一、Spring AOP源码解析

原创

冰枫

发布于 2018-05-05 04:23:12

1.7K20

代码可运行

文章被收录于专栏：冰枫冰枫

运行总次数：0

代码可运行

在Spring中可以通过xml方式，或者注解方式来实现Aop，如果通过注解方式则需要在xml中配置

<aop:aspectj-autoproxy/>

这篇文章详细讲解一下注解方式是如何来实现Aop的。

一、注册beanDefinitionParser

AopNamespaceHandler是aop命名空间的处理类

它注册了解析config、aspectj-autoproxy、scoped-proxy标签的BeanDefinitionParser，spring-configured标签从2.1开始就被移动了context命名空间中。

	@Override
	public void init() {
		// In 2.0 XSD as well as in 2.1 XSD.
		registerBeanDefinitionParser("config", new ConfigBeanDefinitionParser());
		registerBeanDefinitionParser("aspectj-autoproxy", new AspectJAutoProxyBeanDefinitionParser());
		registerBeanDefinitionDecorator("scoped-proxy", new ScopedProxyBeanDefinitionDecorator());

		// Only in 2.0 XSD: moved to context namespace as of 2.1
		registerBeanDefinitionParser("spring-configured", new SpringConfiguredBeanDefinitionParser());
	}

我们直接来看AspectJAutoProxyBeanDefinitionParser的代码：

二、aspectj-autoproxy解析入口

解析分成两项工作

1.注册AspectJAnnotationAutoProxyCreator

2.获取子标签，注册到beanDefinition

@Override
	public BeanDefinition parse(Element element, ParserContext parserContext) {
		AopNamespaceUtils.registerAspectJAnnotationAutoProxyCreatorIfNecessary(parserContext, element);
		extendBeanDefinition(element, parserContext);
		return null;
	}

三、注册AspectJAnnotationAutoProxyCreator

1.如果要代理的类实现了接口，则默认使用jdk动态代理否则将使用cglib进行代理

2.如果配置了proxy-target-class为true，将强制使用cglib进行代理

	public static void registerAspectJAnnotationAutoProxyCreatorIfNecessary(
			ParserContext parserContext, Element sourceElement) {
	  // 注册registerAspectJAnnotationAutoProxyCreator
		BeanDefinition beanDefinition = AopConfigUtils.registerAspectJAnnotationAutoProxyCreatorIfNecessary(
				parserContext.getRegistry(), parserContext.extractSource(sourceElement));
				// 处理xml中配置的aspectj-autoproxy中的proxy-target-class 和 expose-proxy属性
		useClassProxyingIfNecessary(parserContext.getRegistry(), sourceElement);
		// 注册组件
		registerComponentIfNecessary(beanDefinition, parserContext);
	}

顾名思义注册或者升级AspectJAnnotationAutoProxyCreator，如果有优先级更高的AspectJAnnotationAutoProxyCreator，那么升级为优先级更高的AspectJAnnotationAutoProxyCreator，这里不进行详细解释

public static BeanDefinition registerAspectJAnnotationAutoProxyCreatorIfNecessary(BeanDefinitionRegistry registry, Object source) {
		return registerOrEscalateApcAsRequired(AnnotationAwareAspectJAutoProxyCreator.class, registry, source);
	}

完成了上述工作，AnnotationAwareAspectJAutoProxyCreator就已经在IOC容器中注册完毕了。

四、AnnotationAwareAspectJAutoProxyCreator

AnnotationAwareAspectJAutoProxyCreator它层级实现了InstantiationAwareBeanPostProcessor

，学习过Spring IOC容器源码的童鞋应该知道它的postProcessor方法将会在IOC容器中bean的实例化，初始化等等时候被调用。aop的核心也就是在此。

在AbstractAutoProxyCreator类中对这些方法进行了重写：

public Object postProcessBeforeInstantiation(Class<?> beanClass, String beanName) throws BeansException {
		// 在className和beanName中用"_"连接 例：cn.blingfeng.Test_test
		Object cacheKey = getCacheKey(beanClass, beanName);
		// 如果beanName为空或者bean还未被处理过
		if (beanName == null || !this.targetSourcedBeans.contains(beanName)) {
			// 如果不需要代理
			if (this.advisedBeans.containsKey(cacheKey)) {
				return null;
			}
			// 如果为Advisor Advice AopInfrastructureBean 类的实现类 或者 为pointCut则不需要处理
			if (isInfrastructureClass(beanClass) || shouldSkip(beanClass, beanName)) {
				this.advisedBeans.put(cacheKey, Boolean.FALSE);
				return null;
			}
		}

		if (beanName != null) {
			// 获取定制的targetSource，可以通过子类重写此方法，来实现不同的机制
			TargetSource targetSource = getCustomTargetSource(beanClass, beanName);
			if (targetSource != null) {
				this.targetSourcedBeans.add(beanName);
				// 获取增强方法
				Object[] specificInterceptors = getAdvicesAndAdvisorsForBean(beanClass, beanName, targetSource);
				// 创建代理
				Object proxy = createProxy(beanClass, beanName, specificInterceptors, targetSource);
				this.proxyTypes.put(cacheKey, proxy.getClass());
				return proxy;
			}
		}

		return null;
	}

	@Override
	public boolean postProcessAfterInstantiation(Object bean, String beanName) {
		return true;
	}

