GB/T28181-2022规范解读、应用场景和技术实现探究

<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" ></uses-permission>
<uses-permission android:name="android.permission.INTERNET" ></uses-permission>
<uses-permission android:name="android.permission.MOUNT_UNMOUNT_FILESYSTEMS" />
<uses-permission android:name="android.permission.MODIFY_AUDIO_SETTINGS" />
<uses-permission android:name="android.permission.ACCESS_COARSE_LOCATION"></uses-permission>
<uses-permission android:name="android.permission.ACCESS_FINE_LOCATION"></uses-permission>

static {
    System.loadLibrary("SmartPublisher");
    System.loadLibrary("SmartPlayer");
}

splits {
    abi {
        enable true
        reset()
        // Specifies a list of ABIs that Gradle should create APKs for
        include 'armeabi-v7a', 'arm64-v8a', 'x86', 'x86_64' //select ABIs to build APKs for
        // Specify that we do not want to also generate a universal APK that includes all ABIs
        universalApk true
    }
}

<string name="app_name">SmartPublisherSDKDemo</string>

/*
 * GB28181Camera2Activity.java
 * Created by daniusdk.com
 * WeChat: xinsheng120
 */
public class MainActivity extends Activity implements ViewTreeObserver.OnGlobalLayoutListener, Camera2Listener,
        GBSIPAgentListener, GBSIPAgentPlayListener, GBSIPAgentAudioBroadcastListener,
        GBSIPAgentDeviceControlListener, GBSIPAgentQueryCommandListener,
        GBSIPAgentTalkListener,
        GBSIPAgentQueryRecordInfoListener{
}

public interface GBSIPAgentListener
{
    /*注册成功
    * @param dateString: 服务器日期，用来校准设备端时间，用户自行决定是否校准设备时间
    */
    void ntsRegisterOK(String dateString);

    /*
    *注册超时
    */
    void ntsRegisterTimeout();

    /*
    *注册网络传输层异常
    */
    void ntsRegisterTransportError(String errorInfo);

    /*
    *心跳达到异常次数
    */
    void ntsOnHeartBeatException(int exceptionCount, String lastExceptionInfo);

    /*
     * 设备位置请求, 这个主要用在移动设备位置订阅上
     * @param interval 请求间隔, 单位是毫秒
     */
    void ntsOnDevicePositionRequest(String deviceId, int interval);
}

public interface GBSIPAgentPlayListener {

    /*
     *收到s=Play的实时视音频点播
     */
    void ntsOnInvitePlay(String deviceId, SessionDescription sessionDescription);

    /*
     *发送play invite response 异常
     */
    void ntsOnPlayInviteResponseException(String deviceId, int statusCode, String errorInfo);

    /*
     * 收到CANCEL play INVITE请求
     */
    void ntsOnCancelPlay(String deviceId);

    /*
     * 收到Ack
     */
    void ntsOnAckPlay(String deviceId);

    /*
     * 收到Bye
     */
    void ntsOnByePlay(String deviceId);

    /*
     * 不是在收到BYE Message情况下， 终止Play
     */
    void ntsOnTerminatePlay(String deviceId);

    /*
     * Play会话对应的对话终止, 一般不会出发这个回调,目前只有在响应了200K, 但在64*T1时间后还没收到ACK,才可能会出发
    收到这个, 请做相关清理处理
    */
    void ntsOnPlayDialogTerminated(String deviceId);
}

public interface GBSIPAgentAudioBroadcastListener {

    /*
     *收到语音广播通知
     */
    void ntsOnNotifyBroadcastCommand(String fromUserName, String fromUserNameAtDomain, String sn, String sourceID, String targetID);

    /*
     *需要准备接受语音广播的SDP内容
     */
    void ntsOnAudioBroadcast(String commandFromUserName, String commandFromUserNameAtDomain, String sourceID, String targetID);

    /*
     *音频广播, 发送Invite请求异常
     */
    void ntsOnInviteAudioBroadcastException(String sourceID, String targetID, String errorInfo);

    /*
     *音频广播, 等待Invite响应超时
     */
    void ntsOnInviteAudioBroadcastTimeout(String sourceID, String targetID);

    /*
     *音频广播, 收到Invite消息最终响应
     */
    void ntsOnInviteAudioBroadcastResponse(String sourceID, String targetID, int statusCode, SessionDescription sessionDescription);

    /*
     * 音频广播, 收到BYE Message
     */
    void ntsOnByeAudioBroadcast(String sourceID, String targetID);


