TNW 简介

TNW: TypeScript(The) + Node.js(Next) + WeChat 微信公众号开发脚手架,支持任何 Node.js 的服务端框架

测试号申请

测试时请自己的测试号

开启开发者模式

这里说的各种消息交互是指的 开发者模式下的消息交互 如果还没有开启开发者模式可以参考之前写文章 开启公众号开发者模式

简书

掘金

CSDN

开源中国

在 TNW 中实现微信公众号各种消息交互非常简单,步骤如下:

  1. 接收各种消息
  2. 调用 WeChat.handleMsg(...) 方法处理分发消息
  3. 实现 MsgAdapter 接口,实现业务逻辑以及各种消息回复

接收各种消息

开发者 URL 的 POST 方法下接收各种消息 具体实现代码如下

Express 示例如下:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
// 接收微信消息入口
app.post('/msg', function (req: any, res: any) {
    console.log('post...', req.query);
        // 支持多公众号
    let appId: string = req.query.appId;
    if (appId) {
        ApiConfigKit.setCurrentAppId(appId);
    }
        // 获取签名相关的参数用于消息解密(测试号以及明文模式无此参数)
    let msgSignature = req.query.msg_signature,
        timestamp = req.query.timestamp,
        nonce = req.query.nonce;

    //监听 data 事件 用于接收数据
    let buffer: Uint8Array[] = [];
    req.on('data', function (data: any) {
        buffer.push(data);
    });

    req.on('end', function () {
        let msgXml = Buffer.concat(buffer).toString('utf-8');
        // 处理消息并响应对应的回复
        // ....
    });
});

Nest 示例如下:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
@Post("/msg")
  PostMsg(@Req() req: Request, @Res() res: Response) {
    let that = this;
    console.log('post...', req.query);
        // 支持多公众号
    let appId: string = req.query.appId;
    if (appId) {
      ApiConfigKit.setCurrentAppId(appId);
    }
        // 获取签名相关的参数用于消息解密(测试号以及明文模式无此参数)
    let msgSignature = req.query.msg_signature,
      timestamp = req.query.timestamp,
      nonce = req.query.nonce;

    //监听 data 事件 用于接收数据
    let buffer: Uint8Array[] = [];
    req.on('data', function (data: any) {
      buffer.push(data);
    });

    req.on('end', function () {
      let msgXml = Buffer.concat(buffer).toString('utf-8');
      // 处理消息并响应对应的回复
      // ...
    });
  }

处理并分发消息

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
WeChat.handleMsg(msgAdapter: MsgAdapter, msgXml: string, msgSignature?: string, timestamp?: string, nonce?: string)

handleMsg 中包含了消息的解密、各种消息分发、消息加密、各种消息回复。这里就不贴源码了,感兴趣的可以看看源码,源码也有详细的注释。

Gitee-TNW-WeChat

GitHub-TNW-WeChat

其中 msgXmlmsgSignaturetimestampnonce 已在上面的 接收各种消息中 获得,就差 MsgAdapter 了。

MsgAdapter 介绍

MsgAdapter 接口中定义的方法如下:

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
export interface MsgAdapter {
    // 处理文本消息
    processInTextMsg(inTextMsg: InTextMsg): OutMsg;
    // 处理图片消息
    processInImageMsg(inImageMsg: InImageMsg): OutMsg;
    // 处理声音消息
    processInVoiceMsg(inVoiceMsg: InVoiceMsg): OutMsg;
    // 处理视频消息
    processInVideoMsg(inVideoMsg: InVideoMsg): OutMsg;
    // 处理小视频消息
    processInShortVideoMsg(inShortVideoMsg: InShortVideoMsg): OutMsg;
    // 处理地理位置消息
    processInLocationMsg(inLocationMsg: InLocationMsg): OutMsg;
    // 处理链接消息
    processInLinkMsg(inLinkMsg: InLinkMsg): OutMsg;
    // 处理语音识别结果
    processInSpeechRecognitionResults(inSpeechRecognitionResults: InSpeechRecognitionResults): OutMsg;
    // 处理未定义的消息(其他消息...小哥该扩展了)
    processIsNotDefinedMsg(inNotDefinedMsg: InNotDefinedMsg): OutMsg;