	@Override
	public PropertyValues postProcessPropertyValues(
			PropertyValues pvs, PropertyDescriptor[] pds, Object bean, String beanName) {

		return pvs;
	}

	@Override
	public Object postProcessBeforeInitialization(Object bean, String beanName) {
		return bean;
	}

	@Override
	public Object postProcessAfterInitialization(Object bean, String beanName) throws BeansException {
		if (bean != null) {
			Object cacheKey = getCacheKey(bean.getClass(), beanName);
			if (!this.earlyProxyReferences.contains(cacheKey)) {
			 // bena进行包装
				return wrapIfNecessary(bean, beanName, cacheKey);
			}
		}
		return bean;
	}

protected Object wrapIfNecessary(Object bean, String beanName, Object cacheKey) {
    // 如果bean还未被处理
		if (beanName != null && this.targetSourcedBeans.contains(beanName)) {
			return bean;
		}
		// bean不需要增强
		if (Boolean.FALSE.equals(this.advisedBeans.get(cacheKey))) {
			return bean;
		}
		// 如果为Advisor Advice AopInfrastructureBean 类的实现类 或者 为pointCut则不需要处理
		if (isInfrastructureClass(bean.getClass()) || shouldSkip(bean.getClass(), beanName)) {
			this.advisedBeans.put(cacheKey, Boolean.FALSE);
			return bean;
		}

		// 获取增强
		Object[] specificInterceptors = getAdvicesAndAdvisorsForBean(bean.getClass(), beanName, null);
		// 如果存在增强方法
		if (specificInterceptors != DO_NOT_PROXY) {
			this.advisedBeans.put(cacheKey, Boolean.TRUE);
			// 创建代理
			Object proxy = createProxy(bean.getClass(), beanName, specificInterceptors, new SingletonTargetSource(bean));
			this.proxyTypes.put(cacheKey, proxy.getClass());
			return proxy;
		}

		this.advisedBeans.put(cacheKey, Boolean.FALSE);
		return bean;
	}

isInfrastructureClass()方法具体实现，如果为Advice或Advisor或AopInfrastrutureBean的实现则返回true

	protected boolean isInfrastructureClass(Class<?> beanClass) {
		boolean retVal = Advice.class.isAssignableFrom(beanClass) ||
				Advisor.class.isAssignableFrom(beanClass) ||
				AopInfrastructureBean.class.isAssignableFrom(beanClass);
		if (retVal && logger.isTraceEnabled()) {
			logger.trace("Did not attempt to auto-proxy infrastructure class [" + beanClass.getName() + "]");
		}
		return retVal;
	}

shouldSkip()方法具体实现，

首先获取所有的增强，可以看到上面有一个todo注释：考虑缓存aspect names，因为findCandidateAdvisors()这个方法，我们在后面的获取增强方法，进行代理，还要用到，所以弄一个Set集合进行缓存可以提升性能。

然后遍历增强，如果为AspectJPointcutAdvisor派生类则返回true

@Override
	protected boolean shouldSkip(Class<?> beanClass, String beanName) {
		// TODO: Consider optimization by caching the list of the aspect names
		List<Advisor> candidateAdvisors = findCandidateAdvisors();
		for (Advisor advisor : candidateAdvisors) {
			if (advisor instanceof AspectJPointcutAdvisor) {
				if (((AbstractAspectJAdvice) advisor.getAdvice()).getAspectName().equals(beanName)) {
					return true;
				}
			}
		}
		return super.shouldSkip(beanClass, beanName);
	}

获取增强

@Override
	protected Object[] getAdvicesAndAdvisorsForBean(Class<?> beanClass, String beanName, TargetSource targetSource) {
		List<Advisor> advisors = findEligibleAdvisors(beanClass, beanName);
		if (advisors.isEmpty()) {
			return DO_NOT_PROXY;
		}
		return advisors.toArray();
	}

1.首先获取所有的增强

2.寻找适用于该bean的增强

protected List<Advisor> findEligibleAdvisors(Class<?> beanClass, String beanName) {
		// 1.
		List<Advisor> candidateAdvisors = findCandidateAdvisors();
		// 2.
		List<Advisor> eligibleAdvisors = findAdvisorsThatCanApply(candidateAdvisors, beanClass, beanName);
		extendAdvisors(eligibleAdvisors);
		if (!eligibleAdvisors.isEmpty()) {
			eligibleAdvisors = sortAdvisors(eligibleAdvisors);
		}
		return eligibleAdvisors;
	}

我们虽使用了注解来使用aop，但是xml仍可以进行配置，因此需要获取xml和注解配置的增强

@Override
	protected List<Advisor> findCandidateAdvisors() {
		// 获取xml中配置的增强
		List<Advisor> advisors = super.findCandidateAdvisors();
		// 获取注解配置的增强
		advisors.addAll(this.aspectJAdvisorsBuilder.buildAspectJAdvisors());
		return advisors;
	}
