ClickHouse源码笔记2:聚合流程的实现

class Block
{
private:
    using Container = ColumnsWithTypeAndName;
    using IndexByName = std::map<String, size_t>;

    Container data;
    IndexByName index_by_name;

class IBlockInputStream : public TypePromotion<IBlockInputStream>
{
    friend struct BlockStreamProfileInfo;

public:
    IBlockInputStream() { info.parent = this; }
    virtual ~IBlockInputStream() {}

    IBlockInputStream(const IBlockInputStream &) = delete;
    IBlockInputStream & operator=(const IBlockInputStream &) = delete;

    /// To output the data stream transformation tree (query execution plan).
    virtual String getName() const = 0;

    /** Get data structure of the stream in a form of "header" block (it is also called "sample block").
      * Header block contains column names, data types, columns of size 0. Constant columns must have corresponding values.
      * It is guaranteed that method "read" returns blocks of exactly that structure.
      */
    virtual Block getHeader() const = 0;

    virtual const BlockMissingValues & getMissingValues() const
    {
        static const BlockMissingValues none;
        return none;
    }

    /// If this stream generates data in order by some keys, return true.
    virtual bool isSortedOutput() const { return false; }

    /// In case of isSortedOutput, return corresponding SortDescription
    virtual const SortDescription & getSortDescription() const;

    /** Read next block.
      * If there are no more blocks, return an empty block (for which operator `bool` returns false).
      * NOTE: Only one thread can read from one instance of IBlockInputStream simultaneously.
      * This also applies for readPrefix, readSuffix.
      */
    Block read();

class AggregatingBlockInputStream : public IBlockInputStream
{
public:
    /** keys are taken from the GROUP BY part of the query
      * Aggregate functions are searched everywhere in the expression.
      * Columns corresponding to keys and arguments of aggregate functions must already be computed.
      */
    AggregatingBlockInputStream(const BlockInputStreamPtr & input, const Aggregator::Params & params_, bool final_)
        : params(params_), aggregator(params), final(final_)
    {
        children.push_back(input);
    }

    String getName() const override { return "Aggregating"; }

    Block getHeader() const override;

protected:
    Block readImpl() override;

    Aggregator::Params params;
    Aggregator aggregator;
    bool final;

    bool executed = false;

    std::vector<std::unique_ptr<TemporaryFileStream>> temporary_inputs;

     /** From here we will get the completed blocks after the aggregation. */
    std::unique_ptr<IBlockInputStream> impl;
};

 struct Params
    {
        /// Data structure of source blocks.
        Block src_header;
        /// Data structure of intermediate blocks before merge.
        Block intermediate_header;

        /// What to count.
        const ColumnNumbers keys;
        const AggregateDescriptions aggregates;
        const size_t keys_size;
        const size_t aggregates_size;

        /// The settings of approximate calculation of GROUP BY.
        const bool overflow_row;    /// Do we need to put into AggregatedDataVariants::without_key aggregates for keys that are not in max_rows_to_group_by.
        const size_t max_rows_to_group_by;
        const OverflowMode group_by_overflow_mode;



        /// Settings to flush temporary data to the filesystem (external aggregation).
        const size_t max_bytes_before_external_group_by;        /// 0 - do not use external aggregation.

        /// Return empty result when aggregating without keys on empty set.
        bool empty_result_for_aggregation_by_empty_set;

        VolumePtr tmp_volume;

        /// Settings is used to determine cache size. No threads are created.
        size_t max_threads;

        const size_t min_free_disk_space;
        Params(
            const Block & src_header_,
            const ColumnNumbers & keys_, const AggregateDescriptions & aggregates_,
            bool overflow_row_, size_t max_rows_to_group_by_, OverflowMode group_by_overflow_mode_,
            size_t group_by_two_level_threshold_, size_t group_by_two_level_threshold_bytes_,
            size_t max_bytes_before_external_group_by_,
            bool empty_result_for_aggregation_by_empty_set_,
            VolumePtr tmp_volume_, size_t max_threads_,
            size_t min_free_disk_space_)
            : src_header(src_header_),
            keys(keys_), aggregates(aggregates_), keys_size(keys.size()), aggregates_size(aggregates.size()),
            overflow_row(overflow_row_), max_rows_to_group_by(max_rows_to_group_by_), group_by_overflow_mode(group_by_overflow_mode_),
            group_by_two_level_threshold(group_by_two_level_threshold_), group_by_two_level_threshold_bytes(group_by_two_level_threshold_bytes_),
            max_bytes_before_external_group_by(max_bytes_before_external_group_by_),
            empty_result_for_aggregation_by_empty_set(empty_result_for_aggregation_by_empty_set_),
            tmp_volume(tmp_volume_), max_threads(max_threads_),
            min_free_disk_space(min_free_disk_space_)
        {
        }