    // 处理关注、取消关注事件
    processInFollowEvent(inFollowEvent: InFollowEvent): OutMsg;
    // 处理扫码事件
    processInQrCodeEvent(inQrCodeEvent: InQrCodeEvent): OutMsg;
    // 处理地理位置事件
    processInLocationEvent(inLocationEvent: InLocationEvent): OutMsg;
    // 处理地理位置事件
    processInMenuEvent(inMenuEvent: InMenuEvent): OutMsg;
    // 处理模板消息事件
    processInTemplateMsgEvent(inTemplateMsgEvent: InTemplateMsgEvent): OutMsg;
    // 处理摇一摇周边事件
    processInShakearoundUserShakeEvent(inShakearoundUserShakeEvent: InShakearoundUserShakeEvent): OutMsg;
}

InXxxxMsg 统一继承自 InMsgInXxxxEvent 统一继承自 EventInMsgEventInMsg 又继承自 InMsg ,所以在任何的 inXxxxx 中都很容易获取到 toUserName(开发者微信号即appId)fromUserName(发送方帐号openId)TNW 支持多公众,后面会使用到此 appId 来实现不同公众号回复不同的消息

响应对应的回复

代码实现比较简单就不过多介绍了,请看源码

提醒:回复消息时可以对不同的公众号做特殊的处理

代码语言:javascript
代码运行次数:0
运行
AI代码解释
复制
export class MsgController implements MsgAdapter {

    processInTextMsg(inTextMsg: InTextMsg): OutMsg {
        let outMsg: any;
        let content: string = "IJPay 让支付触手可及 \n\nhttps://gitee.com/javen205/IJPay";
        if ("极速开发微信公众号" == inTextMsg.getContent) {
            // 多公众号支持 分别给不同的公众号发送不同的消息
            if (ApiConfigKit.getApiConfig.getAppId == 'wx614c453e0d1dcd12') {
                content = "极速开发微信公众号 \n\nhttps://github.com/javen205/weixin_guide"
                outMsg = new OutTextMsg(inTextMsg);
                outMsg.setContent(content);
            } else {
                content = "极速开发微信公众号 \n\nhttps://github.com/javen205/TNW"
                outMsg = new OutTextMsg(inTextMsg);
                outMsg.setContent(content);
            }

        } else if ("聚合支付" == inTextMsg.getContent) {
            // 最新规则:开发者只能回复1条图文消息;其余场景最多可回复8条图文消息
            outMsg = new OutNewsMsg(inTextMsg);
            outMsg.addArticle("聚合支付了解下", "IJPay 让支付触手可及",
                "https://gitee.com/javen205/IJPay/raw/master/assets/img/IJPay-t.png", "https://gitee.com/javen205/IJPay")
            outMsg.addArticle("jfinal-weixin", "极速开发微信公众号",
                "https://gitee.com/javen205/IJPay/raw/master/assets/img/IJPay-t.png", "https://gitee.com/JFinal/jfinal-weixin")
        } else {
            // outMsg = new OutTextMsg(inTextMsg);
            // outMsg.setContent(content);
            // 转发给多客服PC客户端
            outMsg = new OutCustomMsg(inTextMsg);
            console.log("转发给多客服PC客户端");

        }
        return outMsg;
    }

    processInImageMsg(inImageMsg: InImageMsg): OutMsg {
        let outMsg = new OutImageMsg(inImageMsg);
        outMsg.setMediaId = inImageMsg.getMediaId;
        return outMsg;
    }
    processInVoiceMsg(inVoiceMsg: InVoiceMsg): OutMsg {
        let outMsg = new OutVoiceMsg(inVoiceMsg);
        outMsg.setMediaId = inVoiceMsg.getMediaId;
        return outMsg;
    }
    processInVideoMsg(inVideoMsg: InVideoMsg): OutMsg {
        let outMsg = new OutVideoMsg(inVideoMsg);
        outMsg.setMediaId = inVideoMsg.getMediaId;
        outMsg.setDescription = "IJPay 让支付触手可及";
        outMsg.setTitle = "视频消息";
        return outMsg;
    }
    processInShortVideoMsg(inShortVideoMsg: InShortVideoMsg): OutMsg {
        let outMsg = new OutVideoMsg(inShortVideoMsg);
        outMsg.setMediaId = inShortVideoMsg.getMediaId;
        outMsg.setDescription = "TypeScript + Node.js 开发微信公众号";
        outMsg.setTitle = "短视频消息";
        return outMsg;
    }
    processInLocationMsg(inLocationMsg: InLocationMsg): OutMsg {
        return this.renderOutTextMsg(inLocationMsg,
            "位置消息... \n\nX:" + inLocationMsg.getLocation_X + " Y:" + inLocationMsg.getLocation_Y + "\n\n" + inLocationMsg.getLabel);
    }
    processInLinkMsg(inLinkMsg: InLinkMsg): OutMsg {
        let text = new OutTextMsg(inLinkMsg);
        text.setContent("链接频消息..." + inLinkMsg.getUrl);
        return text;
    }
    processInSpeechRecognitionResults(inSpeechRecognitionResults: InSpeechRecognitionResults): OutMsg {
        let text = new OutTextMsg(inSpeechRecognitionResults);
        text.setContent("语音识别消息..." + inSpeechRecognitionResults.getRecognition);
        return text;
    }

