rk3399-android9.0-secureboot介绍

def calc_hash_level_offsets(image_size, block_size, digest_size):
  """Calculate the offsets of all the hash-levels in a Merkle-tree.

  Arguments:
    image_size: The size of the image to calculate a Merkle-tree for.
    block_size: The block size, e.g. 4096.
    digest_size: The size of each hash, e.g. 32 for SHA-256.

  Returns:
    A tuple where the first argument is an array of offsets and the
    second is size of the tree, in bytes.
  """
  level_offsets = []  # 用来存储每一层在bytearray中的偏移
  level_sizes = []    # 每一层占用的大小
  tree_size = 0       # 树的大小

  num_levels = 0      # 树的层数
  # size用于计算时表示当前层的下一层的数据大小，从第0层（计算数据块hash）开始，
  # 所以初始值为image的大小
  size = image_size
  while size > block_size:
    # 计算当前层数据需要多少个块
    num_blocks = (size + block_size - 1) / block_size
    # round_to_multiple函数用来将第一个参数舍入到最接近第二个参数的倍数
    # 在这里就是对齐到block_size的整数倍
    # 计算当前层的hash digest需要占用的大小
    level_size = round_to_multiple(num_blocks * digest_size, block_size)

    level_sizes.append(level_size)
    tree_size += level_size
    num_levels += 1

    # 循环往上计算，所以更新size为当前层，用于计算上一层
    size = level_size

  # 计算每一层在bytearray中的偏移
  for n in range(0, num_levels):
    offset = 0
    for m in range(n + 1, num_levels):
      offset += level_sizes[m]
    level_offsets.append(offset)

  return level_offsets, tree_size

def generate_hash_tree(image, image_size, block_size, hash_alg_name, salt,
                       digest_padding, hash_level_offsets, tree_size):
  """Generates a Merkle-tree for a file.

  Args:
    image: The image, as a file.
    image_size: The size of the image.
    block_size: The block size, e.g. 4096.
    hash_alg_name: The hash algorithm, e.g. 'sha256' or 'sha1'.
    salt: The salt to use.
    digest_padding: The padding for each digest.
    hash_level_offsets: The offsets from calc_hash_level_offsets().
    tree_size: The size of the tree, in number of bytes.

  Returns:
    A tuple where the first element is the top-level hash and the
    second element is the hash-tree.
  """
  hash_ret = bytearray(tree_size)
  hash_src_offset = 0
  hash_src_size = image_size
  level_num = 0
  while hash_src_size > block_size:
    level_output = ''
    remaining = hash_src_size
    while remaining > 0:
      hasher = hashlib.new(name=hash_alg_name, string=salt)
      # Only read from the file for the first level - for subsequent
      # levels, access the array we're building.
      # 第0层直接按照block_size读取image来进行hash
      if level_num == 0:
        image.seek(hash_src_offset + hash_src_size - remaining)
        data = image.read(min(remaining, block_size))
      # 第0层之上的每一层都由取其下一层来进行hash，eg: 将第m-1层的数据分块hash后生成m层数据
      else:
        offset = hash_level_offsets[level_num - 1] + hash_src_size - remaining
        # 以block_size为单位进行分块
        data = hash_ret[offset:offset + block_size]
      hasher.update(data)

      remaining -= len(data)
      if len(data) < block_size:
        hasher.update('\0' * (block_size - len(data)))
      level_output += hasher.digest()
      if digest_padding > 0:
        level_output += '\0' * digest_padding

    padding_needed = (round_to_multiple(
        len(level_output), block_size) - len(level_output))
    level_output += '\0' * padding_needed

    # Copy level-output into resulting tree.
    offset = hash_level_offsets[level_num]
    hash_ret[offset:offset + len(level_output)] = level_output

    # Continue on to the next level.
    hash_src_size = len(level_output)
    level_num += 1

  # 建树完成后，单独计算root hash
  hasher = hashlib.new(name=hash_alg_name, string=salt)
  hasher.update(level_output)
  return hasher.digest(), hash_ret
