII1_TXD1/UART5_CTSN_M0/GPIO3_B2_d

N21

ETH_RMII1_TXD1

Default

1.8V/3.3V

UART5_CTSN_M0

GPIO3_B2_d

52

ETH_RMII1_TXD0/SAI2_LRCK_M0/GPIO3_B1_d

M21

ETH_RMII1_TXD0

Default

1.8V/3.3V

SAI2_LRCK_M0

GPIO3_B1_d

53

ETH_RMII1_RXD1/SAI2_SCLK_M0/GPIO3_A7_d

M22

ETH_RMII1_RXD1

Default

1.8V/3.3V

SAI2_SCLK_M0

GPIO3_A7_d

54

ETH_RMII1_RXD0/SAI2_SDI_M0/GPIO3_A6_d

L22

ETH_RMII1_RXD0

Default

1.8V/3.3V

SAI2_SDI_M0

GPIO3_A6_d

55

NC/JTAG_TCK_M0/SDMMC_D2/GPIO3_A4_d

H23

JTAG_TCK_M0

1.8V/3.3V

SDMMC_D2

Default

GPIO3_A4_d

56

NC/TEST_CLK_OUT/SDMMC_D1/GPIO3_A3_d

K22

TEST_CLK_OUT

1.8V/3.3V

SDMMC_D1

Default

GPIO3_A3_d

57

NC/SDMMC_D0/GPIO3_A2_d

K23

SDMMC_D0

Default

1.8V/3.3V

GPIO3_A2_d

58

NC/JTAG_TMS_M0/SDMMC_D3/GPIO3_A5_d

H22

JTAG_TMS_M0

1.8V/3.3V

SDMMC_D3

Default

GPIO3_A5_d

59

NC/SDMMC_CMD/GPIO3_A1_d

J21

SDMMC_CMD

Default

1.8V/3.3V

GPIO3_A1_d

60

NC/SDMMC_CLK/GPIO3_A0_d

K21

SDMMC_CLK

Default

1.8V/3.3V

GPIO3_A0_d

61

GND61

GND61

GND

62

SAI3_SDI/DSM_AUD_LN_M1/ETH_RMII0_MDC/GPIO2_B6_d

F22

SAI3_SDI

3.3v

DSM_AUD_LN_M1

ETH_RMII0_MDC

Default

GPIO2_B6_d

63

SAI3_SDO/DSM_AUD_LP_M1/ETH_RMII0_MDIO/GPIO2_B7_d

G21

SAI3_SDO

3.3v

DSM_AUD_LP_M1

ETH_RMII0_MDIO

Default

GPIO2_B7_d

64

SAI3_MCLK /ETH_RMII0_RXDVCRS/GPIO2_C0_d

G22

SAI3_MCLK

3.3v

ETH_RMII0_RXDVCRS

Default

GPIO2_C0_d

65

VCC_1V8_OUT

VCC_1V8_OUT

66

VCC_3V3_OUT

VCC_3V3_OUT

67

GND67

GND67

68

VCCIO4_IN

VCCIO4_IN

69

SAI3_LRCK/DSM_AUD_RP_M1/ETH_RMII0_TXEN/GPIO2_B5_d

F23

SAI3_LRCK

3.3v

DSM_AUD_RP_M1

ETH_RMII0_TXEN

Default

GPIO2_B5_d

70

SAI3_SCLK/DSM_AUD_RN_M1/ETH_RMII0_TXD1/GPIO2_B4_d

F21

SAI3_SCLK

3.3v

DSM_AUD_RN_M1

ETH_RMII0_TXD1

Default

GPIO2_B4_d

71

SPI2_MISO/ETH_RMII0_TXD0/GPIO2_B3_d

E22

SPI2_MISO

3.3v

ETH_RMII0_TXD0

Default

GPIO2_B3_d

72

SPI2_CSN/ETH_RMII0_RXD1/GPIO2_B1_d

D23

SPI2_CSN

3.3v

ETH_RMII0_RXD1

Default

GPIO2_B1_d

73

SPI2_CLK/ETH_RMII0_RXD0/GPIO2_B0_d

D21

SPI2_CLK

3.3v

ETH_RMII0_RXD0

Default

GPIO2_B0_d

74

SPI2_MOSI/ETH_RMII0_CLK/GPIO2_B2_d

E21

SPI2_MOSI

3.3v

ETH_RMII0_CLK

Default

GPIO2_B2_d

75

GND75

GND75

GND

76

NC/FSPI_CLK/GPIO2_A1_d

C22

FSPI_CLK

Default

3.3v

GPIO2_A1_d

77

NC/FSPI_D0/GPIO2_A2_u

B23

FSPI_D0

Default

3.3v

GPIO2_A2_u

78

NC/FSPI_D3/GPIO2_A5_u

C23

FSPI_D3

Default

3.3v

GPIO2_A5_u

79

NC/FSPI_D2/GPIO2_A4_u

C21

FSPI_D2

Default

3.3v

GPIO2_A4_u

80

NC/FSPI_D1/GPIO2_A3_u

B22

FSPI_D1

Default

