Android平台通过RTSP服务实现摄像头麦克风共享

/*
 * MainActivity.java
 * Author: daniusdk.com
 * WeChat：xinsheng120
 */
@Override
protected void onCreate(Bundle savedInstanceState) {
	super.onCreate(savedInstanceState);
	setContentView(R.layout.activity_main);

	...

	context_ = this.getApplicationContext();

	libPublisher = new SmartPublisherJniV2();

	libPublisher.InitRtspServer(context_);      //和UnInitRtspServer配对使用，即便是启动多个RTSP服务，也只需调用一次InitRtspServer，请确保在OpenRtspServer之前调用
}

//启动/停止RTSP服务
class ButtonRtspServiceListener implements View.OnClickListener {
	public void onClick(View v) {
		if (isRTSPServiceRunning) {
			stopRtspService();

			btnRtspService.setText("启动RTSP服务");
			btnRtspPublisher.setEnabled(false);

			isRTSPServiceRunning = false;
			return;
		}

		Log.i(TAG, "onClick start rtsp service..");

		rtsp_handle_ = libPublisher.OpenRtspServer(0);

		if (rtsp_handle_ == 0) {
			Log.e(TAG, "创建rtsp server实例失败! 请检查SDK有效性");
		} else {
			int port = 8554;
			if (libPublisher.SetRtspServerPort(rtsp_handle_, port) != 0) {
				libPublisher.CloseRtspServer(rtsp_handle_);
				rtsp_handle_ = 0;
				Log.e(TAG, "创建rtsp server端口失败! 请检查端口是否重复或者端口不在范围内!");
			}

			if (libPublisher.StartRtspServer(rtsp_handle_, 0) == 0) {
				Log.i(TAG, "启动rtsp server 成功!");
			} else {
				libPublisher.CloseRtspServer(rtsp_handle_);
				rtsp_handle_ = 0;
				Log.e(TAG, "启动rtsp server失败! 请检查设置的端口是否被占用!");
			}

			btnRtspService.setText("停止RTSP服务");
			btnRtspPublisher.setEnabled(true);

			isRTSPServiceRunning = true;
		}
	}
}

//停止RTSP服务
private void stopRtspService() {
	if(!isRTSPServiceRunning)
	{
		return;
	}
	if (libPublisher != null && rtsp_handle_ != 0) {
		libPublisher.StopRtspServer(rtsp_handle_);
		libPublisher.CloseRtspServer(rtsp_handle_);
		rtsp_handle_ = 0;
	}
}

//发布/停止RTSP流
class ButtonRtspPublisherListener implements View.OnClickListener {
	public void onClick(View v) {
		if (stream_publisher_.is_rtsp_publishing()) {
			stopRtspPublisher();

			btnRtspPublisher.setText("发布RTSP流");
			btnGetRtspSessionNumbers.setEnabled(false);
			btnRtspService.setEnabled(true);
			return;
		}

		Log.i(TAG, "onClick start rtsp publisher..");

		InitAndSetConfig();

		String rtsp_stream_name = "stream1";
		stream_publisher_.SetRtspStreamName(rtsp_stream_name);
		stream_publisher_.ClearRtspStreamServer();

		stream_publisher_.AddRtspStreamServer(rtsp_handle_);

		if (!stream_publisher_.StartRtspStream()) {
			stream_publisher_.try_release();
			Log.e(TAG, "调用发布rtsp流接口失败!");
			return;
		}

		startAudioRecorder();
		startLayerPostThread();

		btnRtspPublisher.setText("停止RTSP流");
		btnGetRtspSessionNumbers.setEnabled(true);
		btnRtspService.setEnabled(false);
	}
}

//停止发布RTSP流
private void stopRtspPublisher() {
	stream_publisher_.StopRtspStream();
	stream_publisher_.try_release();

	if (!stream_publisher_.is_publishing())
		stopAudioRecorder();
}

/*
 * MainActivity.java
 * Author: daniusdk.com
 */
private void InitAndSetConfig() {
	if (null == libPublisher)
		return;

	if (!stream_publisher_.empty())
		return;

	Log.i(TAG, "InitAndSetConfig video width: " + video_width_ + ", height" + video_height_ + " imageRotationDegree:" + cameraImageRotationDegree_);

	int audio_opt = 1;
	long handle = libPublisher.SmartPublisherOpen(context_, audio_opt, 3,  video_width_, video_height_);
	if (0==handle) {
		Log.e(TAG, "sdk open failed!");
		return;
	}

