AI驱动TDSQL-C Serverless 数据库技术实战营-融合智能体与TDSQL-C技术，高效实现二手房数据查询与分析应用

pip install openai
pip install langchain
pip install langchain-core
pip install langchain-community
pip install mysql-connector-python
pip install streamlit
pip install plotly
pip install numpy
pip install pandas
pip install watchdog
pip install matplotlib
pip install kaleido

 CREATE TABLE test_table (
    id INT AUTO_INCREMENT PRIMARY KEY,
    community_name VARCHAR(255),
    location_area VARCHAR(100),
    total_price DECIMAL(10, 2),
    unit_price DECIMAL(10, 2),
    house_type VARCHAR(100),
    floor_level VARCHAR(100),
    built_area DECIMAL(10, 2),
    house_structure VARCHAR(100),
    inside_area DECIMAL(10, 2),
    building_type VARCHAR(100),
    orientation VARCHAR(50),
    construction_structure VARCHAR(100),
    decoration_status VARCHAR(100),
    elevator_ratio VARCHAR(50),
    has_elevator VARCHAR(50),
    property_years TEXT,
    listing_time DATE,
    transaction_ownership VARCHAR(100),
    last_transaction DATE,
    house_usage VARCHAR(100),
    house_age VARCHAR(100),
    property_ownership VARCHAR(100),
    mortgage_info VARCHAR(255),
    house_certificate_backup VARCHAR(255)
);

# 数据库连接信息
config = {
    'user': 'root',
    'password': 'your_password’,
    'host': 'bj***************com',
    'database': 'mysqlflex',
    'port':24863,
    'raise_on_warnings': True
}

# CSV文件路径
file_path = '南京二手房数据集.csv'



def insert_csv_data_to_db(config, file_path):
    # 创建连接
    creatConnector = mysql.connector.connect(**config)
    # 获取游标
    cursor = creatConnector.cursor()

    try:
        # 读取csv 数据, 并将数据插入到数据库
        with open(file_path, mode='r', encoding='utf-8') as csv_file:
            reader = csv.DictReader(csv_file)
            rows = list(reader)  # 将CSV行转换为列表，以便批量插入

        # 定义SQL插入语句模板
        query_template = """
        INSERT INTO test_table (
            id,
            community_name,
            location_area,
            total_price,
            unit_price,
            house_type,
            floor_level,
            built_area,
            house_structure,
            inside_area,
            building_type,
            orientation,
            construction_structure,
            decoration_status,
            elevator_ratio,
            has_elevator,
            property_years,
            listing_time,
            transaction_ownership,
            last_transaction,
            house_usage,
            house_age,
            property_ownership,
            mortgage_info,
            house_certificate_backup
        ) VALUES (
            %s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,
            )
        """

        # 将每行数据转换成元组格式，并处理空字段
        values_tuples = []
        for row in rows:
            # 将空字符串转换为None
            values = [None if value == ''  or value == '暂无数据' else value for value in row.values()]
            values_tuples.append(tuple(values))

        # 打印前几个元组进行调试
        # print(values_tuples[:5])
        cursor.executemany(query_template, values_tuples)

        # 提交事务
        creatConnector.commit()

    except mysql.connector.Error as err:
        print(f"Database error: {err}")
    except Exception as e:
        print(f"An error occurred: {e}")
    finally:
        # 关闭游标
        cursor.close()
        # 关闭连接
        creatConnector.close()


if __name__ == '__main__':
    # 调用函数执行插入操作
    insert_csv_data_to_db(config, file_path)

import csv
from langchain_community.utilities import SQLDatabase
from langchain_core.prompts import ChatPromptTemplate
from langchain_community.chat_models import ChatOllama
from langchain_core.output_parsers import StrOutputParser
from langchain_core.runnables import RunnablePassthrough
import streamlit as st
from wordcloud import WordCloud
import matplotlib.pyplot as plt
import yaml
import mysql.connector
from decimal import Decimal
import plotly.graph_objects as go
import plotly
import pkg_resources
import matplotlib
# Streamlit app code
import streamlit as st
import mysql.connector
import csv

# 数据库连接信息
config = {
    'user': 'root',
    'password': 'Ruo*****',
    'host': 'bj-************ncentcdb.com',
    'database': 'mysqlflex',
    'port': 24863,
    'raise_on_warnings': True
}




def insert_csv_data_to_db(config, file_path):
    # 创建连接
    creatConnector = mysql.connector.connect(**config)
    # 获取游标
    cursor = creatConnector.cursor()

    try:
        # 读取csv 数据, 并将数据插入到数据库
        with open(file_path, mode='r', encoding='utf-8') as csv_file:
            reader = csv.DictReader(csv_file)
            rows = list(reader)  # 将CSV行转换为列表，以便批量插入

        # 定义SQL插入语句模板
        query_template = """
        INSERT INTO test_table (
            id,
            community_name,
            location_area,
            total_price,
            unit_price,
            house_type,
            floor_level,
            built_area,
            house_structure,
            inside_area,
            building_type,
            orientation,
            construction_structure,
            decoration_status,
            elevator_ratio,
            has_elevator,
            property_years,
            listing_time,
            transaction_ownership,
            last_transaction,
            house_usage,
            house_age,
            property_ownership,
            mortgage_info,
            house_certificate_backup
        ) VALUES (
            %s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s
            )
        """