3.3v

GPIO2_A3_u

81

NC/FSPI_CSN/GPIO2_A0_u

A22

FSPI_CSN

Default

3.3v

GPIO2_A0_u

82

GND82

GND82

GND

83

SARADC_IN3/GPIO4_B3_z

B21

SARADC_IN3

Default

1.8V

GPIO4_B3_z

84

SARADC_IN2/GPIO4_B2_z

A21

SARADC_IN2

Default

1.8V

GPIO4_B2_z

85

SARADC_IN1_RECOVERY/GPIO4_B1_z

B20

SARADC_IN1_RECOVERY

Default

1.8V

GPIO4_B1_z

86

SARADC_IN0_BOOT/GPIO4_B0_z

A20

SARADC_IN0_BOOT

Default

1.8V

GPIO4_B0_z

87

GND87

GND87

GND

88

ACODEC_ADC_INP

A19

ACODEC_ADC_INP

89

ACODEC_ADC_INN

B19

ACODEC_ADC_INN

90

GND90

GND90

GND

91

USB20_OTG0_VBUSDET

B18

USB20_OTG0_VBUSDET

92

USB20_OTG0_ID

B17

USB20_OTG0_ID

93

USB20_OTG0_DM

B16

USB20_OTG0_DM

94

USB20_OTG0_DP

A16

USB20_OTG0_DP

95

USB20_OTG1_DM

A15

USB20_OTG1_DM

96

USB20_OTG1_DP

B15

USB20_OTG1_DP

97

GND97

GND97

GND

98

MIPI_DPHY_DSI_TX_CLKN/GPO4_A4_z

B14

MIPI_DPHY_DSI_TX_CLKN

Default

1.8V

GPO4_A4_z

99

MIPI_DPHY_DSI_TX_CLKP/GPO4_A5_z

B13

MIPI_DPHY_DSI_TX_CLKP

Default

1.8V

GPO4_A5_z

100

GND100

GND100

GND

101

MIPI_DPHY_DSI_TX_D1N/GPO4_A2_z

B12

MIPI_DPHY_DSI_TX_D1N

Default

1.8V

GPO4_A2_z

102

MIPI_DPHY_DSI_TX_D1P/GPO4_A3_z

A12

MIPI_DPHY_DSI_TX_D1P

Default

1.8V

GPO4_A3_z

103

MIPI_DPHY_DSI_TX_D0N/GPO4_A0_z

A11

MIPI_DPHY_DSI_TX_D0N

Default

1.8V

GPO4_A0_z

104

MIPI_DPHY_DSI_TX_D0P/GPO4_A1_z

B11

MIPI_DPHY_DSI_TX_D0P

Default

1.8V

GPO4_A1_z

105

GND105

GND105

GND

106

FLEXBUS1_D0/DSMC_CLKP/VO_LCDC_DEN/GPIO1_A0_d

B10

FLEXBUS1_D0

3.3v

DSMC_CLKP

VO_LCDC_DEN

Default

GPIO1_A0_d

107

DSMC_SLV_INT/DSMC_INT0/FLEXBUS1_D1/DSMC_CLKN/VO_LCDC_VSYNC/GPIO1_A1_d

1A5

DSMC_SLV_INT

3.3v

DSMC_INT0

FLEXBUS1_D1

DSMC_CLKN

VO_LCDC_VSYNC

Default

GPIO1_A1_d

108

FLEXBUS1_D2/DSMC_DQS0/VO_LCDC_HSYNC/GPIO1_A2_d

A9

FLEXBUS1_D2

3.3v

DSMC_DQS0

VO_LCDC_HSYNC

Default

GPIO1_A2_d

109

FLEXBUS1_D3/DSMC_D0/VO_LCDC_CLK /GPIO1_A3_d

B9

FLEXBUS1_D3

3.3v

DSMC_D0

VO_LCDC_CLK

Default

GPIO1_A3_d

110

GND110

GND110

GND

111

FLEXBUS1_D4/DSMC_D1/VO_LCDC_D23/GPIO1_A4_d

B8

FLEXBUS1_D4

3.3v

DSMC_D1

VO_LCDC_D23

Default

GPIO1_A4_d

112

FLEXBUS1_D5/DSMC_D2/VO_LCDC_D22/GPIO1_A5_d

1A4

FLEXBUS1_D5

3.3v

DSMC_D2

VO_LCDC_D22

Default

GPIO1_A5_d

113

FLEXBUS1_D6/DSMC_D3/VO_LCDC_D21/GPIO1_A6_d

A7

FLEXBUS1_D6

3.3v

DSMC_D3

VO_LCDC_D21

Default

GPIO1_A6_d

114

FLEXBUS1_D7/DSMC_D4/VO_LCDC_D20/GPIO1_A7_d

B7

FLEXBUS1_D7

3.3v

DSMC_D4

VO_LCDC_D20

Default

GPIO1_A7_d

115

GND115

GND115