	Log.i(TAG, "publisherHandle=" + handle);

	int fps = 25;
	int gop = fps * 3;

	initialize_publisher(libPublisher, handle, video_width_, video_height_, fps, gop);

	stream_publisher_.set(libPublisher, handle);
}

private boolean initialize_publisher(SmartPublisherJniV2 lib_publisher, long handle, int width, int height, int fps, int gop) {
	if (null == lib_publisher) {
		Log.e(TAG, "initialize_publisher lib_publisher is null");
		return false;
	}

	if (0 == handle) {
		Log.e(TAG, "initialize_publisher handle is 0");
		return false;
	}

	if (videoEncodeType == 1) {
		int kbps = LibPublisherWrapper.estimate_video_hardware_kbps(width, height, fps, true);
		Log.i(TAG, "h264HWKbps: " + kbps);
		int isSupportH264HWEncoder = lib_publisher.SetSmartPublisherVideoHWEncoder(handle, kbps);
		if (isSupportH264HWEncoder == 0) {
			lib_publisher.SetNativeMediaNDK(handle, 0);
			lib_publisher.SetVideoHWEncoderBitrateMode(handle, 1); // 0:CQ, 1:VBR, 2:CBR
			lib_publisher.SetVideoHWEncoderQuality(handle, 39);
			lib_publisher.SetAVCHWEncoderProfile(handle, 0x08); // 0x01: Baseline, 0x02: Main, 0x08: High

			// lib_publisher.SetAVCHWEncoderLevel(handle, 0x200); // Level 3.1
			// lib_publisher.SetAVCHWEncoderLevel(handle, 0x400); // Level 3.2
			// lib_publisher.SetAVCHWEncoderLevel(handle, 0x800); // Level 4
			lib_publisher.SetAVCHWEncoderLevel(handle, 0x1000); // Level 4.1 多数情况下,这个够用了
			//lib_publisher.SetAVCHWEncoderLevel(handle, 0x2000); // Level 4.2

			// lib_publisher.SetVideoHWEncoderMaxBitrate(handle, ((long)h264HWKbps)*1300);

			Log.i(TAG, "Great, it supports h.264 hardware encoder!");
		}
	} else if (videoEncodeType == 2) {
		int kbps = LibPublisherWrapper.estimate_video_hardware_kbps(width, height, fps, false);
		Log.i(TAG, "hevcHWKbps: " + kbps);
		int isSupportHevcHWEncoder = lib_publisher.SetSmartPublisherVideoHevcHWEncoder(handle, kbps);
		if (isSupportHevcHWEncoder == 0) {
			lib_publisher.SetNativeMediaNDK(handle, 0);
			lib_publisher.SetVideoHWEncoderBitrateMode(handle, 1); // 0:CQ, 1:VBR, 2:CBR
			lib_publisher.SetVideoHWEncoderQuality(handle, 39);

			// libPublisher.SetVideoHWEncoderMaxBitrate(handle, ((long)hevcHWKbps)*1200);

			Log.i(TAG, "Great, it supports hevc hardware encoder!");
		}
	}

	boolean is_sw_vbr_mode = true;
	//H.264 software encoder
	if (is_sw_vbr_mode) {
		int is_enable_vbr = 1;
		int video_quality = LibPublisherWrapper.estimate_video_software_quality(width, height, true);
		int vbr_max_kbps = LibPublisherWrapper.estimate_video_vbr_max_kbps(width, height, fps);
		lib_publisher.SmartPublisherSetSwVBRMode(handle, is_enable_vbr, video_quality, vbr_max_kbps);
	}

	if (is_pcma_) {
		lib_publisher.SmartPublisherSetAudioCodecType(handle, 3);
	} else {
		lib_publisher.SmartPublisherSetAudioCodecType(handle, 1);
	}

	lib_publisher.SetSmartPublisherEventCallbackV2(handle, new EventHandlerPublisherV2().set(handler_, record_executor_));

	lib_publisher.SmartPublisherSetSWVideoEncoderProfile(handle, 3);

	lib_publisher.SmartPublisherSetSWVideoEncoderSpeed(handle, 2);

	lib_publisher.SmartPublisherSetGopInterval(handle, gop);

	lib_publisher.SmartPublisherSetFPS(handle, fps);

	// lib_publisher.SmartPublisherSetSWVideoBitRate(handle, 600, 1200);

	boolean is_noise_suppression = true;
	lib_publisher.SmartPublisherSetNoiseSuppression(handle, is_noise_suppression ? 1 : 0);

	boolean is_agc = false;
	lib_publisher.SmartPublisherSetAGC(handle, is_agc ? 1 : 0);

	int echo_cancel_delay = 0;
	lib_publisher.SmartPublisherSetEchoCancellation(handle, 1, echo_cancel_delay);

	return true;
}

private static class EventHandlerPublisherV2 implements NTSmartEventCallbackV2 {
	@Override
	public void onNTSmartEventCallbackV2(long handle, int id, long param1, long param2, String param3, String param4, Object param5) {

		switch (id) {
			...
			case NTSmartEventID.EVENT_DANIULIVE_ERC_PUBLISHER_RTSP_URL:
				publisher_event = "RTSP服务URL: " + param3;
				break;
		}
	}
}