        /// Only parameters that matter during merge.
        Params(const Block & intermediate_header_,
            const ColumnNumbers & keys_, const AggregateDescriptions & aggregates_, bool overflow_row_, size_t max_threads_)
            : Params(Block(), keys_, aggregates_, overflow_row_, 0, OverflowMode::THROW, 0, 0, 0, false, nullptr, max_threads_, 0)
        {
            intermediate_header = intermediate_header_;
        }
    };

class Aggregator
{
public:
    Aggregator(const Params & params_);

    /// Aggregate the source. Get the result in the form of one of the data structures.
    void execute(const BlockInputStreamPtr & stream, AggregatedDataVariants & result);

    using AggregateColumns = std::vector<ColumnRawPtrs>;
    using AggregateColumnsData = std::vector<ColumnAggregateFunction::Container *>;
    using AggregateColumnsConstData = std::vector<const ColumnAggregateFunction::Container *>;
    using AggregateFunctionsPlainPtrs = std::vector<IAggregateFunction *>;

    /// Process one block. Return false if the processing should be aborted (with group_by_overflow_mode = 'break').
    bool executeOnBlock(const Block & block, AggregatedDataVariants & result,
        ColumnRawPtrs & key_columns, AggregateColumns & aggregate_columns,    /// Passed to not create them anew for each block
        bool & no_more_keys);

    bool executeOnBlock(Columns columns, UInt64 num_rows, AggregatedDataVariants & result,
        ColumnRawPtrs & key_columns, AggregateColumns & aggregate_columns,    /// Passed to not create them anew for each block
        bool & no_more_keys);

    /** Convert the aggregation data structure into a block.
      * If overflow_row = true, then aggregates for rows that are not included in max_rows_to_group_by are put in the first block.
      *
      * If final = false, then ColumnAggregateFunction is created as the aggregation columns with the state of the calculations,
      *  which can then be combined with other states (for distributed query processing).
      * If final = true, then columns with ready values are created as aggregate columns.
      */
    BlocksList convertToBlocks(AggregatedDataVariants & data_variants, bool final, size_t max_threads) const;

    /** Merge several aggregation data structures and output the result as a block stream.
      */
    std::unique_ptr<IBlockInputStream> mergeAndConvertToBlocks(ManyAggregatedDataVariants & data_variants, bool final, size_t max_threads) const;
    ManyAggregatedDataVariants prepareVariantsToMerge(ManyAggregatedDataVariants & data_variants) const;

    /** Merge the stream of partially aggregated blocks into one data structure.
      * (Pre-aggregate several blocks that represent the result of independent aggregations from remote servers.)
      */
    void mergeStream(const BlockInputStreamPtr & stream, AggregatedDataVariants & result, size_t max_threads);

    using BucketToBlocks = std::map<Int32, BlocksList>;
    /// Merge partially aggregated blocks separated to buckets into one data structure.
    void mergeBlocks(BucketToBlocks bucket_to_blocks, AggregatedDataVariants & result, size_t max_threads);

    /// Merge several partially aggregated blocks into one.
    /// Precondition: for all blocks block.info.is_overflows flag must be the same.
    /// (either all blocks are from overflow data or none blocks are).
    /// The resulting block has the same value of is_overflows flag.
    Block mergeBlocks(BlocksList & blocks, bool final);

     std::unique_ptr<IBlockInputStream> mergeAndConvertToBlocks(ManyAggregatedDataVariants & data_variants, bool final, size_t max_threads) const;

    using CancellationHook = std::function<bool()>;

    /** Set a function that checks whether the current task can be aborted.
      */
    void setCancellationHook(const CancellationHook cancellation_hook);

    /// Get data structure of the result.
    Block getHeader(bool final) const;

void Aggregator::execute(const BlockInputStreamPtr & stream, AggregatedDataVariants & result)
{
    Stopwatch watch;

    size_t src_rows = 0;
    size_t src_bytes = 0;

    /// Read all the data
    while (Block block = stream->read())
    {
        if (isCancelled())
            return;

        src_rows += block.rows();
        src_bytes += block.bytes();

        if (!executeOnBlock(block, result, key_columns, aggregate_columns, no_more_keys))
            break;
    }

bool Aggregator::executeOnBlock(Columns columns, UInt64 num_rows, AggregatedDataVariants & result,
    ColumnRawPtrs & key_columns, AggregateColumns & aggregate_columns, bool & no_more_keys)
{
    /// `result` will destroy the states of aggregate functions in the destructor
    result.aggregator = this;

    /// How to perform the aggregation?
    if (result.empty())
    {
        result.init(method_chosen);
        result.keys_size = params.keys_size;
        result.key_sizes = key_sizes;
        LOG_TRACE(log, "Aggregation method: " << result.getMethodName());
    }

    for (size_t i = 0; i < params.aggregates_size; ++i)
        aggregate_columns[i].resize(params.aggregates[i].arguments.size());

    /** Constant columns are not supported directly during aggregation.
      * To make them work anyway, we materialize them.
      */
    Columns materialized_columns;

