libuv源码阅读(15)--ref-timer

原创

wanyicheng

修改于 2021-03-14 09:03:17

63800

代码可运行

文章被收录于专栏：纸上得来终觉浅纸上得来终觉浅

运行总次数：0

代码可运行

#include <stdio.h>

#include <uv.h>

uv_loop_t *loop;
uv_timer_t gc_req;
uv_timer_t fake_job_req;

void gc(uv_timer_t *handle) {
    fprintf(stderr, "Freeing unused objects\n");
}

void fake_job(uv_timer_t *handle) {
    fprintf(stdout, "Fake job done\n");
}

int main() {
    loop = uv_default_loop();

    uv_timer_init(loop, &gc_req);
    // 垃圾回收信号函数 持续执行 解除引用 loop的运行是由下面那个定时器驱动的 所以在它结束后loop也会结束
    uv_unref((uv_handle_t*) &gc_req);
    // 重复执行参数设置
    uv_timer_start(&gc_req, gc, 0, 2000);

    // could actually be a TCP download or something
    // 虚假的任务执行 9秒后结束 只执行一次 它结束后由于loop没有保持引用的激活的timer了 就停止了
    uv_timer_init(loop, &fake_job_req);
    uv_timer_start(&fake_job_req, fake_job, 9000, 0);
    return uv_run(loop, UV_RUN_DEFAULT);
}

先看下结构体：

struct uv_timer_s {
  UV_HANDLE_FIELDS
  UV_TIMER_PRIVATE_FIELDS
};

#define UV_HANDLE_FIELDS                                                      \
  /* public */                                                                \
  void* data;                                                                 \
  /* read-only */                                                             \
  uv_loop_t* loop;                                                            \
  uv_handle_type type;                                                        \
  /* private */                                                               \
  uv_close_cb close_cb;                                                       \
  void* handle_queue[2];                                                      \
  union {                                                                     \
    int fd;                                                                   \
    void* reserved[4];                                                        \
  } u;                                                                        \
  UV_HANDLE_PRIVATE_FIELDS                                                    \

#define UV_HANDLE_PRIVATE_FIELDS                                              \
  uv_handle_t* next_closing;                                                  \
  unsigned int flags;                                                         \

#define UV_TIMER_PRIVATE_FIELDS                                               \
  uv_timer_cb timer_cb;                                                       \
  void* heap_node[3];                                                         \
  uint64_t timeout;                                                           \
  uint64_t repeat;                                                            \
  uint64_t start_id;

主要包含 timercb 和用于最小时间堆节点字段heap_node等；它由一个基础hanlder类型和自身独有的属性构成

int uv_timer_init(uv_loop_t* loop, uv_timer_t* handle) {
  // 同用handler的初始化
  uv__handle_init(loop, (uv_handle_t*)handle, UV_TIMER);
  handle->timer_cb = NULL;
  handle->timeout = 0;
  handle->repeat = 0;
  return 0;
}


int uv_timer_start(uv_timer_t* handle,
                   uv_timer_cb cb,
                   uint64_t timeout,
                   uint64_t repeat) {
  uint64_t clamped_timeout;

  if (uv__is_closing(handle) || cb == NULL)
    return UV_EINVAL;

  if (uv__is_active(handle))
    uv_timer_stop(handle);

  // 计算绝对时间超时值
  clamped_timeout = handle->loop->time + timeout;
  if (clamped_timeout < timeout)
    clamped_timeout = (uint64_t) -1;

  handle->timer_cb = cb;
  handle->timeout = clamped_timeout;
  handle->repeat = repeat;
  /* start_id is the second index to be compared in timer_less_than() */
  handle->start_id = handle->loop->timer_counter++;

  // 插入loop的最小时间堆中
  heap_insert(timer_heap(handle->loop),
              (struct heap_node*) &handle->heap_node,
              timer_less_than);
  // 激活handler
  uv__handle_start(handle);

  return 0;
}

int uv_timer_stop(uv_timer_t* handle) {
  if (!uv__is_active(handle))
    return 0;

  heap_remove(timer_heap(handle->loop),
              (struct heap_node*) &handle->heap_node,
              timer_less_than);
  uv__handle_stop(handle);

  return 0;
}

// 第一个定时器会重置执行 因为设置了repeat的重复时间
int uv_timer_again(uv_timer_t* handle) {
  if (handle->timer_cb == NULL)
    return UV_EINVAL;

  if (handle->repeat) {
    uv_timer_stop(handle);
    uv_timer_start(handle, handle->timer_cb, handle->repeat, handle->repeat);
  }

  return 0;
}

//  一次性定时器执行完回调后就会清除
void uv__run_timers(uv_loop_t* loop) {
  struct heap_node* heap_node;
  uv_timer_t* handle;

  for (;;) {
    heap_node = heap_min(timer_heap(loop));
    if (heap_node == NULL)
      break;

    handle = container_of(heap_node, uv_timer_t, heap_node);
    if (handle->timeout > loop->time)
      break;

    uv_timer_stop(handle);
    uv_timer_again(handle);
    handle->timer_cb(handle);
  }
}