//获取RTSP会话数
class ButtonGetRtspSessionNumbersListener implements View.OnClickListener {
	public void onClick(View v) {
		if (libPublisher != null && rtsp_handle_ != 0) {
			int session_numbers = libPublisher.GetRtspServerClientSessionNumbers(rtsp_handle_);

			Log.i(TAG, "GetRtspSessionNumbers: " + session_numbers);

			PopRtspSessionNumberDialog(session_numbers);
		}
	}
}

//当前RTSP会话数弹出框
private void PopRtspSessionNumberDialog(int session_numbers) {
	final EditText inputUrlTxt = new EditText(this);
	inputUrlTxt.setFocusable(true);
	inputUrlTxt.setEnabled(false);

	String session_numbers_tag = "RTSP服务当前客户会话数: " + session_numbers;
	inputUrlTxt.setText(session_numbers_tag);

	AlertDialog.Builder builderUrl = new AlertDialog.Builder(this);
	builderUrl
			.setTitle("内置RTSP服务")
			.setView(inputUrlTxt).setNegativeButton("确定", null);
	builderUrl.show();
}

@Override
public void onCameraImageData(Image image) {
	....
	for (LibPublisherWrapper i : publisher_array_)
		i.PostLayerImageYUV420888ByteBuffer(0, 0, 0,
			planes[0].getBuffer(), y_offset, planes[0].getRowStride(),
			planes[1].getBuffer(), u_offset, planes[1].getRowStride(),
			planes[2].getBuffer(), v_offset, planes[2].getRowStride(), planes[1].getPixelStride(),
			w, h, 0, 0,
			scale_w, scale_h, scale_filter_mode, rotation_degree);

}

void startAudioRecorder() {
	if (audio_recorder_ != null)
		return;

	audio_recorder_ = new NTAudioRecordV2(this);

	Log.i(TAG, "startAudioRecorder call audio_recorder_.start()+++...");

	audio_recorder_callback_ = new NTAudioRecordV2CallbackImpl(stream_publisher_, null);

	audio_recorder_.AddCallback(audio_recorder_callback_);

	if (!audio_recorder_.Start(is_pcma_ ? 8000 : 44100, 1) ) {
		audio_recorder_.RemoveCallback(audio_recorder_callback_);
		audio_recorder_callback_ = null;

		audio_recorder_ = null;

		Log.e(TAG, "startAudioRecorder start failed.");
	}
	else {
		Log.i(TAG, "startAudioRecorder call audio_recorder_.start() OK---...");
	}
}

void stopAudioRecorder() {
	if (null == audio_recorder_)
		return;

	Log.i(TAG, "stopAudioRecorder+++");

	audio_recorder_.Stop();

	if (audio_recorder_callback_ != null) {
		audio_recorder_.RemoveCallback(audio_recorder_callback_);
		audio_recorder_callback_ = null;
	}

	audio_recorder_ = null;

	Log.i(TAG, "stopAudioRecorder---");
}

private static class NTAudioRecordV2CallbackImpl implements NTAudioRecordV2Callback {
	private WeakReference<LibPublisherWrapper> publisher_0_;
	private WeakReference<LibPublisherWrapper> publisher_1_;

	public NTAudioRecordV2CallbackImpl(LibPublisherWrapper publisher_0) {
		if (publisher_0 != null)
			publisher_0_ = new WeakReference<>(publisher_0);
	}

	private final LibPublisherWrapper get_publisher_0() {
		if (publisher_0_ !=null)
			return publisher_0_.get();

		return null;
	}

	@Override
	public void onNTAudioRecordV2Frame(ByteBuffer data, int size, int sampleRate, int channel, int per_channel_sample_number) {

		LibPublisherWrapper publisher_0 = get_publisher_0();
		if (publisher_0 != null)
			publisher_0.OnPCMData(data, size, sampleRate, channel, per_channel_sample_number);
	}
}

@Override
protected void onDestroy() {
	Log.i(TAG, "activity destory!");

	stopAudioRecorder();

	stopRtspPublisher();
	stopRtspService();
	isRTSPServiceRunning = false;

	stream_publisher_.release();

	if (libPublisher != null)
		libPublisher.UnInitRtspServer();      //如已启用内置服务功能(InitRtspServer)，调用UnInitRtspServer, 注意，即便是启动多个RTSP服务，也只需调用UnInitRtspServer一次

	stopLayerPostThread();

	if (camera2Helper != null) {
		camera2Helper.release();
	}

	super.onDestroy();
}