    /// Remember the columns we will work with
    for (size_t i = 0; i < params.keys_size; ++i)
    {
        materialized_columns.push_back(columns.at(params.keys[i])->convertToFullColumnIfConst());
        key_columns[i] = materialized_columns.back().get();

        if (!result.isLowCardinality())
        {
            auto column_no_lc = recursiveRemoveLowCardinality(key_columns[i]->getPtr());
            if (column_no_lc.get() != key_columns[i])
            {
                materialized_columns.emplace_back(std::move(column_no_lc));
                key_columns[i] = materialized_columns.back().get();
            }
        }
    }

    AggregateFunctionInstructions aggregate_functions_instructions(params.aggregates_size + 1);
    aggregate_functions_instructions[params.aggregates_size].that = nullptr;

    std::vector<std::vector<const IColumn *>> nested_columns_holder;
    for (size_t i = 0; i < params.aggregates_size; ++i)
    {
        for (size_t j = 0; j < aggregate_columns[i].size(); ++j)
        {
            materialized_columns.push_back(columns.at(params.aggregates[i].arguments[j])->convertToFullColumnIfConst());
            aggregate_columns[i][j] = materialized_columns.back().get();

            auto column_no_lc = recursiveRemoveLowCardinality(aggregate_columns[i][j]->getPtr());
            if (column_no_lc.get() != aggregate_columns[i][j])
            {
                materialized_columns.emplace_back(std::move(column_no_lc));
                aggregate_columns[i][j] = materialized_columns.back().get();
            }
        }

        aggregate_functions_instructions[i].arguments = aggregate_columns[i].data();
        aggregate_functions_instructions[i].state_offset = offsets_of_aggregate_states[i];
        auto that = aggregate_functions[i];
        /// Unnest consecutive trailing -State combinators
        while (auto func = typeid_cast<const AggregateFunctionState *>(that))
            that = func->getNestedFunction().get();
        aggregate_functions_instructions[i].that = that;
        aggregate_functions_instructions[i].func = that->getAddressOfAddFunction();

        if (auto func = typeid_cast<const AggregateFunctionArray *>(that))
        {
            /// Unnest consecutive -State combinators before -Array
            that = func->getNestedFunction().get();
            while (auto nested_func = typeid_cast<const AggregateFunctionState *>(that))
                that = nested_func->getNestedFunction().get();
            auto [nested_columns, offsets] = checkAndGetNestedArrayOffset(aggregate_columns[i].data(), that->getArgumentTypes().size());
            nested_columns_holder.push_back(std::move(nested_columns));
            aggregate_functions_instructions[i].batch_arguments = nested_columns_holder.back().data();
            aggregate_functions_instructions[i].offsets = offsets;
        }
        else
            aggregate_functions_instructions[i].batch_arguments = aggregate_columns[i].data();

        aggregate_functions_instructions[i].batch_that = that;
    }

template <typename Method>
void NO_INLINE Aggregator::executeImpl(
    Method & method,
    Arena * aggregates_pool,
    size_t rows,
    ColumnRawPtrs & key_columns,
    AggregateFunctionInstruction * aggregate_instructions,
    bool no_more_keys,
    AggregateDataPtr overflow_row) const
{
    typename Method::State state(key_columns, key_sizes, aggregation_state_cache);

    if (!no_more_keys)
        executeImplBatch(method, state, aggregates_pool, rows, aggregate_instructions);
    else
        executeImplCase<true>(method, state, aggregates_pool, rows, aggregate_instructions, overflow_row);
}

template <typename Method>
void NO_INLINE Aggregator::executeImplBatch(
    Method & method,
    typename Method::State & state,
    Arena * aggregates_pool,
    size_t rows,
    AggregateFunctionInstruction * aggregate_instructions) const
{
    PODArray<AggregateDataPtr> places(rows);

    /// For all rows.
    for (size_t i = 0; i < rows; ++i)
    {
        AggregateDataPtr aggregate_data = nullptr;

        auto emplace_result = state.emplaceKey(method.data, i, *aggregates_pool);

        /// If a new key is inserted, initialize the states of the aggregate functions, and possibly something related to the key.
        if (emplace_result.isInserted())
        {
            /// exception-safety - if you can not allocate memory or create states, then destructors will not be called.
            emplace_result.setMapped(nullptr);

            aggregate_data = aggregates_pool->alignedAlloc(total_size_of_aggregate_states, align_aggregate_states);
            createAggregateStates(aggregate_data);

            emplace_result.setMapped(aggregate_data);
        }
        else
            aggregate_data = emplace_result.getMapped();

        places[i] = aggregate_data;
        assert(places[i] != nullptr);
    }

    /// Add values to the aggregate functions.
    for (AggregateFunctionInstruction * inst = aggregate_instructions; inst->that; ++inst)
    {
        if (inst->offsets)
            inst->batch_that->addBatchArray(rows, places.data(), inst->state_offset, inst->batch_arguments, inst->offsets, aggregates_pool);
        else
            inst->batch_that->addBatch(rows, places.data(), inst->state_offset, inst->batch_arguments, aggregates_pool);
    }
