绘图需求最大的难关往往是数据整理，比如下面的双层list ：

set.seed(123456)
gs=list(tmp1=list(g1=sample(1000,abs(floor(100*rnorm(1)))),
                  g2=sample(1000,abs(floor(100*rnorm(1))))),
        tmp2=list(g1=sample(1000,abs(floor(100*rnorm(1)))),
                  g2=sample(1000,abs(floor(100*rnorm(1))))),
        tmp3=list(g1=sample(1000,abs(floor(100*rnorm(1)))),
                  g2=sample(1000,abs(floor(100*rnorm(1))))))
gs

这个双层list的数据结构如下：

有3个样本，每个样本里面都是上下调基因集合，以 g1和g2区分：

require("VennDiagram")
VENN.LIST <- lapply(gs, function(x) x$g1)
venn.plot1 <- venn.diagram(VENN.LIST , NULL,
                          fill=c("red", "blue",'green'),
                          alpha=c(0.5,0.5,0.5), cex = 2, cat.fontface=4,
                          category.names=c('tmp1','tmp2','tmp3'),
                          main="g1 Gene Lists")
# To plot the venn diagram we will use the grid.draw() function to plot the venn diagram
grid.draw(venn.plot1)

require("VennDiagram")
VENN.LIST <- lapply(gs, function(x) x$g2)
venn.plot2 <- venn.diagram(VENN.LIST , NULL,
                          fill=c("red", "blue",'green'),
                          alpha=c(0.5,0.5,0.5), cex = 2, cat.fontface=4,
                          category.names=c('tmp1','tmp2','tmp3'),
                          main="g2 Gene Lists")
# To plot the venn diagram we will use the grid.draw() function to plot the venn diagram
grid.draw(venn.plot2)


grid.newpage()
grid.draw(venn.plot1)
grid.newpage()
grid.draw(venn.plot2)

如下所示：

韦恩图固然是一种展现方式，可以看到3个样品各自的上下调基因的overlap情况，基本上呢，随机生成的数值它们的overlap不咋地！

但是呢，3个样品我们其实更想看各自的上下调基因集的生物学功能，需要把这个双层list变成长形数据框，超级复杂，下面的代码：

deg=gs
deg_list=lapply(names(deg), function(y){
  tmp=deg[[y]]
  data.frame(group= paste(y,unlist(lapply(names(tmp), function(x){
    rep(x,length(tmp[[x]]))
  })),sep='_') ,
  gene=unlist(tmp))
})
group_g=do.call(rbind,deg_list)
group_g=do.call(rbind,deg_list)
library(org.Hs.eg.db)
group_g$gene=toTable(org.Hs.egSYMBOL)[group_g$gene,2]
head(group_g)

library(clusterProfiler)

# Convert gene ID into entrez genes
head(group_g)
tmp <- bitr(group_g$gene, fromType="SYMBOL",
            toType="ENTREZID",
            OrgDb="org.Hs.eg.db")

de_gene_clusters=merge(tmp,group_g,by.x='SYMBOL',by.y='gene')
table(de_gene_clusters$group)
head(de_gene_clusters)

list_de_gene_clusters <- split(de_gene_clusters$ENTREZID,
                               de_gene_clusters$group)

library(ggplot2)
gcSample= list_de_gene_clusters
xx <- compareCluster(gcSample, fun="enrichKEGG",
                     organism="hsa", pvalueCutoff=0.05)
dotplot(xx)