    processInFollowEvent(inFollowEvent: InFollowEvent): OutMsg {

        if (InFollowEvent.EVENT_INFOLLOW_SUBSCRIBE == inFollowEvent.getEvent) {
            return this.renderOutTextMsg(inFollowEvent,
                "感谢你的关注 么么哒 \n\n交流群:114196246");
        }
        else if (InFollowEvent.EVENT_INFOLLOW_UNSUBSCRIBE == inFollowEvent.getEvent) {
            console.error("取消关注:" + inFollowEvent.getFromUserName);
            return this.renderOutTextMsg(inFollowEvent);
        } else {
            return this.renderOutTextMsg(inFollowEvent);
        }
    }

    processInQrCodeEvent(inQrCodeEvent: InQrCodeEvent): OutMsg {
        if (InQrCodeEvent.EVENT_INQRCODE_SUBSCRIBE == inQrCodeEvent.getEvent) {
            console.debug("扫码未关注:" + inQrCodeEvent.getFromUserName);
            return this.renderOutTextMsg(inQrCodeEvent,
                "感谢您的关注,二维码内容:" + inQrCodeEvent.getEventKey);
        }
        else if (InQrCodeEvent.EVENT_INQRCODE_SCAN == inQrCodeEvent.getEvent) {
            console.debug("扫码已关注:" + inQrCodeEvent.getFromUserName);
            return this.renderOutTextMsg(inQrCodeEvent);
        } else {
            return this.renderOutTextMsg(inQrCodeEvent);
        }
    }
    processInLocationEvent(inLocationEvent: InLocationEvent): OutMsg {
        console.debug("发送地理位置事件:" + inLocationEvent.getFromUserName);

        return this.renderOutTextMsg(inLocationEvent,
            "地理位置是:" + inLocationEvent.getLatitude);
    }
    processInMenuEvent(inMenuEvent: InMenuEvent): OutMsg {
        console.debug("菜单事件:" + inMenuEvent.getFromUserName);

        return this.renderOutTextMsg(inMenuEvent,
            "菜单事件内容是:" + inMenuEvent.getEventKey);
    }
    processInTemplateMsgEvent(inTemplateMsgEvent: InTemplateMsgEvent): OutMsg {
        console.debug("模板消息事件:" + inTemplateMsgEvent.getFromUserName + " " + inTemplateMsgEvent.getStatus);
        return this.renderOutTextMsg(inTemplateMsgEvent,
            "消息发送状态:" + inTemplateMsgEvent.getStatus);
    }

    processInShakearoundUserShakeEvent(inShakearoundUserShakeEvent: InShakearoundUserShakeEvent): OutMsg {
        console.debug("摇一摇事件:" + inShakearoundUserShakeEvent.getFromUserName + " " + inShakearoundUserShakeEvent.getUuid);
        return this.renderOutTextMsg(inShakearoundUserShakeEvent,
            "uuid:" + inShakearoundUserShakeEvent.getUuid);
    }

    processIsNotDefinedMsg(inNotDefinedMsg: InNotDefinedMsg): OutMsg {
        return this.renderOutTextMsg(inNotDefinedMsg,
            "未知消息");
    }

    renderOutTextMsg(inMsg: InMsg, content?: string): OutTextMsg {
        let outMsg = new OutTextMsg(inMsg);
        outMsg.setContent(content ? content : " ");
        return outMsg;
    }
}

开源推荐