GND

116

FLEXBUS0_CSN_M0/FLEXBUS1_D8/DSMC_D5/VO_LCDC_D19/GPIO1_B0_d

1A3

FLEXBUS0_CSN_M0

3.3v

FLEXBUS1_D8

DSMC_D5

VO_LCDC_D19

Default

GPIO1_B0_d

117

RM_IO24/UART5_CTSN_M1/FLEXBUS1_CSN_M0/FLEXBUS1_D9/DSMC_CSN1/VO_LCDC_D18/GPIO1_B1_d

1A2

RM_IO24

3.3v

UART5_CTSN_M1

FLEXBUS1_CSN_M0

FLEXBUS1_D9

DSMC_CSN1

VO_LCDC_D18

Default

GPIO1_B1_d

118

RM_IO25/SAI2_SCLK_M1/FLEXBUS0_CSN_M1/FLEXBUS0_D15/FLEXBUS1_D10/DSMC_INT2/VO_LCDC_D17/GPIO1_B2_d

A5

RM_IO25

3.3v

SAI2_SCLK_M1

FLEXBUS0_CSN_M1

FLEXBUS0_D15

FLEXBUS1_D10

DSMC_INT2

VO_LCDC_D17

Default

GPIO1_B2_d

119

RM_IO26/SAI2_LRCK_M1/FLEXBUS1_CSN_M1/FLEXBUS0_D14/FLEXBUS1_D11/DSMC_INT3/VO_LCDC_D16/GPIO1_B3_d

B5

RM_IO26

3.3v

SAI2_LRCK_M1

FLEXBUS1_CSN_M1

FLEXBUS0_D14

FLEXBUS1_D11

DSMC_INT3

VO_LCDC_D16

Default

GPIO1_B3_d

120

FLEXBUS0_CSN_M2/FLEXBUS0_D13/FLEXBUS1_D12/DSMC_D6/VO_LCDC_D15/GPIO1_B4_d

1A1

FLEXBUS0_CSN_M2

3.3v

FLEXBUS0_D13

FLEXBUS1_D12

DSMC_D6

VO_LCDC_D15

Default

GPIO1_B4_d

121

FLEXBUS1_CSN_M2/FLEXBUS0_D12/FLEXBUS1_D13/DSMC_D7/VO_LCDC_D14/GPIO1_B5_d

C3

FLEXBUS1_CSN_M2

3.3v

FLEXBUS0_D12

FLEXBUS1_D13

DSMC_D7

VO_LCDC_D14

Default

GPIO1_B5_d

122

FLEXBUS0_CSN_M3/FLEXBUS0_D11/FLEXBUS1_D14/DSMC_CSN0 /VO_LCDC_D13/GPIO1_B6_d

A3

FLEXBUS0_CSN_M3

3.3v

FLEXBUS0_D11

FLEXBUS1_D14

DSMC_CSN0

VO_LCDC_D13

Default

GPIO1_B6_d

123

FLEXBUS1_CSN_M3/FLEXBUS0_D10/FLEXBUS1_D15/DSMC_RDYN/VO_LCDC_D12/GPIO1_B7_d

B3

FLEXBUS1_CSN_M3

3.3v

FLEXBUS0_D10

FLEXBUS1_D15

DSMC_RDYN

VO_LCDC_D12

Default

GPIO1_B7_d

124

GND124

GND124

GND

125

DSMC_SLV_CLK/FLEXBUS0_CSN_M4/DSMC_INT1/FLEXBUS1_CLK/DSMC_RESETN/VO_LCDC_D11/GPIO1_C0_d

A2

DSMC_SLV_CLK/

3.3v

FLEXBUS0_CSN_M4

DSMC_INT1

FLEXBUS1_CLK

DSMC_RESETN

VO_LCDC_D11

Default

GPIO1_C0_d

126

DSMC_SLV_DQS0/SAI2_MCLK_M1/FLEXBUS1_CSN_M4/DSM_AUD_RN_M0/FLEXBUS0_CLK/DSMC_D8/VO_LCDC_D10/GPIO1_C1_d

B2

DSMC_SLV_DQS0

3.3v

SAI2_MCLK_M1

FLEXBUS1_CSN_M4

DSM_AUD_RN_M0

FLEXBUS0_CLK

DSMC_D8

VO_LCDC_D10

Default

GPIO1_C1_d

3.3v

127

DSMC_SLV_D0/RM_IO27/SAI2_SDI_M1/FLEXBUS0_CSN_M5/DSM_AUD_RP_M0/FLEXBUS0_D9/DSMC_D9/VO_LCDC_D9/GPIO1_C2_d

B1

DSMC_SLV_D0

RM_IO27

SAI2_SDI_M1

FLEXBUS0_CSN_M5

DSM_AUD_RP_M0

FLEXBUS0_D9

DSMC_D9

VO_LCDC_D9

Default

GPIO1_C2_d

3.3v

128

DSMC_SLV_D1/RM_IO28/SAI2_SDO_M1/FLEXBUS1_CSN_M5/FLEXBUS0_D8/DSMC_D10/VO_LCDC_D8/GPIO1_C3_d

C2

DSMC_SLV_D1

RM_IO28

SAI2_SDO_M1

FLEXBUS1_CSN_M5

FLEXBUS0_D8

DSMC_D10

VO_LCDC_D8

Default

GPIO1_C3_d