        # 将每行数据转换成元组格式，并处理空字段
        values_tuples = []
        for row in rows:
            # 将空字符串转换为None
            values = [None if value == '' or value == '暂无数据' else value for value in row.values()]
            values_tuples.append(tuple(values))

        # 打印前几个元组进行调试
        # print(values_tuples[:5])
        cursor.executemany(query_template, values_tuples)

        # 提交事务
        creatConnector.commit()

    except mysql.connector.Error as err:
        print(f"Database error: {err}")
    except Exception as e:
        print(f"An error occurred: {e}")
    finally:
        # 关闭游标
        cursor.close()
        # 关闭连接
        creatConnector.close()



yaml_file_path = 'config.yaml'

with open(yaml_file_path, 'r') as file:
  config_data = yaml.safe_load(file)


# 获取所有的已安装的pip包
def get_piplist(p):
  return [d.project_name for d in pkg_resources.working_set]


# 获取llm用于提供AI交互
ollama = ChatOllama(model=config_data['hai']['model'], base_url=config_data['hai']['base_url'])

db_user = config_data['database']['db_user']
db_password = config_data['database']['db_password']
db_host = config_data['database']['db_host']
db_port = config_data['database']['db_port']
db_name = config_data['database']['db_name']


# 获得schema
def get_schema(db):
  schema = mysql_db.get_table_info()
  return schema


def getResult(content):
  global mysql_db
  # 数据库连接
  mysql_db = SQLDatabase.from_uri(f"mysql+mysqlconnector://{db_user}:{db_password}@{db_host}:{db_port}/{db_name}")
  # 获得 数据库中表的信息
  # mysql_db_schema = mysql_db.get_table_info()
  # print(mysql_db_schema)
  template = """基于下面提供的数据库schema, 根据用户提供的要求编写sql查询语句,要求尽量使用最优sql,每次查询都是独立的问题，不要收到其他查询的干扰:
    {schema}
    Question: {question}
    只返回sql语句，不要任何其他多余的字符，例如markdown的格式字符等:
    如果有异常抛出不要显示出来
    """
  prompt = ChatPromptTemplate.from_template(template)
  text_2_sql_chain = (
    RunnablePassthrough.assign(schema=get_schema)
    | prompt
    | ollama
    | StrOutputParser()
  )

  # 执行langchain 获取操作的sql语句
  sql = text_2_sql_chain.invoke({"question": content})

  print(sql)
  # 连接数据库进行数据的获取
  # 配置连接信息
  conn = mysql.connector.connect(

    host=db_host,
    port=db_port,
    user=db_user,
    password=db_password,
    database=db_name
  )
  # 创建游标对象
  cursor = conn.cursor()
  # 查询数据
  cursor.execute(sql.strip("```").strip("```sql"))
  info = cursor.fetchall()
  # 打印结果
  # for row in info:
  # print(row)
  # 关闭游标和数据库连接
  cursor.close()
  conn.close()
  # 根据数据生成对应的图表
  print(info)
  template2 = """
    以下提供当前python环境已经安装的pip包集合:
    {installed_packages};
    请根据data提供的信息，生成是一个适合展示数据的plotly的图表的可执行代码,要求如下：
        1.不要导入没有安装的pip包代码
        2.如果存在多个数据类别，尽量使用柱状图，循环生成时图表中对不同数据请使用不同颜色区分，
        3.图表要生成图片格式,保存在当前文件夹下即可，名称固定为：图表.png,
        4.我需要您生成的代码是没有 Markdown 标记的，纯粹的编程语言代码。
        5.生成的代码请注意将所有依赖包提前导入，
        6.不要使用iplot等需要特定环境的代码
        7.请注意数据之间是否可以转换，使用正确的代码
        8.不需要生成注释
    data:{data}

    这是查询的sql语句与文本:

    sql:{sql}
    question:{question}
    返回数据要求:
    仅仅返回python代码，不要有额外的字符
    """
  prompt2 = ChatPromptTemplate.from_template(template2)
  data_2_code_chain = (
    RunnablePassthrough.assign(installed_packages=get_piplist)
    | prompt2
    | ollama
    | StrOutputParser()
  )

  # 执行langchain 获取操作的sql语句
  code = data_2_code_chain.invoke({"data": info, "sql": sql, 'question': content})

  # 删除数据两端可能存在的markdown格式
  print(code.strip("```").strip("```python"))
  exec(code.strip("```").strip("```python"))
  return {"code": code, "SQL": sql, "Query": info}


# 构建展示页面
import streamlit

# 设置页面标题
streamlit.title('智能体与TDSQL-C 的结合应用之二手房信息查询')
# 设置对话框
content = streamlit.text_area('请输入想查询的信息', value='', max_chars=None)
# 提问按钮 # 设置点击操作
if streamlit.button('提问'):
  # 开始ai及langchain操作
  if content:
    # 进行结果获取
    result = getResult(content)
    # 显示操作结果
    streamlit.write('AI生成的SQL语句:')
    streamlit.write(result['SQL'])
    streamlit.write('SQL语句的查询结果:')
    streamlit.write(result['Query'])
    streamlit.write('plotly图表代码:')
    streamlit.write(result['code'])
    # 显示图表内容（生成在getResult中）
  streamlit.image('./图表.png', width=800)
