【诊断方法】AWR 快照（snapshot）无法获取

set mark html on
spool Info.html
alter session set NLS_DATE_FORMAT = 'YYYY/MM/DD HH24:MI:SS';
alter session set nls_timestamp_format='YYYY-MM-DD HH24:MI:SS.FF3'

---数据库状态
select open_mode from v$database;
---AWR相关环境设定信息
show parameter control_management_pack_access
show parameter statistics

---AWR设定信息
select * from dba_hist_wr_control;

---快照的取得信息
select * from dba_hist_snapshot order by snap_id;

---快照的最新取得时间信息
col systimestamp form a35
col most_recent_snap_time form a25
col snap_interval form a17
select systimestamp,
      most_recent_snap_time,
      snap_interval
 from wrm$_wr_control
where dbid = (select dbid from v$database);

---快照的错误信息
col instance_number form 999 head INST
col begin_interval_time form a25
col flush_elapsed form a17
col status form 999
col error_count form 999 head ERR
col snap_flag form 999 head SNAP
select * from
 (select snap_id,instance_number,STARTUP_TIME，begin_interval_time,
         flush_elapsed,status,error_count,snap_flag
    from wrm$_snapshot
   where dbid = (select dbid from v$database)
   order by snap_id desc)
 where rownum <= 10
 order by snap_id
;

---快照的错误原因
select * from wrm$_snap_error
where dbid = (select dbid from v$database)
order by snap_id;

---版本11.2.0.2以后，通过WRM$_SNAPSHOT_DETAILS视图获得各AWR对象表的处理时间

 set pagesize 999
 column name format a28
 column time format a29
 variable dbid number
 exec select dbid into :dbid from v$database;
 variable snap_id number
 exec select max(snap_id) into :snap_id from wrm$_snapshot where dbid=:dbid;
 select table_name_kewrtb name, end_time-begin_time time
 from wrm$_snapshot_details, x$kewrtb
 where snap_id = :snap_id and dbid = :dbid
      and table_id = table_id_kewrtb
      order by table_id;

---获取AQ相关信息，看是否AQ的信息太多
SELECT q_name, a, COUNT (*) HOW_MANY
FROM (SELECT q_name, TRUNC(enq_time, 'DD') AS a
FROM SYS.alert_qt
ORDER BY enq_time)
GROUP BY a, q_name
ORDER BY a;

select systimestamp, count(*), QUEUE, MSG_STATE
from aq$ALERT_QT
group by msg_state, queue;

spool off;
set mark html off;

例如：
Suspending MMON slave action kewrmafsa_ for 82800 seconds

export ORACLE_HOME=<OracleHome>
cd $ORACLE_HOME\OPatch
./opatch lsinventory

查看本节点的MMON状态：SQL> oradebug setmypid
SQL> oradebug unit_test kebm_dmp_slv_attrs kewrmafsa_

输出例：
SQL> oradebug setmypid
Statement processed.
SQL> oradebug unit_test kebm_dmp_slv_attrs kewrmafsa_
Status: 2
Flags: 0
Runtime limit: 1800
CPU time limit: 600
Violations: 0
Suspended until: 0 ★如果这个值大于0的话，则代表MMON发生了挂起


查看远程节点的MMON状态（RAC）：SQL> oradebug setmypid
SQL> oradebug unit_test kebm_dmp_slv_attrs kewrmrfsa_

如果发生了挂起，使用如下命令进行恢复。SQL> oradebug unit_test kebm_set_slv_attrs kewrmafsa_ retain retain retain retain 0 0

例：
SQL> exec dbms_workload_repository.create_snapshot();

SQL> connect / as sysdba
SQL> @?/rdbms/admin/awrinfo.sql

有效：
---MMON action trace
SQL> alter session set "_swrf_test_action" = 28;
--snapshot flush Trace
SQL> alter session set "_swrf_test_action" = 10;

无效：（设置后等待1小时以上，包含AWR取得时间段）
SQL> alter session set "_swrf_test_action" = 29;
SQL> alter session set "_swrf_test_action" = 11;

例：
有效：
begin
dbms_monitor.serv_mod_act_trace_enable(service_name=>'SYS$BACKGROUND',
module_name=>'MMON_SLAVE',
action_name=>'Auto-Flush Slave Action');

dbms_monitor.serv_mod_act_trace_enable(service_name=>'SYS$BACKGROUND',
module_name=>'MMON_SLAVE',
action_name=>'Remote-Flush Slave Action');
end;
/

无效：
begin
dbms_monitor.serv_mod_act_trace_disable(service_name=>'SYS$BACKGROUND',
module_name=>'MMON_SLAVE',
action_name=>'Auto-Flush Slave Action');

dbms_monitor.serv_mod_act_trace_disable(service_name=>'SYS$BACKGROUND',
module_name=>'MMON_SLAVE',
action_name=>'Remote-Flush Slave Action');
end;
/

有效：
（trace AWR SQL）
alter session set events 'immediate trace name awr_test level 3';

另外，也可以通过以下的设置获得其他的一些trace。
trace AWR snapshots：
alter session set events 'immediate trace name awr_test level 1';
trace AWR purging：
alter session set events 'immediate trace name awr_test level 2';

无效：（关闭所有awr test trace）
alter session set events 'immediate trace name awr_test level 4';

SQL> connect /as sysdba
SQL> oradebug setmypid
SQL> oradebug unlimit
SQL> oradebug setinst all
SQL> oradebug -g all hanganalyze 4
SQL> oradebug -g all dump systemstate 266
SQL> quit

<等待...>
SQL> connect /as sysdba
SQL> oradebug setmypid
SQL> oradebug unlimit
SQL> oradebug setinst all
SQL> oradebug -g all hanganalyze 4
SQL> oradebug -g all dump systemstate 266
SQL> quit

<等待...>
SQL> connect /as sysdba
SQL> oradebug setmypid
SQL> oradebug unlimit
SQL> oradebug setinst all
SQL> oradebug -g all hanganalyze 4
SQL> oradebug -g all dump systemstate 266
SQL> quit

1.确认MMON的PID
SELECT s.program, p.pid
FROM v$session s, v$process p
WHERE s.paddr=p.addr
AND s.program like '%(MMON)';

2.获取errorstack
oradebug setorapid <MMON_PID_from_previous_query>
oradebug unlimit
oradebug short_stack   ---> Repeat this command one or more times.
oradebug tracefile_name

例：
alter system enable restricted session;
alter system disable restricted session;

例:
kill -9 <MMON Process ID>

MMON被kill或，会自动启动MMON和MMON Slave进程（m00x）

通过重启数据库会重新启动MMON，从而解决相关问题

--
alter system set "_alert_message_purge"=0;

declare
po dbms_aqadm.aq$_purge_options_t;
begin
 dbms_aqadm.purge_queue_table(queue_table => 'ALERT_QT',
                              purge_condition => NULL,
                              purge_options => po);
end;
/

alter system set "_alert_message_purge"=1;

参考：
How to Recreate the Automatic Workload Repository (AWR)? (Doc ID 782974.1)

例：
SQL> execute dbms_stats.gather_table_stats

例：
alter system set "_awr_disabled_flush_tables" = 'wrh$_sql_bind_metadata';