    /*
     * 不是在收到BYE Message情况下， 终止音频广播
     */
    void ntsOnTerminateAudioBroadcast(String sourceID, String targetID);
}

public interface GBSIPAgentDeviceControlListener {

    /*
     * 收到远程启动控制命令
     */
    void ntsOnDeviceControlTeleBootCommand(String deviceId, String teleBootValue);

    /*
    * 云台控制
     */
    void ntsOnDeviceControlPTZCmd(String deviceId, String typeValue);
}

public interface GBSIPAgentQueryCommandListener {

    /*
     * 设备预置位查询
     */
    void ntsOnDevicePresetQueryCommand(String fromUserName, String fromUserNameAtDomain, String sn, String deviceId);
}

public interface GBSIPAgentTalkListener {
    /*
     *收到s=Talk 语音对讲
     */
    void ntsOnInviteTalk(String deviceId, SessionDescription sessionDescription);

    /*
     *发送talk invite response 异常
     */
    void ntsOnTalkInviteResponseException(String deviceId, int statusCode, String errorInfo);

    /*
     * 收到CANCEL Talk INVITE请求
     */
    void ntsOnCancelTalk(String deviceId);

    /*
     * 收到Ack
     */
    void ntsOnAckTalk(String deviceId);

    /*
     * 收到Bye
     */
    void ntsOnByeTalk(String deviceId);

    /*
     * 不是在收到BYE Message情况下， 终止Talk
     */
    void ntsOnTerminateTalk(String deviceId);

    /*
     * Talk会话对应的对话终止, 一般不会出发这个回调,目前只有在响应了200K, 但在64*T1时间后还没收到ACK,才可能会出发
    收到这个, 请做相关清理处理
    */
    void ntsOnTalkDialogTerminated(String deviceId);
}

public interface GBSIPAgentPlaybackListener {
    void ntsOnInvitePlayback(long var1, String var3, SessionDescription var4);

    void ntsOnPlaybackInviteResponseException(long var1, String var3, int var4, String var5);

    void ntsOnCancelPlayback(long var1, String var3);

    void ntsOnAckPlayback(long var1, String var3);

    void ntsOnPlaybackMANSRTSPPlayCommand(long var1, String var3);

    void ntsOnPlaybackMANSRTSPPauseCommand(long var1, String var3);

    void ntsOnPlaybackMANSRTSPScaleCommand(long var1, String var3, double var4);

    void ntsOnPlaybackMANSRTSPSeekCommand(long var1, String var3, double var4);

    void ntsOnPlaybackMANSRTSPTeardownCommand(long var1, String var3);

    void ntsOnByePlayback(long var1, String var3);

    void ntsOnTerminatePlayback(long var1, String var3);

    void ntsOnPlaybackDialogTerminated(long var1, String var3);
}

public interface GBSIPAgentDownloadListener {
    void ntsOnInviteDownload(long var1, String var3, SessionDescription var4);

    void ntsOnDownloadInviteResponseException(long var1, String var3, int var4, String var5);

    void ntsOnCancelDownload(long var1, String var3);

    void ntsOnAckDownload(long var1, String var3);

    void ntsOnDownloadMANSRTSPScaleCommand(long var1, String var3, double var4);

    void ntsOnByeDownload(long var1, String var3);

    void ntsOnTerminateDownload(long var1, String var3);

    void ntsOnDownloadDialogTerminated(long var1, String var3);
}

/*
 * SmartPublisherJniV2.java
 * Author: https://daniusdk.com
 */
/**
 * 设置GB28181 RTP Sender
 *
 * @param rtp_sender_handle, CreateRTPSender返回值
 * @param rtp_payload_type, 对于GB28181 PS, 协议定义是96, 具体以SDP为准,  RFC 3551有定义
 * @param encoding_name, 编码名, 请参考 RFC 3551, 当前仅支持: "PS", 其他值返回失败
 * @return {0} if successful
 */
public native int SetGB28181RTPSender(long handle, long rtp_sender_handle, int rtp_payload_type, String encoding_name);

/**
 * 设置GB28181 RTP 收到的音频包回调
 * @param handle
 * @param audio_packet_callback
 * @return
 */
public native int SetGB28181ReceiveAudioPacketCallback(long handle, NTAudioPacketCallback audio_packet_callback);

/**
 * 启动 GB28181 媒体流
 *
 * @return {0} if successful
 */
public native int StartGB28181MediaStream(long handle);

/**
 * 停止 GB28181 媒体流
 *
 * @return {0} if successful
 */
public native int StopGB28181MediaStream(long handle);
